Life Span SPIRIT User manual

NOTE: This manual may be subject to updates or changes. Up to date manuals are available through our website at www.lifespanonline.com.au

Product may vary slightly from the item pictured due to model upgrades

Read all instructions carefully before using this product. Retain this owner’s manual for

future reference.

SPIRIT OWNER’S MANUAL

SPIRIT

TABLE OF CONTENTS

1. IMPORTANT SAFETY INSTRUCTIONS 3

2. IMPORTANT ELECTRICAL INFORMATION 4

3. IMPORTANT OPERATING INSTRUCTIONS 5

4. ASSEMBLY INSTRUCTIONS 6

5. FOLDING INSTRUCTIONS 10

6. OPERATION GUIDE 11

7. EXERCISE GUIDE 21

8. MAINTENANCE INSTRUCTIONS 23

9. EXPLODED DIAGRAM 30

10. PARTS LIST 31

11. TROUBLE SHOOTING GUIDE 33

12. WARRANTY 35

SPIRIT

1. IMPORTANT SAFETY INSTRUCTIONS

WARNING - Read all instructions before using this treadmill.

It is important your treadmill receives regular maintenance to prolong its useful life. Failing to

regularly maintain your treadmill may void your warranty.

Danger –To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to

cleaning and/or service work.

DO NOT USE AN EXTENSION CORD: DO NOT ATTEMPT TO DISABLE THE GROUNDED PLUG BY

USING IMPROPER ADAPTERS OR IN ANY WAY MODIFY THE CORD SET.

Install the treadmill on a flat level surface with access to a 220-240 volt (50/60Hz), grounded outlet.

Do not operate treadmill on deeply padded, plush or shag carpet. Damage to both carpet and

treadmill may result.

Do not block the rear of the treadmill. Provide a minimum of 1 metre clearance between the rear of

the treadmill and any fixed object.

Place your unit on a solid, level surface when in use

Never allow children on or near the treadmill.

When running, make sure the plastic clip is fastened on your clothing. It is for your safety, should

you fall or move too far back on the treadmill.

Keep hands away from all moving parts.

Never operate the treadmill if it has a damaged cord or plug.

Keep the cord away from heated surfaces.

Do not operate where aerosol spray products are being used or where oxygen is being administered.

Sparks from the motor may ignite a highly gaseous environment.

Never drop or insert any object into any openings.

The treadmill is intended for in-home use only and not suitable for long time running.

SPIRIT

To disconnect, turn all controls to the off position, remove the safety key, and then remove the plug

from the outlet.

The pulse sensors are not medical devices. Various factors, including the user’s movement, may

affect the accuracy of heart rate readings. The pulse sensors are intended only as exercise aids in

determining heart rate trends in general.

Use the handrails provided; they are for your safety.

Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on your

treadmill. Quality athletic shoes are recommended to avoid leg fatigue.

Allowed temperature: 5 to 40 degrees.

Remove the safety key after use to prevent unauthorized treadmill operation.

2. IMPORTANT ELECTRICAL INFORMATION

WARNING!

NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. Route the power

cord away from any moving part of the treadmill including the elevation mechanism and transport

wheels.

NEVER remove any cover without first disconnecting AC power.

NEVER expose this treadmill to rain or moisture. This treadmill is not designed for use outdoors,

near a pool, or in any other high humidity environment.

This is high-power item; please do not share the same outlet with other high power machines such

as, fridges, air conditioning etc. Please choose an outlet exclusively for the machine and make sure

the fuse is 10A.

SPIRIT

3. IMPORTANT OPERATING INSTRUCTIONS

Be sure to read the entire manual before operating your machine.

Understand that changes in speed and incline do not occur immediately. Set your desired speed on

the computer console and release the adjustment key. The computer will obey the command

gradually.

Use caution while participating in other activities while walking on your treadmill, such as watching

television, reading, etc. These distractions may cause you to lose balance or stray from walking in

the centre of the belt; which may result in serious injury.

In order to prevent losing balance and suffering unexpected injury, NEVER mount or dismount the

treadmill while the belt is moving. This unit starts with at a very low speed. Simply standing on the

belt during slow acceleration is proper after you have learned to operate this machine.

Always hold on to handrail while making control changes.

A safety key is provided with this machine. Remove the safety key will stop the walking belt

immediately; the treadmill will shut off automatically. Inserting the safety key will reset the display.

Do not use excessive pressure on console control keys. They are precision set to function properly

with little finger pressure.

SPIRIT

4. ASSEMBLY INSTRUCTIONS

PARTS LIST

DES.

Specification

Qty

DES.

Specification

Qty

Main frame

wrench w/screw driver

S=13、14、15

#5 Allen wrench

5mm

Lock washer

Bolt

M8*45

Bolt

ST4.2*19

Bolt

M8*16

Spring

Left back cover

Rubber Pads

Right back cover

Safety key

ASSEMBLY TOOLS:

5#ALLEN WRENCH 5mm x 1pc

Wrench with screw driver S=13, 14, 15 x 1pc

Note: Do not connect power before completing assembly

SPIRIT

STEP 1:

STEP 2:

1. Open the carton

2. Extract the parts listed above

3. Place the Main Frame onto level

ground

1. Move the display according to the

diagram. Insert Bolts M8*16(51) and

Lock washers (64) into Left and Right

Upright.

2. Attach the Computer frame to Left

Upright and Right Uprights by

tightening the bolts

Note: As you erect the display, make sure

that you do not damage the wires between

the tubes.

SPIRIT

STEP 3:

STEP 4:

1. Erect the display according to the

diagram

Note: Support the upright tube with your

hands to prevent it from falling down.

1. Use the 5# Allen Wrench (12), m8*45 bolt

(70) and lock washer (64) to attach the

left and right upright tubes (3,4) to the

Main Frame (1) using the Bolt M8*16 (51)

and Lock washer (64).

SPIRIT

STEP 5:

STEP 6:

STEP 7:

1. Use the wrench w/screw driver (61) to

attach the Left back cover(83) onto the

base frame with ST4.2*19(60).

1. Knock the spring(89) onto the rubber

pads(43)

2. Lift the frame up, and screw the rubber to

the frame.

1. Place the safety key (71) onto the

computer and start your exercise.

SPIRIT

5. FOLDING INSTRUCTIONS

Folding:

Unfolding:

Place your hand on position (A), then pull

up the base frame until you hear the click

sound emitted when the air pressure bar

(B) is locked into the round tube.

Whilst supporting position A with our

hand, gently push the marked area on the

air pressure bar with your foot.

The base frame will descend gradually.

(Please keep people and any pets away

the machine during descent)

Video Tutorial Available at:

http://youtu.be/TcuPbJ7KuxQ

Lifespan Fitness YouTube Channel:

http://www.youtube.com/user/treadmillsvideos
