LG GCB369BVQA User manual

P/No.MFL37432203

FRIDGE-FREEZER

Please read this User’s Guide carefully before

operating and keep it handy for reference at all times.

User's Guide

Important

(In the UK Only)

The wires in this mains lead are coloured in accordance

with the following code:

As the colours of the wires in the mains lead of this

apparatus may not correspond with the coloured

markings identifying the terminals in your plug, proceed

as follows:

The wire which is coloured Green and Yellow must be

connected to the terminal in the plug which is marked

with the letter E or by the earth symbol( ) or coloured

Green or Green and Yellow.

The wire which is coloured Blue must be connected to

the terminal which is marked with the letter N or

coloured Black.

The wire which is coloured Brown must be connected to

the terminal which is marked with the letter L or

coloured Red.

If a 13 amp(BS 1363) plug is used, fit a 13 amp BS 1362

fuse.

GREEN AND YELLOW:EARTH

BLUE:NEUTRAL

BROWN:LIVE

This appliance must be earthed

Fuse

Cord

grip

Green and Yellow(Earth)

Brown(Live)

Blue(Neutral)

Introduction

Installation

Operation

Suggestion On

Food storage

Trouble Shooting

Care and

Maintenance

To Reverse

the Doors

Table of Contents

Registration

Important Safety Instruction

Identification of Parts

Installation

Starting

Temperature Control

Defrosting

Storing Food

General Information

Lamp Replacement

Cleaning

Trouble Shooting

To Reverse the Doors

Refrigerator

Freezer

Vacation

Lock

Self Test

Ice Making

Super Freezer

Function

Introduction

Precaution

Registration

The model and serial number are found on the rear of

this unit. This number is unique to this unit and not

available to others. You should record requested

information here and retain this guide as a permanent

record of your purchase. Staple your receipt here.

Date of Purchase :

Dealer Purchased From :

Dealer Address :

Dealer Phone No. :

Model No. :

Serial No. :

Important Safety Instruction

This fridge-freezer must be properly installed and

located in accordance with the Installation

Instruction before it is used.

Never unplug your fridge-freezer by pulling on the

power cord. Always grip plug firmly and pull straight

out from the outlet.

When moving your appliance away from the wall,

be careful not to roll over or damage the power

cord.

After your fridge-freezer is in operation, do not

Children should be supervised to ensure that they

do not play with the appliance.

touch the cold surfaces in the freezer compartment,

particularly when hands are damp or wet. Skin may

adhere to these extremely cold surfaces.

Introduction

Important Safety Instruction

Don't Use an

Extension Cord

If possible, connect the fridge-freezer to its own individual

electrical outlet to prevent it and other appliances or household

lights from causing an overload.

Accessibility of

Supply Plug

The supply plug of the refrigerator-freezer should be placed in

easy accessible position for quick disconnection in emergency.

Supply Cord

Replacement

If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a similarly qualified person

in order to avoid a hazard.

Don't store

Don't store or use gasoline or other flammable vapors and

liquids in the vicinity of this or any other appliance.

Grounding

(Earthing)

In the event of an electric short circuit, grounding (earthing)

reduces the risk of electric shock by providing an escape wire for

the electric current. In order to prevent possible electric shock,

this appliance must be grounded. Improper use of the

grounding plug can result in an electric shock. Consult a

qualified electrician or service person if the grounding

instructions are not completely understood, or if you have

doubts on whether the appliance is properly grounded.

Danger

Risk of child entrapment. Before you throw away your old

refrigerator or freezer: Take off the doors.

Leave the shelves in place so that children may not easily

climb inside.

It will cause electric shock or fire.

Do not modify or

extend the Power

Cord length

Precaution Pull out the power plug prior to cleaning the fridge-

freezer.

Never damage, serverely bend, pull out, or twist the

power cord because power cord damage may cause a

fire or electronic shock. Never place glass products in the

freezer because they may be broken when their inner

contents are frozen.

noi

cud

bosi

atn

tiw

an ,)a

(

gir

sla si ti

ibitapmoc

eht

lla

tsni d

tah

at eb dluo

.dega

iucr

c gn

tare

pip eht

o tuo gnit

ted

si ka

l a

rujn

eye na esuac

dna

ting

o secruos

etop ro sem

lf dekan

rof gnidna

s si

ecnailppa eht

cihw ni moor eht

.setunim lareves

ria

sag elba

mal

a fo n

ht diova ot redro nI

is eht

srucco

ric gnita

girfer eh

ni kael

fi erutxim

sdnepe

is eb

m e

nai

ppa eht hcihw ni moor

ht fo

tsum

oor ehT .de

tna

girfer fo tnuoma eht no

m1 2eht ed

nare

girfe

reve rof ezi

ral

citra

ruoy

i t

nar

egirf

tnuoma ehT .ecnailppa

disni etal

noitacifitne

wohs

i ecnailppa

.ecnailppa

s yna

nai

ppa n

rats reveN

.re

lae

ruoy

usno

,tbuod ni fI .e

ama

Warning

o n

s n

eso

to ,

eco

ric t

egi

ail

a l

t ss

ail

fo s

moc

rp l

psi

tiw

Introduction

Identification of Parts

Note If you find some parts missing from your unit, they

may be parts only used in other models.

Removable

Glass Shelf(2 or 3)

Lamp

Multi-air Flow Duct

Fresh Zone (Optional)

Refrigerator

Temperature Control

(1 or 2)

Vegetable Drawer

Used to keep fruits

and vegetables, etc.

fresh and crisp.

Ice Cube Tray

Freezer

Compartment

Removable

Plinth

Rotatable

Door Basket

(3 or 5)

Utility Corner

(movable)

Bottle Holder

Door Basket

Leveling Screw

Egg Tray(1 or 2)

(Optional)

Handle

Bottle

Installation

1. Select a good location.

Place your fridge-freezer where it is easy to use.

2. Avoid placing the unit near heat sources,

direct sunlight or moisture.

3. There must be proper air circulation around your

fridge-freezer to keep it operating efficiently.

4. To avoid vibration, the unit must be leveled.

If required, adjust the leveling screws to compensate

for the uneven floor.

The front should be slightly higher than the rear to aid

in door closing.

Leveling screws can be turned easily by tipping the

cabinet slightly.

Turn the leveling screws counterclockwise( ) to

raise the unit, clockwise( ) to lower it.

5. Clean your fridge-freezer thoroughly and wipe off all

dust accumulated during shipping.

6. Install accessories such as ice cube box, etc., in their

proper places.They are packed together to prevent

possible damage during shipment.

7. Connect the power supply cord (or plug) to the outlet.

Don't double up with other appliances on the same

outlet.

8. To ensure proper air circulation around the fridge -

freezer, please maintain sufficient space on both the

sides as well as top and maintain at least 2 inches (5

cm) from the rear wall.

When your fridge-freezer is installed, allow it 2-3 hours to

stabilize at normal operating temperature prior to filling

it with fresh or frozen foods.

If power plug is disconnected, allow 5 minutes delay

before restarting.

Your fridge-freezer is now ready for use.

Installation

Starting

Operation

Display Panel For Temperature Control

Temperature Control

Your fridge-freezer has two controls that let you regulate

the temperature in the fridge and freezer compartments.

• Initially set the TEMP. CONTROL at

"4". Then adjust the compartment

temperature according to your

desire.

• If you want an inside temperature

slightly less cold or colder, turn the

knob towards MIN or MAX,

respectively. When the surrounding

temperature is low, adjust the TEMP. CONTROL 'MIN'.

Refrigerator

Freezer

TEMP. CONTROL

MAX

MIN

This manual suits for next models
