Lenovo IdeaPad K1 User manual

07/12/11 09:32IdeaPad Tablet K1 - User Manual

Page 1 sur 1http://download.lenovo.com/UserFiles/UserGuide/en/K1_MULTI_LANGUAGE/K1%20v2.0/110822%20update/assets/data/EN/index.html

IdeaPad Tablet K1

User Guide V1.0

Please read the

safety precautions and important notes

in the supplied manual before use.

07/12/11 09:33IdeaPad Tablet K1 - Chapter 01

Page 1 sur 11http://download.lenovo.com/UserFiles/UserGuide/en/K1_MULTI_LANGUAGE/K1%20v2.0/110822%20update/assets/data/EN/chapter01.html

Chapter 01

Overview of IdeaPad Tablet K1

*Specific models only

1-1 Appearance Description

1-2 Buttons Description

1-3 Powering IdeaPad Tablet K1 On/Off

1-4 Turning Screen Backlight On/Off

1-5 Screen Lock/Unlock

1-6 Basic Gestures

1-7 Navigation Tips

1-8 4-Pane Desktop

1-9 Home Screen

1-10 Switching Home Screen

1-11 Status Bar

1-12 Recent Apps

1-13 Applications Management

1-14 Entering Text

1-15 Synchronization

1-1 Appearance Description

The picture is for reference purposes only, and may differ from the actual item, which is the standard.

1-2 Buttons Description

07/12/11 09:33IdeaPad Tablet K1 - Chapter 01

Page 2 sur 11http://download.lenovo.com/UserFiles/UserGuide/en/K1_MULTI_LANGUAGE/K1%20v2.0/110822%20update/assets/data/EN/chapter01.html

Power Button

While in the shutdown mode, press and hold this button (for about 2-3 sec) to power on your IdeaPad Tablet K1.

After your IdeaPad Tablet K1 is powered on, press this button to turn off the illuminated screen display. While the

screen display is off, press this button again to re-illuminate the screen.

After your IdeaPad Tablet K1 is powered on, press and hold this button (for about 2-3 sec) to bring up IdeaPad Tablet

K1. Power off pop-up box; press OK to shut down IdeaPad Tablet K1.

After your IdeaPad Tablet K1 is powered on, press and hold this button (for about 6 sec) to forced shutdown.

Volume Button

Adjusts the volume.

Screen Rotation Lock Button

Toggle the button UP to unlock the screen orientation, allowing screen rotation.

Toggle the button DOWN to lock the screen orientation, not allowing screen rotation.

*SIM card socket

The SIM card slot is located on the upper right of the device frame. In the Power off mode, insert the end of a sharp-

pointed object into the small hole above the socket until the stopper pin pops out, and then insert the SIM card. To

remove the SIM card, push the stopper down with your finger until it pops out.

1-3 Powering IdeaPad Tablet K1 On/Off

Powering IdeaPad Tablet K1 On

Press and hold the "Power" button on the upper left of IdeaPad Tablet K1, and the Lenovo and startup screens display in

sequence, indicating that IdeaPad Tablet K1 has been powered on.

Powering IdeaPad Tablet K1 Off

Press and hold the "Power" button on the upper left of IdeaPad Tablet K1 until <Power off> appears.

off your IdeaPad Tablet K1.

*For the 3G-enabled version, be sure to insert or remove the SIM card in the Power off mode. Doing so when the device is

on may damage the SIM card.

1-4 Turning Screen Backlight On/Off

07/12/11 09:33IdeaPad Tablet K1 - Chapter 01

Page 3 sur 11http://download.lenovo.com/UserFiles/UserGuide/en/K1_MULTI_LANGUAGE/K1%20v2.0/110822%20update/assets/data/EN/chapter01.html

1-4 Turning Screen Backlight On/Off

Turning Screen Backlight On

In the standby mode, you can tap the "Power" button on the upper left of the IdeaPad Tablet K1 to "wake" the screen up.

The device's screen will then light up, indicating that the backlight has been turned on.

Turning Screen Backlight Off

If your IdeaPad Tablet K1 is powered on and you do not use it temporarily, you can tap the "Power" button on its upper left

to turn off the screen backlight. Your IdeaPad Tablet K1 will enter the standby mode to save power.

1-5 Screen Lock/Unlock

Lock Screen

Auto Lock

You can set Screen timeout in <Screen> under " Settings". If there is no operation within the preset standby time,

then the screen backlight will automatically turn off, and the device will be locked.

07/12/11 09:33IdeaPad Tablet K1 - Chapter 01

Page 4 sur 11http://download.lenovo.com/UserFiles/UserGuide/en/K1_MULTI_LANGUAGE/K1%20v2.0/110822%20update/assets/data/EN/chapter01.html

Manual Lock

If your IdeaPad Tablet K1 is powered on and you do not use it temporarily, you can tap the "Power" button on its upper left

to dim the screen display down. The device will then enter the standby mode and become locked.

How to Unlock

Once in the standby mode, tap the "Power" button on the upper left of IdeaPad Tablet K1 to brighten the screen display

back up to normal level. You can also tap the lock icon by following on-screen instructions to unlock the screen, as shown in

the figure below:

Screen Lock Pattern Settings

You can touch <Lock screen> in <Location & security> under "Settings" to set the screen lock pattern. After this function

has been enabled, you will need to draw your unlock pattern in order to unlock the screen before you can use your device.

1-6 Basic Gestures

(1) Scroll up to display

the dynamic menu

(2) Scroll down to return

to the previous page

(3) Click to return to the

desktop

(4) Press and hold to

capture screen

07/12/11 09:33IdeaPad Tablet K1 - Chapter 01

Page 5 sur 11http://download.lenovo.com/UserFiles/UserGuide/en/K1_MULTI_LANGUAGE/K1%20v2.0/110822%20update/assets/data/EN/chapter01.html

the dynamic menu

to the previous page

Down

desktop

Click

capture screen

1-7 Navigation Tips

Home : Back to the home screen.

Back : Back to the previous screen.

Recent Apps : Display recent apps.

App menu : Display all tablet’s apps.

Add widget : Add widgets and shortcuts.

07/12/11 09:33IdeaPad Tablet K1 - Chapter 01

Page 6 sur 11http://download.lenovo.com/UserFiles/UserGuide/en/K1_MULTI_LANGUAGE/K1%20v2.0/110822%20update/assets/data/EN/chapter01.html

1 - Open App Menu 4 - Back

2 - Recent Apps 5 - Add Widget

3 - Home

1-8 4-Pane Desktop

07/12/11 09:33IdeaPad Tablet K1 - Chapter 01

Page 7 sur 11http://download.lenovo.com/UserFiles/UserGuide/en/K1_MULTI_LANGUAGE/K1%20v2.0/110822%20update/assets/data/EN/chapter01.html

1-9 Home Screen

This desktop enables you to quickly view and open your most frequently used applications.

In the home screen, you can add widgets or shortcuts, and change your wallpaper.

Touch to add widgets and shortcuts, and to change your wallpaper. Drag the widget, shortcut, or other item to

the home screen panel you want.

To delete something on the home screen, touch and hold the desired gadget until a Trash Bin icon appears on the

upper right corner, and then drag and drop the gadget icon onto the Trash Bin icon.

1-10 Switching Home Screen

07/12/11 09:33IdeaPad Tablet K1 - Chapter 01

Page 8 sur 11http://download.lenovo.com/UserFiles/UserGuide/en/K1_MULTI_LANGUAGE/K1%20v2.0/110822%20update/assets/data/EN/chapter01.html

Your IdeaPad Tablet K1 has multiple desktops.

You can slide the screen with your finger to switch the display, and move icons among home screens.

1-11 Status Bar

The system message(s), if any, will be displayed in the lower right corner of IdeaPad Tablet K1.

You can get the information about WLAN connection status, Signal level, Power level, Charging status and other detail

notifications about your tablet.

Touch the Status bar, display the Notification Panel. Press button can open the detail setting view, including Airplane

mode switch, Wi-fi setting shortcut, brightness adjustment toolbar, notifications switch, settings shortcut, etc..

1-12 Recent Apps

Your tablet remembers the apps you used recently.

Touch to see your recent apps list. Touch an app to open it.

07/12/11 09:33IdeaPad Tablet K1 - Chapter 01

Page 9 sur 11http://download.lenovo.com/UserFiles/UserGuide/en/K1_MULTI_LANGUAGE/K1%20v2.0/110822%20update/assets/data/EN/chapter01.html

Touch to see your recent apps list. Touch an app to open it.

1-13 Applications Management

Tap on the home screen to open the applications list.

You can enter

Manage applications

Applications

under "

Settings

Uninstall

Tap Downloaded, then the app, press the Uninstall button on the top to uninstall app.

Stop/change setting

Tap All or Running, tap the app, then the option you want.

Reinstall

Tap Market in applications list, for details please refer to "App Shop" on "Chapter 2".

Previously installed apps are listed and available for downloading.
