Lenovo TAB A10-70 User manual

Lenovo TAB A10-70

Quick Start Guide v1.0

Read this guide carefully before using your tablet.

All information labeled with * in this guide refers only to the

WLAN + 3G model (Lenovo A7600-H).

Technical speciﬁcations

Type: CMOS

Pixels: 5 MP (back) + 2 MP (front)

GPS

Height: 264.1 mm Width: 176.54 mm Depth:

8.9 mm

Weight: 561 g *563 g

CPU: MT8121 Quad Core 1.3GHz

*MT8382 Quad Core 1.3GHz

Size: 10.1 inches (diagonal) Screen: Multi-touch display

Resolution: 1280 × 800 LCD type: IPS

Model: Lenovo A7600-F *Lenovo A7600-H

②Bluetooth 4.0 WLAN 802.11b/g/n *WCDMA, GSM

①Actual product may differ.

② Launch with Android 4.2 which only supports BT 4.0 PXP proﬁle.

Battery: 6340 mAh

Wireless communication

Display

Model and system

Power and battery

CPU

① Size and weight

Camera

Version: WLAN *WLAN + 3G

System:Android 4.2

First glance

The WLAN model (Lenovo A7600-F) does not have a SIM card slot.

Micro USB port

Microphone

Speakers Back camera

On/Off button

Front camera

789

Volume key

*SIM card slot

microSD card slot

Earphone jack

SIM

10.00

Installing the *SIM card & microSD card

Step 1. Open the card slot cover as shown.

Step 2. Insert the SIM card into the SIM card slot and the microSD card

into the microSD card slot.

Step 3. Carefully replace the card slot cover.

You can use cellular services with the WLAN + 3G model (Lenovo

A7600-H) by inserting the SIM card provided by your carrier services.

Install the SIM card as shown.

Do not insert or remove the SIM card while your tablet is turned on. Doing so

may permanently damage your SIM card or tablet.

SIM

Reset

Your device has a built-in rechargeable battery. For more information

about battery safety, see “Built-in rechargeable battery notice” in the

Important Product Information Guide .

Charging and turning on/off your tablet

Low battery Fully charged Charging

Before using your tablet, you might need to charge the battery.

Charge the battery as shown.

Method 1. Connect your tablet to a power outlet using the included cable and

USB power adapter.

Method 2. Charge the battery using a computer.

8306LVP912W

Printed in China

Learn more

Legal notices

Lenovo and the Lenovo logo are trademarks of Lenovo in the United States,

other countries, or both.

Other company, product, or service names may be trademarks or service

marks of others.

Manufactured under license from Dolby Laboratories. Dolby and the

double-D symbol are trademarks of Dolby Laboratories.

First Edition (February 2014) © Copyright Lenovo 2014.

For other useful manuals, please access “User Guide” from the Browser

favorites in your tablet.

For “Regulatory Notices”, please go to http://support.lenovo.com/.

Getting support

For support on network service and billing, please contact your wireless

network operator. For instructions on how to use your tablet, go to

http://support.lenovo.com/.

Radio and Telecommunications Terminal Equipment Directive

This product is in compliance with the essential requirements and other

relevant provisions of the Radio and Telecommunications Terminal

Equipment Directive, 1999/5/EC.

European Union conformity
