Legacy Sconce User manual

2

Registration

3. Owners Record

4. The Cabinetry / Our Commitment

Setup

5. Unpacking Your Speakers

6. Speaker Installation

12. Hook up Cables

13. Amplification

Technology

14. Designer’s Note

15. Specifications

3

The model and serial numbers are located on the rear of the unit. Record

these numbers in the spaces provided below. Refer to them when calling

upon your dealer regarding this product.

Model No. _______________________________

Serial No. _______________________________

Date of purchase: _________________________

Thank you for selecting a Legacy Loudspeaker System. These hand-

crafted instruments will provide you with many years of listening

enjoyment. Please take a few moments to read this brief manual to insure

maximum benefit from your speaker system.

4

Handcrafted

Each Sconce cabinet is impeccably finished with select veneers. The

exquisite finish is hand-rubbed several times to assure a patina at home

with the most elegant decor.

Our Commitment

A great deal of forethought, love and satisfaction is instilled in each piece

of Legacy workmanship. We take pride in getting to know many of our

customers on a first name basis.

Your purchase is backed by the renown “Legacy Satisfaction Guarantee”.

5

Your new speaker system has been very carefully packaged to insure that

it travels to you safely. A double-wall outer carton protects each speaker

with heavy V-board corner protectors. Custom foam end caps are used to

protect the elegant cabinetry, and a plastic liner is provided as

waterproofing. Please save this packing for future transportation. If cartons

become damaged or misplaced, new ones can be purchased from Legacy

Audio.

6

Precautions

If you have any doubts about your ability to properly install in-wall

loudspeakers, you should use the services of a custom installer.

7

Installing the Sconce On-Wall Loudspeakers

Packing List

Sconce Speaker with pre-attached mounting keys

Wall Plate

Installation Manual

Tools Required

Pencil

Level

Phillips Screwdriver

Tape Measure

8

Installation Preparation:

1. Determine and mark the location of all speakers. Use of a level will be helpful to assure

the proper orientation. Sconce speakers may be installed either horizontally or vertically.

Sconce Surround speakers can only be installed in the vertical position. Consider the

location of pipes, wires or other materials that may be affected by drilling or installing

fasteners into the wall.

2. Install suitable speaker wire from your electronic components to the location of where the

speaker terminal plate will rest, once installed, and leave enough wire length to allow easy

connection to both the receiver/amplifier and the speaker. Legacy Audio recommends the

use of up to 16-gauge wire for the Sconce speaker system. If installing in the wall be sure

that the wire meets local electrical code.

9

Mounting Sconce:

1. Install the provided metal wall plate as shown (Figure 1) with a minimum of (4), #8 Pan

Head Screws, making sure that the proper side of the wall plate is placed against the wall.

Note that the Sconce speaker has two pre-attached diamond shaped keys mounted to the

back panel. These keys will align with the corresponding diamond shaped keyholes in the

wall plate.

Consider the position and orientation of the speaker when attached with corresponding key

points. Use screws long enough to provide at least one-inch penetration into the wall stud

or masonry surface. If using the minimum number of mounting screws, insure that at least

one screw is installed on each side of the back plate keyhole area.

It is recommended that on-wall speakers be installed where all fasteners or screws are

imbedded into a wall stud or masonry component. Other options may include the use of

mollies or toggles depending upon the wall materials and thickness.

Caution: Improper mounting of the speaker to the wall could result in the speaker falling,

creating a dangerous condition. You should engage the services of a professional installer

if you are not fully qualified to mount these speakers on a wall.

10

2. Using at least two people, lift the Sconce speaker close to the back plate and make

necessary wire connections insuring correct wire polarity.

3. Place the Sconce speaker onto the back plate aligning the metal keys into the keyhole

areas of the wall plate. Firmly press the speaker down and slide into the wall plate to

secure the speaker.
