Larson Electronics EPL-SL-2-LED-ITG-M2 User manual

EPL-SL-2-LED-ITG-M2

Explosion Proof LED String Lights

120-277V AC - (2) LED Lamps - 360° - Y Connector

Instruction Manual

Thank you for your purchase of the Larson Electronics EPL-SL-2-LED-ITG-M2 string light.

WARNING

TO AVOID THE RISK OFFIRE, EXPLOSION OR ELECTRIC SHOCK, THIS PRODUCT SHOULD BE INSTALLED,

INSPECTED AND MAINTAINED BY A QUALIFIED ELECTRICIAN ONLY, IN ACCORDANCE WITH ALL

APPLICABLE ELECTRICAL CODES.

TO AVOID ELECTRIC SHOCK:

•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.

•PRODUCT MUST BE CONNECTEDTOA WIRING SYSTEM WITHAN EQUIPMENT-GROUNDING

CONDUCTOR.

TO AVOID EXPLOSION:

•MAKE SURE THE SUPPLY VOLTAGE IS WITHIN THE VOLTAGE RATING.

•ENSURE THE MARKED T RATING IS LESS THAN THE IGNITION TEMPERATURE OF THE HAZARDOUS

ATMOSPHERE.

•DO NOT OPERATE IN AMBIENT TEMPERATURES ABOVE THOSE INDICATED ON THE PRODUCT

NAMEPLATE.

•DO NOT OPERATE IF THE LENS, CORD, SEALS, HOUSING, RECEPTACLES, ETC. IS CRACKED OR

DAMAGED. IF SO, DISCONTINUE USE AND CONTACT MANUFACTURER FOR REPLACEMENT PARTS.

•ALL FASTENERS SHOULD BE PROPERLY SEATED.

The Larson Electronics EPL-SL-2-LED-ITG-M2 Explosion Proof LED String Light is ideal for general lighting, detailed tasks

and inspections in hazardous locations. This 60-watt unit features a total of two LED handlamps, which provides 6,000

lumens of total output during use. A unique angled board design ensures 360° of comprehensive illumination. The

explosion proof light is equipped with a Y connector, which has a single input cord with an explosion proof cord cap

branching out to the LED lights.

Operation

Position device near work area for operation. Run cable to nearby power source. Insert

and twist-lock explosion-proof plug into a compatible receptacle within the hazardous

environment. See Plug Operation below for specifics on operating the explosion proof

cord cap with compatible explosion proof receptacle within the hazardous area. The light

is "instant on", meaning it will illuminate as soon as it is supplied with power.

PLUG OPERATION

Electrical connection between plug and compatible receptacle is accomplished after plug

fully inserts into receptacle and rotated clockwise.

WARNING: Check product label for correct voltage! Failure to comply could

result in damage to the fixture which may not be covered by any warranty.

1. Lift receptacle door and locate polarization on mating plug pin and receptacle face. Insert plug straight all

the way into receptacle until it cannot go further.

2. Rotate plug clockwise limit (37º), this closes internal contacts and completes circuit. This also

mechanically locks plug into receptacle so it cannot be pulled out.

3. To remove plug, push plug inward and turn to counterclockwise, pull plug straight out.

Larson Electronics, LLC Phone: (877) 348-9680 Fax: (903) 498-3364 www.larsonelectronics.com 1of 2

Larson Electronics, LLC Phone: (877) 348-9680 Fax: (903) 498-3364 www.larsonelectronics.com 2of 2

EPL-SL-2-LED-ITG-M2

MAINTENANCE

There are no serviceable parts inside the fixture. However, it is good practice to routinely clean and check the

fixture for proper function.

•Disconnect power running to the lamp and be sure the fixture is cool to the touch.

•Use a non-abrasive glass cleaning solution to clean the lens.

Note: It is not necessary to open the fixture and clean or touch the LED’s.

USE AND CARE

Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.

Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of

children when not in use.Inspect for good working condition prior to storage and before re-use.

REPLACEMENT PARTS

The EPL-SL-2-LED-ITG-M2 is designed to provide years of reliable performance. Should the need for replacement parts

arise, please contact Larson Electronics.

THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.

SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT

SAL[email protected] OR BY PHONE AT 1-877-348-9680 FOR FURTHER ASSISTANCE.

PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
