KTI Networks KS-108F User manual

5/8-Port Fast Ethernet Switches

with 1 Fiber Connection

KS-105F, KS-108F

Specifications :

Key Features :

 Provide 4/7 10/100Mbps Fast Ethernet Switch ports and 1 100Base-FX port

 Each TP port supports auto-negotiation and auto-MDI/MDI-X detection

 For the 100Base-FX fiber port, the switch series supports variety of fiber connectors for different

application needs. The fiber connectors include ST, SC, MT-RJ, LC and VF-45 types for

multimode and single mode fiber cables

 Support duplex mode selector for the 100BASE-FX fiber port

 Self learning for active MAC addresses and address aging

 Store-and-forward switching to ensure only good packets are forwarded

 Forwarding and filtering at full wire speed

 Support IEEE 802.3x flow control for full-duplex mode and backpressure flow control for half-

duplex mode

 Comprehensive LED indicators provide quick, easy to read port and switch information

10/100 Ports IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX std.

Shielded RJ-45 jacks with Auto MDI-X detection

Auto-negotiation capable

Speed for 10Mbps or 100Mbps

Full-duplex or half-duplex mode support

100FX Port IEEE 802.3u 100BASE-FX compliant

Fixed 100Mbps operation

Duplex mode selector - full-duplex or half-duplex

Flow control IEEE 802.3x pause packet for full-duplex operation

Back-pressure for half-duplex operation

Cables 10Base-T : Cat. 3, 4, 5 or higher (100 meters max.)

100Base-TX : Cat. 5, 5e or higher (100 meters max.)

100Base-FX : multimode or single mode fiber cable

LEDs Power status

Per port : Speed, Link, Activity, Duplex, Collision status

Forwarding rate 14,880 pps for Ethernet (10M)

148,800 pps for Fast Ethernet (100M)

Filtering address Multicast/Broadcast/Unicast address

MAC Address Table 1K entries

Aging time KS-105F : 300 seconds

KS-108F : 240 seconds

080110

FCC Part 15'Class A

CISPR 22 Class A

Katron Technologies Inc.

15F-7, No. 79, Sec. 1, Hsin Tai Wu Rd.,

Hsi-chih, Taipei Hsien, Taiwan.

Te l : 886-2-2698-3878

Fax : 886-2-2698-3873

E-mail : [email protected]

URL : http : //www.ktinet.com.tw

KTI Networks Inc.

7400 Harwin Dr., Suite 120 Houston,

Texas 77036 U.S.A.

Te l : 713-266-3891

Fax : 713-914-0555

E-mail : [email protected]

URL : http : //www.ktinet.com

Trademarks : All brand names are trademarks or registered

trademarks of their respective holders.

This information is subject to change without prior notice.

Environment Operating Temperature : 0

C ~ 40

Relative Humidity : 10% ~ 90% non-condensing

Dimensions KS-105F : 144 x 104.5 x 26 mm (WxDxH)

KS-108F : 180 x 114.5 x 26 mm (WxDxH)

DC IN Jack Rating +7.5V/1A, D6.3mm D2.0mm

DC IN voltage Operating +6.0V ~ +12.6VDC (Device DC Input)

Power Consumption KS-105F : 3.9 watts. (max.)

KS-108F : 6.3 watts. (max.)

Fiber Optical Specification :

Model Connector FiberCable Wavelength Tx Power Sensitivity Rx Max.

-T ST Duplex MMF 1310nm -19~ -14dBm -31dBm -14dBm

-C SC Duplex MMF 1310nm -19~ -14dBm -31dBm -14dBm

-JM MT-RJ MMF 1310nm -19~ -14dBm -31dBm -14dBm

-VM VF-45 MMF 1310nm -20~ -14dBm -31dBm -14dBm

-SA2 SC Duplex SMF 1310nm -15~ -8dBm -31dBm -7dBm

-SL2 SC Duplex SMF 1310nm -15~ -7dBm -32dBm -3dBm

-SL3 SC Duplex SMF 1310nm -15~ -8dBm -34dBm 0dBm

-SL4 SC Duplex SMF 1310nm -5~ 0dBm -34dBm -3dBm

-W3515 Bi-Di SC SMF TX 1310nm -14~ -8dBm -31dBm 0dBm

RX 1550nm

-W5315 Bi-Di SC SMF TX 1550nm -14~ -8dBm -31dBm 0dBm

RX 1310nm

MMF : Multimode fiber -62.5/125 µm, 50/125 µm

SMF : Single Mode fiber - 9 /125 µm

Ordering Information :

MM : Multimode Fiber

SM : Single Mode Fiber

Ref. Distance: Reference connection distance

Mode

Fiber Distance

Ref.

2km

KS-105F

KS-108F

-T

-C

Dual ST

Dual SC

Connector

2km

20km

40km

20km

30km

-JM

-VM

-SL4

-SA2

-SL2

-SL3

MT-RJ

VF-45

Dual SC

15~20km

-W3515

-W5315

Bi-Di SC

080110
