Kodak V1233 - Easyshare 12.1MP Digital Camera User manual
www.kodak.com/go/v1233support 1
ENGLISH
Installing the software
Loading the KLIC-7004 battery
After installing the software, return to this
Getting Started Guide.
Be
f
ore connecting any ca
bl
es, insta
ll
t
h
e so
f
tware t
h
at was
included with your camera. Follow the on-screen instructions.
2www.kodak.com/go/easysharecenter
ENGLISH
Charging the battery
Charge until all 3 Battery Charging lights are lit.
If the Battery Charging lights do not turn on during USB charging, ensure:
■The USB cable is connected to a powered USB port
■The computer is turned on, and not in sleep mode
For more on USB charging, visit www.kodak.com/go/USBcharging.
To purchase accessories, visit www.kodak.com/go/v1233accessories.
Charge using a USB computer Charge using a Kodak 5V AC
adapter (may be sold separately)
USB / A/V adapter
(included)
USB cable
(included)
Battery Charging lights
www.kodak.com/go/v1233support 3
ENGLISH
Turning on the camera
Setting the language, date/time
2
1
to change.
for previous/next field.
OK to accept.
At the prompt, press OK.
2
1to change.
OK to accept.
Language:
Date/Time:
OK (press)
4www.kodak.com/go/easysharecenter
ENGLISH
Taking a picture/video
Press the Shutter button
completely down, then
release it.
To stop recording, press and
release the Shutter button
again.
1Press the On/Off or the Auto/SCN
mode button to turn on the camera.
2
Pictures Videos
1
2
Press the Video mode button.
Press the Shutter button halfway
to focus and set exposure.
When the framing marks turn
green, press the Shutter button
completely down.
Video
mode
Framing
marks
www.kodak.com/go/v1233support 5
ENGLISH
Reviewing pictures/videos
1
2for previous/next.
Press Review.
(Press again to exit.)
Videos:
Play. (Press OK to pause/unpause.)
During playback to adjust the volume.
During playback to play at 2X speed; press again for 4X.
During playback to reverse at 2X speed; press again for 4X.
Press and hold for 4 seconds to jump to a bookmark.
6www.kodak.com/go/easysharecenter
ENGLISH
Transferring pictures/videos
For package contents, see your product package. To use a dock, see its Getting Started
Guide. For dock compatibility, visit www.kodak.com/go/dockcompatibility. To
purchase accessories, visit www.kodak.com/go/v1233accessories.
USB cable (U-8)
(included)
USB / A/V adapter
(included)
USB cable
(included)
Kodak EasyShare photo frame dock 2,
camera dock, or printer dock
(may be sold separately)
www.kodak.com/go/v1233support 7
ENGLISH
Keep learning about your camera!
Congratulations! You have:
• set up your camera
• taken pictures
• transferred pictures to your computer
Visit www.kodak.com/go/v1233support for:
• the user’s guide
• interactive troubleshooting and repairs
• interactive tutorials
• FAQs
• downloads
• accessories
• printing information
• product registration
Keep learning!
Finish reading this book, so you can take and share your best pictures!
To better understand each menu option, use camera Help.
(Highlight a menu choice, then press the Zoom telephoto T button.)
8www.kodak.com/go/easysharecenter
ENGLISH
Front view
NOTE: 6, 7, and 8 are also Battery Charging lights.
1Zoom lever (W/T) 7Video mode button
2Shutter button 8Favorites mode button
3Flash 9Lens
4Flash button 10 Video light/Self-timer light/AF assist light
5On/Off button 11 DC-In (5V)
6Auto/SCN (scene) mode button 12 Microphone
4
2
8
679
12
5
11
3
1
10
www.kodak.com/go/v1233support 9
ENGLISH
Back view
1LCD 7Share button
2Speaker 8Menu button
3Review button 9Battery compartment
4Delete button 10 Slot for optional SD or MMC card
5Joystick ; OK button (press) 11 Tripod socket
6Strap post 12 USB, A/V Out, Dock connector
5
6
3
2
12
11
4
1
optional
9
10 8
7
10 www.kodak.com/go/easysharecenter
1Doing more with your camera
Storing pictures on an SD or MMC card
Your camera has internal memory. You can purchase an SD or MMC card to
conveniently store more pictures/videos (visit www.kodak.com/go/v1233accessories).
CAUTION:
A card can only be inserted one way; forcing it may cause damage.
Inserting or removing a card while it is being accessed may damage the
pictures, the card, or the camera.
optional
1Turn off the camera.
2Insert or remove the
optional card.
3Turn on the camera.
