1. About this document
1.1. Use of the Operating and Installation Instruc-
tions
The Operating and Installation Instructions are part of the pump.
Forward the Operating and Installation Instructions to any sub-
sequent owners of the pump
Customer-specific project pumps (pump models which begin with
"PJM" or "PMM") may differ from the Operating and Installation In-
structions.
In the case of project pumps, take note of any additionally
agreed specifications.
1.2. Symbols and markings
Warning
WARNING
This symbol indicates a potential danger.
It also indicates the possible consequences of fail-
ure to observe the warning. The signal word (e.g.
"Warning") indicates the level of danger
Here you will see actions for avoiding the dan-
ger and potential consequences.
Danger levels
Signal word
Meaning Consequences if not observed
DANGER warns of immedi-
ate danger
Consequences are death or se-
rious injury and/or serious prop-
erty damage.
WARNING warns of poten-
tial danger
Death or serious injury and/or
serious damage to property are
possible
CAUTION warns of a poten-
tially dangerous
situation
Minor injury or damage to prop-
erty are possible.
Tab. 1
Other information and symbols
This indicates a required activity (step).
This indicates the first step of a required activity. Additional
consecutively numbered steps follow
This symbol indicates important information
Project pumps
Diaphragm Pump NMS 030 Use
KNF Micro BA306116-306115 NMS030-EN 0221
Operating and Installation Instructions 3
2. Use
2.1. Intended use
KNF pumps in the NMS030 range are to transfer, evacuate and
compress gases.
Owner's responsibility
Only install and operate the pumps under the operating parameters
and conditions described in Chapter 4, Technical data. Only com-
pletely installed pumps may be taken into service.
Before using a medium, check whether the medium can be trans-
ferred danger-free in the specific application case.
Before using a medium, check the compatibility of the materials of
the pump head, pump housing, diaphragm and valves with the me-
dium.
The temperature of the medium must lie within the permissible
temperature range (see Chapter 4).
The transferred gas should not contain particles as these can pre-
vent the pump from working correctly. If this cannot be guaranteed,
a filter < 100 m with sufficiently large filter area must be used up-
stream of the pump.
See the type- plate or data sheet for full electrical and pneumatic
data.
2.2. Improper use
DANGER
The pumps must not be operated in an explo-
sive atmosphere.
The pumps are not suitable for transferring dusts and liquids.
Please contact your local KNF partner for special designs that
are not included in the technical specification (www.knf.com).
Operating parameters and
conditions
Requirements for
transferred medium
Diaphragm Pump NMS 030 Safety
KNF Micro BA306116-306115 NMS030-EN 0221
Operating and Installation Instructions 4
3. Safety
Observe the safety precautions in Chapters
5. Installation and connection and 6. Operation.
The pumps are built according to the generally recognized rules of
technology and in accordance with the pertinent occupational
safety and accident prevention regulations. Nevertheless, dangers
may occur during their use which may lead to injuries to the user or
others, or to damage to the pump or other property.
Only use the pumps when they are in a good technical and proper
working order, in accordance with their intended use, observing the
safety advice within the Operating and Installation Instructions, at
all times.
Make sure that only trained and instructed personnel or specially
trained personnel work on the pumps. This especially applies to
assembly, connection and servicing work.
Make sure that all personnel have read and understood the Oper-
ating and Installation Instructions, and in particular the "Safety"
chapter.
Always ensure adherence to all pertinent accident prevention and
safety regulations when working on and operating the pump.
When transferring dangerous media, observe the safety regula-
tions for handling such media.
Always ensure adherence to all information stickers on the pumps,
such as flow direction arrows and type plates, and keep stickers in
legible condition.
All replacement parts should be properly stored and disposed of in
accordance with the applicable environmental protection regula-
tions. Observe the respective national and international regula-
tions. This especially applies to parts contaminated with toxic sub-
stances.
Dispose of all packaging in an environmentally-appropriate
manner. The packaging materials are recyclable.
Dispose of end-of-life equipment in an environmentally
friendly manner. Use appropriate waste collection systems
for the disposal of end-of-life equipment. Used pumps con-
tain valuable recyclable materials.
For the purposes of the Machinery Directive 2006/42/EC, pumps
are “partly completed machinery", and are therefore to be regarded
as not ready for use. Partly completed machinery may not be com-
missioned until such time as it has been determined that the ma-
chine in which the partly completed machinery is to be assembled
conforms to the provisions of the Machinery Directive 2006/42/EC.
The essential requirements of Annex I of Directive 2006/42/EC
(general principles) are applied and observed.
General Principles No. 1
No. 1.1.2. / 1.1.3. / 1.3.1. / 1.3.3. / 1.3.4. / 1.4.1. / 1.5.8. /
1.5.9./ 1.7.4. / 1.7.4.1. / 1.7.4.3.
Personnel
Working in a
safety-conscious manner
Handling dangerous media
Notes
Environmental protection
Disposal
EU directives/standards
Diaphragm Pump NMS 030 Safety
KNF Micro BA306116-306115 NMS030-EN 0221
Operating and Installation Instructions 5
As these partly completed machinery are OEM-models the power
supplies and the equipment for disconnecting and switching-off the
partly completed machinery respectively have to be considered
when mounting as well as over-current and overload protective
gear.
In addition a protection against mechanical parts in motion, hot
parts, if existing, has to be provided when mounting.
The pumps comply with the safety requirements regarding electro-
magnetic compatibility in Directive 2014/30/EU, if the pump is pow-
ered by an industrially produced power supply which is used within
the specified limits. (Supply voltage motor current, load torque).
The pumps comply with the fundamental requirements of Directive
2011/65/EU (RoHS2).
The following harmonised standards are met::
NMS 030 K_DC NMS 030 K_DCB
DIN EN 55014-1 DIN EN 55014-1 1)
DIN EN 55014-2 DIN EN 55014-2
DIN EN 60034-1 DIN EN 61000-6-1
DIN EN 61000-6-1 DIN EN 61000-6-3
DIN EN 61000-6-2
Tab. 2 1) see chapter 5.2
All repairs to the pump(s) must be carried out by the relevant KNF
customer service team.
Only use genuine parts from KNF for servicing work.
Customer service and repairs
Diaphragm Pump NMS 030 Technical data
KNF Micro BA306116-306115 NMS030-EN 0221
Operating and Installation Instructions 6
4. Technical data
General parameters
Parameter Value
Allowed ambient temperature (°C) + 5 to + 40
Allowed medium temperature (°C) + 5 to + 40
Tab. 3
Pump Materials of gas-contacting parts
Type designation NMS030 KP….
Components Material
1)
Head plate; intermediate plate PPS
Housing PPS
Valve plate / seals EPDM
Diaphragm EPDM
Tab. 4 1) according DIN ISO 1629 and 1043.1
The pump type NMS030K_DC stands for
Motor voltage 12V 24V
Power consumption [W]
12
12
Max. I load [A]
1.00
0.50
Max. permissible current
consumption [A]
1.42
0.71
Connection [-]
Flat plug A 2.8x0.5.
Protection class [-]
IP00
IP00
Weight
1
)
[g]
348
348
Delivery rate at atm. Pressure
[l/min] 2), 3) 11
Max. operating permissible
pressure [bar g] 0.2
Max. vacuum [mbar abs] < 200
Tab.5
The pump type NMS030K_DCB (brushless) stands for
Motor voltage 12V 24V 12V-4 24V-4
Supply voltage [V] 12
24
10…28
10…28
Power consumption [W] 11
11
9.2
12
Max. I load [A] 0.91
0.46
0.80
0.50
Max. permissible current
consumption [A] 1.8
0.9
1.8
1.8
Lead size [-] AWG 24 AWG 24
Protection class [-] IP 54 IP 54
Weight
1
)
[g] 218
218
218
218
Delivery rate at atm. Pressure
[l/min] 2), 3) 10.5 9.6 4) 12 5)
Max. operating permissible
pressure [bar g] 0.2 0.2
Max vacuum [mbar abs] < 200 < 200
Tab.6
1) The weight may differ slightly from the stated value, depending on the version.
2) Depending on the application level (MASL), ambient temperature, material design
of the pump head and the connection hoses used, the flow rates may vary from the
values shown.
3) Measured with air at 20°C / at atmospheric pressure
4) At 5VDC control voltage
5) At 6VDC control voltage
Diaphragm Pump NMS 030 Technical data
KNF Micro BA306116-306115 NMS030-EN 0221
Operating and Installation Instructions 7
Motor electrical specifications DCB-4 12V / 24V
Electrical connections
Function Lead color Signal
name
Size
+ Supply voltage
Red + Vs AWG 24
- Supply voltage Black - Vs / GND AWG 24
Speed control – input
signal White Vctrl AWG 24
Frequency output –
output signal Green FG AWG 24
DC control input Vctrl
Control voltage range DC 0...7 [VDC]
Speed range 300..2800 [1/min]
Resistant to surge voltages up to 28 [VDC]
Input resistance (Vctrl < 5.3VDC) [ 62 [k]
Threshold voltage 0.11 (VDC)
Speed/voltage constants 460 (rpm/V)
Control voltage characteristic
FG frequency output
FG pulses per mech. revolution 6 [ ]
Pulse duty factor 50 [%]
Output series resistance 4 [k]
Output level "high" (Iout <0.1mA) 4… 5 [V]
Output level "low" (Iout <0.1mA) max. 0.5 [V]
Tab.7
The supply voltage is not designed for operation with pulse-width mod-
ulated voltages (PWM).
PWM signal (frequency 6-20 kHz ) can be used on the speed input
signal to control the pump
Diaphragm Pump NMS 030 Assembly and function
KNF Micro BA306116-306115 NMS030-EN 0221
Operating and Installation Instructions 8
5. Assembly and function
Only install the pump under the operating parameters and condi-
tions described in Chapter 4, Technical data.
Observe the safety precautions (see Chapter 3).
5.1. Installation
Before installation, store the pump at the installation location to
bring it up to ambient
Make sure that the installation location is dry and the pump is pro-
tected against water in the form of rain, spray, splashes and drips.
Protect the pump against dust.
Protect the pump against vibration and impact.
Generally speaking, the pump can be installed in any position.
For maximum accuracy and rapid venting install the pump, at high-
est point in the system to prevent condensate from collection in the
pump head.
WARNING
Risk of physical injury and damage to the pump due
to automatic start
If the pump overheats and the thermal switch /
electronics stops pump operation, the pumps will
restart automatically as soon as the motor has
had time to cool down.
Take steps to ensure that this cannot produce a haz-
ardous situation
5.2. Electrical connection
Only have the pump connected by an authorized specialist
Only have the pump connected when the power supply is discon-
nected.
When connecting the device to a power source, the relevant
norms, directives, regulations and technical standards must be ob-
served
Connecting the pump
Make sure that the power supply data match the data on the
motor's type plate. The current consumption can be found on
the type plate.
Connect the motor cables. For electrical data see Chapter 4.
Note the proper polarity.
For DC motors:
red motor cable: +
black motor cable: -
In the case of brushless DC motors:
incorrect polarity may damage to the electronics.
Installation location
Installation position
Contact and foreign body pro-
tection
Diaphragm Pump NMS 030 Assembly and function
KNF Micro BA306116-306115 NMS030-EN 0221
Operating and Installation Instructions 9
In order to ensure that emissions comply with the EN 55014-1
emission standard, this pump type with a brushless DC motor DCB
must be fitted with an additional circuit. The additional circuit must
be installed as closely as possible to the motor.
The additional circuit must be installed according to the following
wiring diagram and its defined components in order to achieve the
required level of attenuation.
Fig. 8: Additional circuit
5.3. Pneumatic connection
Only connect components to the pump that are designed to
handle the pneumatic data of the pump (see Chapter 4, Tech-
nical data)
Only use hoses that are suitable for the maximum operating
pressure of the pump (see Chapter 4)
Only use hoses that are chemically resistant to the media be-
ing pumped
5.3.1. Connecting the pump
Arrows on the pump head indicate the flow direction.
Remove the protective caps from the hose connections.
Connect the suction and pressure lines.
If the pump is used to build up pressure, make sure that all
transition joints between hose and pump are secure in order to
ensure that the hoses cannot come off.
Check that the hoses and transition joints (hose connect-
or/hose) are fitted correctly and securely.
Check that the system is leak-tight.
Additional circuit for
brushless DCB Motor
C1: Condenser
≥ 2200 µF / UN = 12 V
≥ 1000 µF / UN = 24 V
Connected
components
Hoses
M
C1
+
-
Diaphragm Pump NMS 030 Operation
KNF Micro BA306116-306115 NMS030-EN 0221
Operating and Installation Instructions 10
6. Operation
Operate the pumps only under the operating parameters and
conditions described in Chapter 4, Technical data
Make sure that the pumps are being used properly (see Chap-
ter 2.1).
Avoid improper use of the pumps (see Chapter 2.2)
Observe the safety precautions (see Chapter 3).
The pump is a component intended to be incorporated into an-
other machine. Before putting into service it must be estab-
lished that the machinery or systems in which the pump is in-
stalled meets the relevant regulations
CAUTION
Risk of burning
The drive heats up.
Avoid contact with the pump drive.
Avoid contact with flammable materials
Excessive pressure and the inherent dangers thereof can be
prevented by placing a bypass line with a pressure relief valve
between the pressure and suction side of the pump. Please
contact your local KNF partner for further information
(www.knf.com).
If the pump stops running, restore the system to normal atmos-
pheric pressure.
For pumps with thermal switch or electronic overload protection:
WARNING
Risk of physical injury and damage to the pump
due to automatic start
If the pump overheats and pump operation is
stopped by the thermal switch / electronics, the
pumps will restart automatically as soon as
the motor
has had time to cool down
Take steps to ensure that this cannot produce a
hazardous situation
Regularly inspect the pump for external damage or leaks.
Switching the pumps on and off
The motor speed of the pump, and thus the flow rate, is adjustable
and can also be regulated to some extent.
For more details, see Chapter 4, Technical data
Pump standstill
Inspection
Setting and regulating motor
speed
This manual suits for next models
1
Table of contents
Other KNF Water Pump manuals
Popular Water Pump manuals by other brands
Sykes AmeriPumps
Sykes AmeriPumps GP100M Operation and maintenance instructions
DUROMAX
DUROMAX XP WX Series user manual
BRINKMANN PUMPS
BRINKMANN PUMPS SBF550 operating instructions
Franklin Electric
Franklin Electric IPS Installation & operation manual
Xylem
Xylem e-1532 Series instruction manual
Milton Roy
Milton Roy PRIMEROYAL instruction manual
