KitchenAid KSCS25MTMK01 User manual

CABINET PARTS

For Model: KSCS25MTMS01, KSCS25MTMK01

(Monochromatic Stainless)(Monochromatic Stainless)

04−07 Printed In U.S.A. (mat) Part No. W10139250 Rev. A

REFRIGERATOR

CABINET PARTS

For Model: KSCS25MTMS01, KSCS25MTMK01

(Monochromatic Stainless)(Monochromatic Stainless)

W10139250

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

2318593 Use & Care Guide

2223419 Service & Wiring

Sheet

2318477 Installation

Instructions

2326392 Energy Guide

2220407 Modular Icemaker

Service Sheet

2 Front Roller Asm

2306950 Left Side

2306951 Right Side

3 2223263 Strap, Roller

4 2306949 Roller, Rear (2)

5 2223388 Clip, Retainer (4)

6 2155013 Clip, Grille

7 489478 Screw

8 2223545 Shim

9 Hinge Top, RC

2307008AP

Apollo Gray

10 3400113 Screw

11 3400243 Screw

12 2307179 Hinge Assembly,

Bottom−RC

(Includes #34)

13 Filler, Wrapper

2223893AP

Apollo Gray

14 Grille, Filter

2322234AP

Apollo Gray

15 3400108 Screw

16 Hinge, Top FC

2307007AP

Apollo Gray

17 489464 Screw

18 2304888 Drain Fitting

19 2254566 Tube, Extension

21 2223409 Cover, Unit

22 2223387 Pin, Roller (4)

23 549193 Clamp, Service

Cord

24 489084 Screw

25 2307152 Hinge Assembly,

Bottom−FC

(Includes 29 & 32)

26 Button, Water

Filter

2260503AP

Apollo Gray

27 2260526 Housing, Water

Filter

28 4396841 Water Filter

29 2307051 Door Closer, FC

30 Cap, Water

Filter

2260518AP

Apollo Gray

31 Cabinet (Not A

Serviceable Part)

32 489483 Screw

34 2307049 Door Closer, RC

35 3400858 Screw

36 2304709 Tube, Filter

Outlet

37 2319868 Tube, Filter

Inlet

REFRIGERATOR LINER PARTS

For Model: KSCS25MTMS01, KSCS25MTMK01

(Monochromatic Stainless)(Monochromatic Stainless)

W10139250

Illus. Part

No. No. DESCRIPTION

1 Liner (Not A

Serviceable Part)

2 2224121 Escutcheon, Meat

Pan Control

3 2224123 Slide, Meat

Pan Control

4 1118894 Switch, Rocker

Arm

5 2188820 Thermistor

6 2223456 Ladder, Shelf (2)

7 2301234 Housing, Door

Control

8 489084 Screw

9 2301235 Slide, Door

Control

10 2171846 Release Valve

11 2179404K Rack, Wine & Egg

12 2317105 Cover, Thermistor

13 489478 Screw

14 2304597 Gasket,

Air Baffle

15 2223403 Cover,

Air Baffle

16 2224076 Air Diffuser

Assembly

17 2220377 Air Baffle

18 2162085 Socket

19 2205813 Strap

20 2255743 Light Bulb

21 2223663 Light Lens

REFRIGERATOR SHELF PARTS

For Model: KSCS25MTMS01, KSCS25MTMK01

(Monochromatic Stainless)(Monochromatic Stainless)

W10139250

Illus. Part

No. No. DESCRIPTION

1 2224061 Shelf Assembly,

Cantilever (2)

2 2301025 Button, Humidity

3 2301026 Slide, Humidity

4 2301117 Gasket, Side (2)

5 2203027 Cover, Meat Pan

(Includes Items

13, 14, 15 & 20)

6 2301023 Snack Pan

(Includes 30 & 31)

7 Glide Assembly,

Crisper Pan

2301548 Right Side

2301549 Left Side

8 2301001 Window,

Crisper Pan

9 2301567 Cover, Crisper

(Includes 2,

3, 4, 11, 12,

13, 14 & 19)

10 2301027 Glass, Cover

11 2301116 Gasket (Front)

12 2301115 Gasket (Rear)

13 2174478 Eyelet, Roller

14 2188212 Roller

15 489211 Screw

16 2301031 Crisper Pan

(Includes 8, 13

14, 19 & 31)

17 2223790 Meat Pan

(Includes 13,

14, 19 & 22)

18 Glide Assembly,

Snack Pan

2301550 Right Side

2301551 Left Side

19 489261 Screw

20 2223487 Deflector

21 Support Assembly

2301569 Right Side

2301570 Left Side

22 2203031 Handle

25 2196485 Stud Assembly

26 2301566 Shelf, Snack Pan

27 3400894 Screw

28 2196483 Stud Assembly

29 8281158 Screw

30 2301006 Window, Snack Pan

31 Cap, Snack Pan

2301016 Right Side

2301017 Left Side

FREEZER LINER PARTS

For Model: KSCS25MTMS01, KSCS25MTMK01

(Monochromatic Stainless)(Monochromatic Stainless)

W10139250

FREEZER LINER PARTS

For Model: KSCS25MTMS01, KSCS25MTMK01

(Monochromatic Stainless)(Monochromatic Stainless)

W10139250

Illus. Part

No. No. DESCRIPTION

1 Liner (Not A

Seviceable Part)

2 2223777 Spacer, Slide (2)

3 941839 Hole Plug

4 2223782 Basket, Front

5 2254611 Basket, Deep (2)

6 2223500 Shelf Assembly,

Cantilever (2)

7 2224053 Front, Basket

8 Shelf Track

2223787 Right Side

2223788 Left Side

9 2254615 Shelf, Fixed

10 2254612 Basket, Lower

11 3400893 Screw

12 842534 Clip, Air Duct

13 Glide Assembly,

Basket (2)

2301544 Right Side

2301545 Left Side

14 2259487 Cover, Emitter

15 8534064 Screw

16 2198635 Spring

17 2198634 Pin

18 2198665 Tube, P.C. Board

19 2220398 P.C. Board

Emitter

20 2224125 Cover, Ice Maker

21 Slide, Ice Maker

Mounting

2212321 Right Side

2306900 Left Side

22 489478 Screw

23 489214 Screw

24 2162085 Light Socket

25 2255743 Light Bulb

26 8281185 Screw

27 2198633 Flipper

28 2255561 Cover, Receiver

29 2301340 Slide, Ice Maker

Shut Off

30 2255114 P.C. Board,

Receiver

31 2198643 Lens

32 2198589 Light Shield

33 2212340 Light Lens

34 2198641 Bracket, Ice Maker

Cover

35 2155597 Socket, Light

36 3400893 Screw

37 Ladder

2223414 Left Side

2223415 Right Side

38 2303378 Shield, Wiring

REFRIGERATOR DOOR PARTS

For Model: KSCS25MTMS01, KSCS25MTMK01

(Monochromatic Stainless)(Monochromatic Stainless)

W10139250

REFRIGERATOR DOOR PARTS

For Model: KSCS25MTMS01, KSCS25MTMK01

(Monochromatic Stainless)(Monochromatic Stainless)

W10139250

Illus. Part

No. No. DESCRIPTION

1 Refrigerator Door

(Includes #7)

2307198SA

Monochromatic

Stainless

2 2203087K Trim, Shelf

3 2255421 Dairy Door

4 2223883 Caddy, Can

6 2219698 Stud, Handle

7 Door Gasket,

Magnetic

2223326 Mist Beige

8 Handle

2319727S Stainless Steel

W10010140

Set Screw

10 2223879 Dairy Compartment

11 488208 Screw

12 2307048 Thimble Cam, RC

13 2308091 Thimble, Top

14 489420 Screw

15 Bracket, Door Stop

2306940 Chrome

16 2223860 Door Bin (3)

17 3400012 Screw

18 2224173 Door Bin,

Shallow

W10046610

Nameplate

20 2156006K Plug, Trim

FREEZER DOOR PARTS

For Model: KSCS25MTMS01, KSCS25MTMK01

(Monochromatic Stainless)(Monochromatic Stainless)

W10139250

FREEZER DOOR PARTS

For Model: KSCS25MTMS01, KSCS25MTMK01

(Monochromatic Stainless)(Monochromatic Stainless)

W10139250

Illus. Part

No. No. DESCRIPTION

1 Freezer Door

(Includes #8

And Dispenser

Front Parts)

W10135898

Monochromatic

Stainless

2 Handle

2319727S Stainless Steel

3 2219698 Stud, Handle

4 488208 Screw

5 3400012 Screw

W10010140

Set Screw

7 2223559K Shelf Bin (3)

8 Door Gasket,

Magnetic

2326340 Apollo Grey

10 2219982 Trim, Door Shelf

11 2308091 Thimble, Top

12 2223317 Upper Bin

13 2317256 Lower Bin

14 2307050 Thimble Cam, FC

16 489420 Screw

17 Bracket, Door Stop

2306940 Chrome

18 2317272 Latch, Bin

19 2198608 Spring, Latch

W10131326

Cover, Crusher

22 3400065 Screw (2)

W10135750

Ice Container

(Complete)

This manual suits for next models
