KitchenAid KBRS19KT User guide

Bottom Mount Refrigerator

PRODUCT MODEL NUMBERS OVERALL DIMENSIONS

LOCATION REQUIREMENTS

KBLS19KT

KBLS20ET

KBLS22ET

KBLS22KT

KBRS19KT

KBRS20ET

KBRS22ET

KBRS22KT

Electrical: A 115 Volt, 60 Hz., AC only 15 or 20

amp fused, grounded electrical supply is required.

It is recommended that a separate circuit serving

only your refrigerator be provided. Use an outlet

that cannot be turned off by a switch. Do not use

an extension cord.

Water: Connect the ice maker to a cold water line

with water pressure between 35 and 100 psi

(241-689 kPa).

If a reverse osmosis water filtration system is

connected to your cold water supply, the water

pressure to the system needs to be a minimum of

approximately 40 to 60 psi (276-414 kPa).

IMPORTANT: The pressure of the water coming

out of a reverse osmosis system going to the

water inlet valve of the refrigerator needs to be

between 35 and 100 psi (241-689 kPa).

Because Whirlpool Corporation policy includes a continuous commitment to improve

our products, we reserve the right to change materials and specifications without notice.

Dimensions are for planning purposes only. For complete details, see Installation

Instructions packed with product. Specifications subject to change without notice.

Ref. 12828153

07-17-07

2¹⁄₈" (5.4 cm)

¹⁄₂" (1.25 cm)

Depth Cab. Width Cab. Height Overall Height

Model # "A" "B" "C" "D"

KBLS19KT 30 7/8" 29 5/8" 65 1/2" 66 3/4"

KBLS20ET 26 7/8" 35 5/8" 68 1/2" 69 3/4"

KBLS22ET 30 7/8" 32 5/8" 68 1/2" 69 3/4"

KBLS22KT 30 7/8" 32 5/8" 68 1/2" 69 3/4"

KBRS19KT 30 7/8" 29 5/8" 65 1/2" 66 3/4"

KBRS20ET 26 7/8" 35 5/8" 68 1/2" 69 3/4"

KBRS22ET 30 7/8" 32 5/8" 68 1/2" 69 3/4"

KBRS22KT 30 7/8" 32 5/8" 68 1/2" 69 3/4"

To ensure proper ventilation for your refrigerator, allow for 1⁄2" (1.25 cm) space on

each side, at the top and behind the refrigerator. When installing your refrigerator

next to a fixed wall, leave 2 1/8" (5.4 cm) minimum on the hinge side to allow for

the door to swing open. If your refrigerator has an ice maker, allow extra space at

the back for the water line connections.

NOTE: Do not install the refrigerator near an oven, radiator, or other heat source, nor

in a location where the temperature will fall below 55°F (13°C).

overall

top of

cabinet

not incl.

handle
