PRODUCT MODEL NUMBERS OVERALL DIMENSIONS

LOCATION REQUIREMENTS

KBFL25EV

KBFS25EV

Electrical: A 115 Volt, 60 Hz., AC only 15- or 20-

amp fused, grounded electrical supply is required.

It is recommended that a separate circuit serving

only your refrigerator be provided. Use an outlet

that cannot be turned off by a switch. Do not use

an extension cord.

Water: Connect the ice maker to a cold water

supply with water pressure between 35 and

120 psi (241 and 827 kPa).

If a reverse osmosis water filtration system is

connected to your cold water supply, the water

pressure to the system needs to be a minimum of

approximately 40 to 60 psi (276 to 414 kPa).

IMPORTANT: The pressure of the water coming out

of a reverse osmosis system going to the water

inlet valve of the refrigerator needs to be between

35 and 120 psi (241 and 827 kPa).

Because Whirlpool Corporation policy includes a continuous commitment to improve

our products, we reserve the right to change materials and specifications without notice.

Dimensions are for planning purposes only. For complete details, see Installation

Instructions packed with product. Specifications subject to change without notice.

Ref. W10187309

06-17-08

2-1/2" (6.3 cm)

1/2" (1.25 cm)

4

1

D

overall

C

top of

cabinet

B

includes

handles

A

Depth with Handles Cab. Width Cab. Height Overall Height

Model # "A" "B" "C" "D

To ensure proper ventilation for your refrigerator, allow for 1⁄2" (1.25 cm) space at

the top and behind the refrigerator. If your refrigerator has an ice maker, allow extra

space at the back for the water connections. When installing your refrigerator next

to a fixed wall, leave 2 1/2" (6.3 cm) minimum on each side (some models require

more) to allow for the door to swing open.

NOTE: It is recommended that you do not install the refrigerator near an oven,

radiator, or other heat source. Do not install the refrigerator in a location where the

temperature will fall below 55°F (13°C).

Bottom Mount Refrigirator

KBFL25EV 34-1/8" 35-5/8" 68-1/2" 69-7/8"

KBFS25EV 34-1/8" 35-5/8" 68-1/2" 69-7/8"
