KitchenAid KM25G0XWH5 User manual

c2006 KITCHENAID

4−06 Litho in U.S.A. (ebk) Part No. 8212279

5 QT. STAND MIXER

COMMERCIAL BOWL LIFT

MODELS:

KM25G0XWH5 (White)

CASE, GEARING AND PLANETARY UNIT

For Model: KM25G0X_ _5

8212279

CASE, GEARING AND PLANETARY UNIT

For Model: KM25G0X_ _5

8212279

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 9703311 Gearcase Motor

Housing

2 9707507 Motor (10 Tooth)

3 242765−2 Cap, Attachemnt

Hub

4 9709194 Thumb Screw

5 9707795 Band, Trim

6 9706813 Power Cord

7 9709125 Transmission

Housing

8 9706648 Control Assembly

9 9703312 Sensor, Hall

Effect

10 9706090 Washer

11 9703434 Washer, Fiber

12 9707627 Gear, Pinion

13 9703438 Retaining Clip

14 9708191 Agitator Shaft

Assembly

15 9708172 Planetary Assembly

16 9704677 Pin, Groove

17 9709231 Worm Gear

18 9707223 Retaining Pin

19 9706529 Gear, Worm

Follower

20 9703338 Gear, Attachment

Hub Bevel

21 9703337 Gear, Bevel

22 3400617 Screw, 6−32 x 1/4

23 3400814 Screw, 8−32 x 5/8

24 9707793 Lower Gear Case

25 9703680 Retaining Clip

26 67500−55 "O" Ring

27 3400200 Screw (3)

1/4 − 20 x 3/4

28 Bearing

9703560 Front

9703570 Rear

29 9703445 Thrust Bearing

30 9706036 Lead, Motor to

Control

31 9706247 Seal, Motor

Shaft

32 9709511 Gasket,

Transmission

33 9703339 Gear, Internal

34 8533910 Washer

35 9706141 Ring, Attachment

Hub

36 9706814 Screen, Vent

37 9706816 Guard

BASE AND PEDESTAL UNIT

For Model: KM25G0X_ _5

8212279

Illus. Part

No. No. DESCRIPTION

1 Literature Parts

9707796 Use & Care Guide

8212279 Repair Parts List

2 9708649 Foot, Rubber (5)

3 9703673 Column Assembly

4 9707633 Bowl Support

(Includes Item 18)

5 9703474 Latch, Bowl Spring

6 9706885 Arm, Bowl Lift

7 9706787 Rod, Bowl Lift

8 9703690 Base And Foot

Assembly

9 9703439 Washer

10 9237 Spring

11 4159092 Nut

12 9706788 Handle, Bowl Lift

13 3400863 Screw

14 9707681 Bowl (5 Qt)

15 4176045 Beater, Flat

16 9708196 Dough Hook

17 9704310 Wire Whip

18 4162028 Pin, Bowl Locating

20 9703426 Cam, Adjusting

21 3400200 Screw,

1/4−20 x 3/4

22 3400018 Screw,

10−24 x 1/2

23 9703307 Clip

ACCESSORY PARTS

For Model: KM25G0X_ _5

8212279

Illus. Part

No. No. DESCRIPTION

Following Parts Not Illustrated

OPTIONAL ATTACHMENTS, ACCESSORIES

AND SERVICE ITEMS

4164778 Mixer Attachment

Pak (Includes Food

Grinder (FG−A),

Food Strainer

(FVSP), And

Vegetable Slicer,

(RVS−A)

(FPP−A)

4164749 Food Grinder

(FG−A)

8211924 Grain Mill

(KGMA)

4164768 Pasta Maker And

Food Grinder

(Includes SNP

Pasta Maker

Plates)

(SN/FG−A)

4164775 Fruit/Vegetable

Strainer Parts (Use

With FG−A Model

Only) (FVSP)

4164750 Rotor Slicer/Shredder

(With 4 Standard

Cones) Fine Shredder,

Coarse Shredder,

Thick Slicer, And

Thin Slicer (RVS−A)

4164824 Pasta Maker Plates

(SNP−A)

4164774 Fruit/Vegetable

Strainer And Food

Grinder (FVS/FG−A)

4162838 Food Tray (FT)

4164748 Juicer (JE)

4164747 Can Opener (CO)

4164803 Sausage Stuffer

Kit (SSA)

4160588 Grease, Planetary

9707963 Ice Cream Maker

(KICA0WH0)
