KitchenAid KDSS907SSS00 User manual
COOKTOP PARTS
1
For Models: KDSS907SSS00
(S.Steel)
7−06 Litho in U.S.A. (cre) Part No. 8186744
30" Slide−In
Dual Fuel
CONVECTION
COOKTOP PARTS
28186744
Illus. Part
No. No. DESCRIPTION
For Models: KDSS907SSS00
(S.Steel)
1 Literaturre Parts
W10075750
Installation
Instructiions
9763459 Use & Care Guide
9762788 Tech Sheet
9757680 Anti−Tip Instruct.
3191638 Safe Cooking Tips
9759133 Safe Cooking Tips
9763467 Guide Easy Set
2
W10110471
Burner Box
3 9761784 Bracket, Mounting
4
W10106360
Cooktop
5 3196537 Screw
7 3400843 Screw
8
W10108030
Bracket, Spark
Module
9 9763445 Bracket, Burner
10 9756821 Support, Wiring
11 8522426 Module, Spark
12
9761555CB
Grate, Burner
13
9761556CB
Grate, Brnr (TCB)
16 9759944 Thermostat (60c)
18
9761557CB
Grate,Insert (TCB)
19 Cap, Burner
9761563CB
12.5K (RR)
8284669 6K (RF, LR)
20 4449809 Screw
21 3196160 Screw
22 Orifice Holder
W10110375
Small (2)
W10110376
Large
23 9761755 Cover, Cktp Rear
24 9763436 Cover, Top Rear
25 Head, Burner
8286182 Large
8286181 Small (2)
26
W10109920
Gasket (Tape)
OVEN PARTS
3
For Models: KDSS907SSS00
(S.Steel)
8186744
OVEN PARTS
4
For Models: KDSS907SSS00
(S.Steel)
8186744
Illus. Part
No. No. DESCRIPTION
1
W10109560
Trim, Side
(Right Hand)
W10109510
(Left Hand)
3 Hinge Receiver
4455605 Left Hand
4455606 Right Hand
4 9760749 Bumper, Door
6 3400832 Screw
7 8303099 Top Chassis
8 4451478 Support,Insulation
9 4452158 Tube, Vent
10
W10067870
Lens, Light
11
W10009930
Oven Light Assy
12 4452166 Bulb, Light
14 9760756 Frame, Front
15
W10074200
Gasket, Door
17 4452152 Bracket, Mounting
18 9757685 Guide, Side Panel
19 9757461 Bracket,Side Panel
20
9760723PB
Oven, Side Panel
21 9757811 Brace, Side Panel
22 9760888 Latch, Motorized
23 9757807 Thermostat SPST
(230)
24 9759890 Clip, Side Panel
25 4455641 Side, Chassis
(R.H. & L.H.)
26 9759761 Back, Chassis
27 Liner, Oven
(Not serviceable)
28 9759945 Standoff, Rear
29 4455636 Sensor
30 9756454 Bracket, GOC
32
W10083460
Slide, GOC
33 9761801 Central, Appliance
34 3196537 Screw
35 9763491 Brkt, Regulator
36 9759091 Regulator,Pressure
37 9759242 Thermostat (TOD)
(Temp.) SPST 130C
43 9759713 Base, Chassis
49 4448933 Retainer, Gasket
50 9758583 Cover, Back
51 4449809 Screw
54
9756481SS
Vent, Bottom Upper
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
9756817 Insulation, Wrap
9756470 Insulation, Back
DOOR AND DRAWER PARTS
5
For Models: KDSS907SSS00
(S.Steel)
8186744
DOOR AND DRAWER PARTS
6
For Models: KDSS907SSS00
(S.Steel)
8186744
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 9758676 Support, Element
2 8054056 Element, Warming
3 8274149 Sensor
4 9762919 Cover, Access
5
9762766SS
Glass, Door Front
6 9763456 Panel, Drawer
7 4449809 Screw
8
8303774SS
Handle, Door
9 9759230 Bracket, Central
10 Hinge, Door
9760579 Orange RH
9760580 Orange LH
11 9761935 Foot, Rear
12 9759229 Bracket, Side
13
9763444SS
Nameplate
14 3400832 Nut
15 9757706 Glass, Inner
16 4457114 Shield, Heat Btm
17 9759225 Glass, Inner (2)
18 4451722 Insulation, Door
19 9759413 Liner, Door
20 9757805 Drawer Assy
21 3196037 Foot, Front
22
W10045140
Cover, Terminal
23 4457132 Retainer, Glass
24
9761747SS
Front, Drawer
25 Bracket, Handle
9763497 R.Hand
9763496 L.Hand
26
9761573SS
Handle, Drawer
27 Side, Base
9759953 R.Side
9759954 L.Side
28 4449743 Screw
29 8301084 Shield, Top Heat
(Addition)(2)
30 8533988 Screw
31 3196537 Screw
32 Slide−Drawer
4453718 L.Hand
4453719 R.Hand
33 4457103 Shield, Heat Top
34 3196160 Screw
TOP VENTING PARTS
7
For Models: KDSS907SSS00
(S.Steel)
8186744
Illus. Part
No. No. DESCRIPTION
1 9759320 Blower
2 4451758 Block, Foam
5 4449868 Block, Terminal
6 3196538 Screw
7 9757829 Bracket, Transfrmr
8 9760212 Transformer
9 3196537 Screw
11 4449809 Screw
12 9757778 Vent, Exhaust
14 4455177 Elbow,Vent−Bottom
15 4455178 Elbow,Vent−Top
16 9759938 Bracket, Term.Box
17 9759884 Insulation
18 9757404 Box, Terminal
19 9759721 Insulatr,Term.Box
20 9761958 Block, Terminal
21 3400080 Screw
22 9757405 Cover, Term. Box
23 3196160 Screw
INTERNAL OVEN PARTS
8
For Models: KDSS907SSS00
(S.Steel)
8186744
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 4451583 Motor, Convection
3 4457277 Grill, Broiler
4 4457276 Pan, Broiler
6 4448717 Rack, Oven
7 9760774 Element, Broil
9 9760769 Element, Convect
10 9756690 Cover, Fan
11 9755542 Probe, Meat
12 3181534 Rack, Roasting
13 4455037 Tray, Bake
Hidden
14 9760768 Element, Bake
15 4452226 Blade, fan
16 4452227 Nut
17 9755543 Jack, Meat Probe
18 9755547 Lock Washer
19 9755546 Hex Nut
21 4449154 Screw
22 4450039 Cover, Bake Tray
COOKTOP BURNER PARTS
9
For Models: KDSS907SSS00
(S.Steel)
8186744
Illus. Part
No. No. DESCRIPTION
2 9761069 Tubing, Burner(RF)
3 9761070 Tubing, Burner(RR)
5 9761068 Tubing, Burner(LR)
7 4456816 Valve, Burner
Small (2)
8 4456817 Valve, Burner
Large
9 9756824 Spark Switch &
Harness Assembly
10 9761752 Tube, Manifold
11 Manifold
9761641 TCB
9761642 Cooktop
12 3196537 Screw
14 8523704 Bolt, Valve (4)
18 9761751 Tubing
DF to Regulator
TRIPLE CROWN BURNER
10
For Models: KDSS907SSS00
(S.Steel)
8186744
Illus. Part
No. No. DESCRIPTION
1 9761639 Burner Assy.,
Triple Crown Brnr
2 8285250 Plate, Closure
3 8285255 Internal Head,
Triple Crown Brnr
4 8285256 External Head,
Triple Crown Brnr
5 8285258 Cap, Burner Ext.
6
9758829CB
Cap, Burner Int.
7 3400702 Screw
8 3400843 Screw
9 9760519 Valve, T.C.B.
10 Tube, T.C.B. Gas
9761072 Outer
9761071 Inner
