KitchenAid KDRP407HSS0 User manual
OVEN PARTS
1
For Model: KDRP407HSS0
(Stainless Steel)
12−99 Litho in U.S.A. (RS) Part No. 8177425
30" KITCHENAID
FREE STANDING RANGE
DUAL FUEL
OVEN PARTS
2
For Model: KDRP407HSS0
(Stainless Steel)
8177425
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 Literature Parts
LIT4452762
Installation
Instructions
LIT4452761
Use & Care Guide
LIT4453057
Tech Sheet
LIT4449066
Cookbook Conv.
LIT4453152
Conversion
Instructions
LIT3191638
Safer Cooking Tips
2 4449809 Screw, 8−18 x 3/8
3 4452224 Solenoid
4 4452312 Switch, Micro
5 4451426 Switch, Micro
6 4451537 Spring, Latch
7 4453114 Top, Chassis
8 4448520 Bumper, Door
9 4452158 Tube, Vent
10 4452163 Lens, Light
11 4448972 Oven Light Assy
12 4452164 Bulb, Light
13 Hinge Receiver
4454664 Left Hand
4454665 Right Hand
14 4451740 Frame, Front
15 4449372 Gasket, Door
19 4451478 Support, Insulation
24 4451896 Latch Assy
25 Side, Chassis
4452418 Right Hand
4452419 Left Hand
26 4452234 Back, Chassis
27 Liner, Oven
(Not serviceable)
29 4451665 Sensor
30 4449154 Screw, 8−32 x .440
31 4449040 Screw, 8−18 x 3/8
32 3196176 Screw, 8−18 x 1/2
37 4452223 Thermostat (TOD)
(Temp.) SPST
43 4452435 Base, Chassis
49 4448933 Retainer, Gasket
50 4451747 Cover, Back
56 4448982 Button, Plug
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449316 Insulation, Wrap
4450365 Insulation, Back
4452337 Insulation,
Bottom Vent
OVEN DOOR PARTS
3
For Model: KDRP407HSS0
(Stainless Steel)
8177425
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 4451719 Door Liner
2 4452343 Hinge, Door
3 4449259 Glass, Inner
4 4451722 Insulation, Door
5 4451671 Retainer, Glass
7 4449263 Glass, Inner
8 4449743 Screw, 8−32 x 3/8
9 4451668 Retainer, Glass
12 4452316 Assy, Door Glass
13 4452088 Door Handle
14 Bracket, Handle
4452487 Right Hand
4452488 Left Hand
19 4450362 Shield, Heat
20 4449809 Screw, 8−18 x 3/8
21 4452326 Seal, Door Top
23 4451432 Retainer, Clip
24 3196184 Screw, 8−32 x .548
INTERNAL OVEN PARTS
4
For Model: KDRP407HSS0
(Stainless Steel)
8177425
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
2 4452154 Element, Broil
4449154 Screw
3 3147563 Grill, Broiler
4 3147845 Pan, Broiler
5 3181534 Rack, Roasting
6 4452807 Rack, Oven
7 4452155 Element, Hidden
Bake
9 4451583 Motor, Convection
10 4452226 Blade, Fan
11 4448418 Cover, Fan
12 4452227 Nut
13 4452157 Element,
Convection
14 4448723 Tray, Hidden
Bake
15 4450039 Cover, Access
16 4449154 Screw, 8−32 x .440
17 4449809 Screw, 8−18 x 3/8
CONTROL PANEL PARTS
5
For Model: KDRP407HSS0
(Stainless Steel)
8177425
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 4455216 Panel, Control
2 4453000 Bracket, Display
3 4453120 Bracket, Display
Mounting
4 3196537 Screw, 8−18 x 3/8
5 4452443 Control, Zodiac
6 4449899 Screw, 6−19 x 1
7 4453199 Escutcheon,
Control Panel
8 4452999 Module, Display
9 2004333 Palnut
10 2005292 Nameplate
11 4455211 Face, Control
Panel
12 4455192 Bezel, Knob
13 4454970 Knob, Control
14 4455115 Knob, Temp/Time
15 4455141 Knob, Selector
16 4452998 Button, Cancel
17 4452997 Button, Enter
TOP VENTING PARTS
6
For Model: KDRP407HSS0
(Stainless Steel)
8177425
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 4451759 Vent, Exhaust
2 4451438 Elbow, Vent−Top
3 4452811 Blower 60MM
4 4451752 Elbow, Vent−Bottom
5 6610122 Transformer, Light
6 4451891 Transformer,
Control
7 4449809 Screw, 8−18 x 3/8
8 4455352 Bracket, Blower
11 4449868 Block, Terminal
14 4452442 Side, Control Top
21 4451758 Seal, Foam
22 4452489 Deflector, Vent
Box
23 4452441 Bracket, Control
Mounting
24 4452444 Control, Zodiac
25 4451985 Suppressor
7
For Model: KDRP407HSS0
(Stainless Steel)
8177425
COOKTOP PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 4455032 Cooktop
2 9754181 Burner Head
3 3368921 Screw, 7−18 x 3/4
4 4455243 Cap, Burner
5 9754188 Orifice Holder
6 3177991 Screw, 8−18 x 1/4
7 4454963 Grate, Burner
8 4454964 Grate, Filler
9 4454961 Trim, Island
10 4455031 Support,
Backsplash
11 4454959 Trim, Backsplash
12 3400837 Screw, 8−18 x 3/8
13 3192525 Orifice, Burner
14 9754215 Ignitor, Burner
15 4455109 Plate, Simmer
8
For Model: KDRP407HSS0
(Stainless Steel)
8177425
1 4455078 Tubing, Gas
Burner −RF
2 4455079 Tubing, Gas
Burner −RR
3 4455148 Tubing, Gas
Burner −LF
4 4455149 Tubing, Gas
Burner −LR
5 4452814 Manifold Assembly
Left Side
6 4452815 Tube, Manifold
7 4452816 Manifold Assembly
Right Side
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
8 3192157 Valve, Burner
9 307630 Bolt, Gas Valve
10 4453032 Burner Switch &
Harness Assembly
3191387 Seal, Switch
11 4453033 Pressure Regulator
12 4454951 Box, Burner
15 Side, Burner Box
4454953 Right Side
4454954 Left Side
16 4455027 Support, Rear
17 4454975 Support, Cooktop
18 3192811 Bracket, Burner
19 3177991 Screw, 8−18 x 1/4
20 4454974 Rail, Support
RH & LH
21 4452818 Tube, Manifold
22 4453119 Cover, Manifold
23 Adapter
4453116 1/2" Female
4453115 1/2" Male
24 4453036 Cover, Burner
Box
25 8053421 Module, Spark
BURNER BOX AND MANIFOLD PARTS
9
For Model: KDRP407HSS0
(Stainless Steel)
8177425
CHASSIS PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 4452802 Vent, Bottom
Lower
2 4449809 Screw, 8−18 x 3/8
3 4452798 Backer, Trim Lower
4 3400837 Screw, 8−18 x 3/8
5 4452800 Deflector, Center
6 4452420 Vent, Bottom Upper
7 4452425 Vent, Center
8 3196537 Screw, 8−18 x 3/8
9 4452432 Bracket, Mounting
Regulator
10 4452430 Foot Assembly
11 489462 Screw,
5/16−12 x 3/4
12 4452809 Gusset
13 4452416 Support, Channel
14 4452433 Brace, Rear
15 4452804 Trim, Front
Right & Left Side
16 3196537 Screw, 8−18 x 3/8
17 Side Chassis
4452418 Right Side
4452419 Left Side
MISCELLANEOUS PARTS
10
For Model: KDRP407HSS0
(Stainless Steel)
8177425
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
4453192 Seal, Ribbon
Cable
4453191 Seal, Access
Panel
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242829 Wire (12 Ga.
150 c Red)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242826 Wire (14 Ga.
150 c White)
242827 Wire (14 Ga.
150 c Yellow)
242832 Wire (14 Ga.
200 c Yellow)
WIRING HARNESS PARTS
4448444 Grommet, Rail
4453001 Harness, Wire
(Main)
4453002 Harness, Wire
(Spark Module)
4453003 Harness, Wire
(Ignitor 39")
3192230 Harness, Wire
(Ignitor 28")
3191506 Bushing, Conduit
1129449 Bushing
4450952 Conduit
4449809 Screw
112432 Nut
4450800 Screw, Ground
4454835 Tie, Cable
4452222 Spacer, Harness
Miscellaneous
814381 Pin Hinge Kit
4455353 Spud Kit
