KitchenAid 5KHBC312C User manual

5KHBC312C

W10910604B.indb 1 1/21/2019 2:33:44 PM

TABLE OF CONTENTS

PARTS AND FEATURES ��3

Commercial Hand Blender parts ��3

Optional accessories��4

Commercial Hand Blender features ��4

COMMERCIAL HAND BLENDER SAFETY ��5

Important Safeguards��5

Electrical Requirements ��7

OPERATING THE COMMERCIAL HAND BLENDER ��8

Before ﬁrst use��8

Intended use��8

Using the twist lock blending arm��9

Tips for great results��11

CARE AND CLEANING ��12

TROUBLESHOOTING��13

TECHNICAL SPECIFICATIONS��14

W10910604B.indb 2 1/21/2019 2:33:44 PM

ENGLISH

PARTS AND FEATURES | 3

PARTS AND FEATURES

COMMERCIAL HAND BLENDER PARTS

Power cord

Stainless steel

blending arm

Motor body

Power button

Speed control buttons

Lock switch

Stainless steel wall mount

5KHBC312 (305mm [12”])

MODEL

W10910604B.indb 3 1/21/2019 2:33:44 PM

4| PARTS AND FEATURES

PARTS AND FEATURES

OPTIONAL ACCESSORIES

Accessory Model # Style Length/ Max

Blend Volume

Whisk

attachment

KHBC10WER 254 mm (10”)

Multipurpose

S-blade

KHBC08MSS

203 mm (8”)

11�4 L (3 gal)

KHBC10MSS

254 mm (10”)

22�7 L (6 gal)

KHBC12MSS

305 mm (12”)

38�0 L (9 gal)

COMMERCIAL HAND BLENDER FEATURES

Speed control

Provides easy adjustment of speed�

Power button

Located on the front of the motor body

and activated by pressing and holding

during blending� To stop blending,

simply release the power button�

Lock switch

Press to unlock in order for Power button

to function; press to lock when

Commercial Hand Blender is not in use�

Motor body

Designed for a comfortable, non-slip

grip�

Powerful DC motor (not shown)

Provides powerful blending action and is

designed for quiet, long-life operation�

Twist lock stainless steel blending arm

Simply seats onto the motor body and

is rotated to lock together� The sharp

stainless steel blade is covered to help

prevent splashing while blending�

Power cord

Long enough to take the Commercial

Hand Blender to the cooktop or work

area and rounded with no grooves for

easy cleanup�

W10910604B.indb 4 1/21/2019 2:33:46 PM

ENGLISH

COMMERCIAL HAND BLENDER SAFETY | 5

COMMERCIAL HAND BLENDER SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety

precautions should always be followed, including the

following:

1. Read all instructions. Misuse of appliance may result

in personal injury.

2. To protect against risk of electrical shock do not put

motor body, cord, or electrical plug of this Commercial

Hand Blender in water or other liquid.

3. Children should be supervised to insure they do not

play with the appliance. The appliance is not to be

used by children. The appliance and cord should be

out of reach of children. Children shall not clean or

perform user maintenance on the appliance without

supervision.

4. This appliance is not intended for use by persons

(including children) with reduced physical sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instructions concerning use of the appliance in a

safe way and understand the hazards involved.

W10910604B.indb 5 1/21/2019 2:33:46 PM

6| COMMERCIAL HAND BLENDER SAFETY

5. Unplug from outlet when not in use, before putting on

or taking off parts, and before cleaning.

6. Avoid contact with moving parts.

7. Do not operate any appliance with a damaged cord or

plug or after the appliance malfunctions, or is dropped

or damaged in any manner. Return appliance to the

nearest Authorised Service Centre for examination,

repair or electrical or mechanical adjustment.

8. The use of attachments not recommended or sold by

the manufacturer may cause re, electric shock, or

injury.

9. Do not use outdoors.

10. Do not let cord hang over edge of table or counter.

11. Do not let cord contact hot surfaces, including the

stove.

12. Never leave the appliance unattended while it is in

operation.

13. When mixing liquids, especially hot liquids, use a tall

container or make small quantities at a time to reduce

spillage and possibility of injury.

14. Keep hands, hair, clothing, and utensils away from

beaters during operation to prevent the possibility

of severe injury to persons and/or damage to the

Commercial Hand Blender.

15. Blades are sharp. Care should be taken when handling

the sharp cutting blades, emptying the bowl, and

during cleaning.

16. Always disconnect the blender from the supply if it is

left unattended and before assembling, disassembling

or cleaning.

17. Turn the appliance OFF, then unplug from the outlet

when not in use, before assembling or disassembling

parts and before cleaning. To unplug, grasp the plug

and pull from the outlet. Never pull from the power

cord.

18. Do not use appliance for other than intended use.

19. Do not operate Commercial Hand Blender when not in

contact with ingredients being blended.

COMMERCIAL HAND BLENDER SAFETY

W10910604B.indb 6 1/21/2019 2:33:46 PM

ENGLISH

COMMERCIAL HAND BLENDER SAFETY | 7

COMMERCIAL HAND BLENDER SAFETY

ELECTRICAL REQUIREMENTS

Electrical Shock Hazard

Plug into an earthed outlet.

Do not remove earth prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these

instructions can result in death,

fire, or electrical shock.

NOTE: If the power cord is damaged, it

must be replaced by the manufacturer or

its service agent in order to avoid a hazard�

Do not use an extension cord� If the power

supply cord is too short, have a qualified

electrician or service technician install an

outlet near the appliance�

Volts: 220 V

Hertz: 50 Hz

20. Remove attachments from Commercial Hand Blender

before washing.

21. This product is designed for commercial use only.

22. Refer to the “Care and Cleaning” section for

instructions on cleaning the surfaces in contact with

food.

SAVE THESE INSTRUCTIONS

W10910604B.indb 7 1/21/2019 2:33:47 PM

8| OPERATING THE COMMERCIAL HAND BLENDER

OPERATING THE COMMERCIAL HAND BLENDER

BEFORE FIRST USE

Before using the using the KitchenAid

Commercial Hand Blender for the ﬁrst time,

wipe the motor body with a clean, damp

cloth to remove any dirt or dust�

IMPORTANT: Do not immerse the motor

body in water�

Wash all the attachments and accessories

by hand or in the dishwasher� See Care

and Cleaning section of this manual for

instructions� Mild dish soap may be used,

but do not use abrasive cleansers� Dry

thoroughly with a soft cloth�

IMPORTANT: Always be sure to

unplug the power cord from the wall

socket before attaching or removing

attachments�

INTENDED USE

This KitchenAid Commercial Hand Blender is intended for use in restaurants, professional

kitchens, and other foodservice locations� The Commercial Hand Blender can be used

directly in a pot or bowl to mix a variety of ingredients�

Multipurpose S-blade uses

• Soups

• Vegetable purées

• Mousses

• Compotes

• Sauces

• Bisques

• Cooked meats

• Beef gravy

• Liquify fruits

• Minces

Whisk uses

• Pancake batter

• Mayonnaise

• Egg whites

• Pudding

• Whipped cream

W10910604B.indb 8 1/21/2019 2:33:47 PM

ENGLISH

OPERATING THE COMMERCIAL HAND BLENDER | 9

OPERATING THE COMMERCIAL HAND BLENDER

USING THE TWIST LOCK BLENDING ARM

1. Insert blending arm attachment into

motor body with the alignment mark

facing the back of the unit, and twist to

lock� The alignment mark on the

attachment should line up with the

mark on the body�

2. Plug the electrical cord into an

electrical wall socket�

3. Set Commercial Hand Blender to

Low or High speed �

4. Insert the Commercial Hand Blender

into the mixture�

NOTE: The Commercial Hand Blender

should only be immersed in liquids

the length of the attachment� Do not

submerge beyond the seam of the

blending attachment� Do not immerse the

motor body into liquids or other mixtures�

To avoid damaging blades or mixing

container, do not touch the blade to the

bottom of the mixing container or use in

a mixing container that has protruding

parts that can go under the metal guard�

5. Press the Lock switch to unlock

Commercial Hand Blender�

6. Press the Power button to activate the

Commercial Hand Blender�

7. When blending is complete, release

the power button before removing

Commercial Hand Blender from the

mixture�

8. Unplug immediately after use, before

removing or changing attachments�

Electrical Shock Hazard

Plug into an earthed outlet.

Do not remove earth prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these

instructions can result in death,

fire, or electrical shock.

W10910604B.indb 9 1/21/2019 2:33:47 PM

10 | OPERATING THE COMMERCIAL HAND BLENDER

Using a light circular motion from your

wrist, draw the Commercial Hand Blender

up slightly and let it fall again into the

ingredients� Allow your wrist motion and

the weight of the Commercial Hand

Blender to do the work�

NOTE: If a piece of food becomes lodged

in the guard surrounding the blade, follow

the instructions noted below:

1. Release the power button and unplug

the Commercial Hand Blender from the

electrical outlet�

2. Once power has been disconnected,

use a spatula to remove the food

lodged in the plastic guard� Do not use

your fingers to remove lodged food�

3. After lodged food has been removed,

plug the Commercial Hand Blender

back into the electrical outlet and

resume operation�

Wrist

movement

OPERATING THE COMMERCIAL HAND BLENDER

USING THE TWIST LOCK BLENDING ARM

For best results, insert Commercial Hand

Blender with blending arm attached into

the pot or bowl containing ingredients at

an angle� Use your free hand to hold the

pot or bowl or hold the Commercial Hand

Blender near the base of the motor unit for

better stability� Remember to stop the

Commercial Hand Blender before removing

it from the pot or bowl to avoid splashing�

Rest the Commercial Hand Blender on the

bottom of the pot or bowl momentarily

then hold at an angle and slowly draw it

upwards against the side of the pot or

bowl� As the Commercial Hand Blender is

drawn up you will notice the ingredients

from the bottom of the pot or bowl being

drawn up� When the ingredients are no

longer being drawn up from the bottom,

return the Commercial Hand Blender to the

bottom of the pot or bowl and repeat the

process until the ingredients are at the

desired consistency�

Blending

Drawing up

W10910604B.indb 10 1/21/2019 2:33:48 PM

Table of contents

Languages:

Other KitchenAid Blender manuals

KitchenAid

KitchenAid 5KSB1565 Installation guide

KitchenAid

KitchenAid KHBRV00 User manual

KitchenAid

KitchenAid 5KHBV53Z User manual

KitchenAid

KitchenAid Pro Line KSB8270 User manual

KitchenAid

KitchenAid 5KSB6061 User manual

KitchenAid

KitchenAid 5KHBC210 User manual

KitchenAid

KitchenAid 5KSB40 Series User manual

KitchenAid

KitchenAid KHB1231BY User manual

KitchenAid

KitchenAid KSB560AQ - Martha Stewart - Collection... User manual

KitchenAid

KitchenAid 5KSB13 A Series User manual

KitchenAid

KitchenAid 5KSB7068 User manual

KitchenAid

KitchenAid KHB2561OB Quick guide

KitchenAid

KitchenAid K400 User manual

KitchenAid

KitchenAid KHBV53BM User manual

KitchenAid

KitchenAid KSB1332 User manual

KitchenAid

KitchenAid 9KSBC2F1 User manual

KitchenAid

KitchenAid 7KSB40 Series User manual

KitchenAid

KitchenAid 5KSB40 Series User manual

KitchenAid

KitchenAid KCB148SGR - Pro Line Commercial Bar Blender User manual

KitchenAid

KitchenAid Brasil KES25 User manual

KitchenAid

KitchenAid KSB550 Quick guide

KitchenAid

KitchenAid KSB560 Quick guide

KitchenAid

KitchenAid KHB100 Quick guide

KitchenAid

KitchenAid KSB1575 User manual

Popular Blender manuals by other brands

ROTOR

ROTOR 1125.201 instruction manual

Braun

Braun Multiquick 5 Vario series User instructions

ARENDO

ARENDO MIRA 305424 user manual

CHEF-BUILT

CHEF-BUILT CCB-3500 instruction manual

Viconte

Viconte VC-4406 instruction manual

Oster

Oster BLSTAB-CB0 user manual

HOFFEN

HOFFEN MC-3005 instruction manual

Black & Decker

Black & Decker BLC18750DM user guide

Sunbeam

Sunbeam 4182 user manual

Bialetti

Bialetti FMX35 Instructions for use

Black & Decker

Black & Decker BL8000 user manual

Duronic

Duronic BL530 manual

Exquisit

Exquisit MS 3002 wes instruction manual

Lumme

Lumme LU-KP1891A user manual

Binatone

Binatone HB-735 instruction manual

Moulinex

Moulinex LM936E10 manual

Oster

Oster VERSA Performance guide

Ninja

Ninja NN210Q instructions
