Kidde TRUSENSE SMOKE User manual

TRUSENSE SMOKE

User Guide

Multi-Criteria Optical Sensor Smoke Alarm

Model 2040-DSR

Model 2040-DSR-5B (oversized mounting bracket)

9V BATTERY

SMOKE ALARM

2040DSR 2040DSR5B

P/N: 2040-7202-01 RevB

RED = ALARM

GREEN = OPERATE

AMBER = FAULT

RED = ALARM

GREEN = OPERATE

AMBER = FAULT

SMOKE ALARM

Advanced Smoke Detection Technology

SENSE

SMOKE ALARM

Advanced Smoke Detection Technology

SENSE

Helps Reduce Cooking

Nuisance Alarms

UL 217 8

Ed.

Thank You for Purchasing this Kidde Smoke Alarm

This model is powered by a 9V battery. It also contains SMART HUSH® Control to temporarily

silence nuisance alarms.

Teach children how to respond to the alarm and that they should never play with the

unit. Your Kidde Smoke Alarm was designed for use in a residential environment. It is not

designed for use in a recreational vehicle (RV) or boat.

NOTE: Please thoroughly read this user guide and save the document for future reference

and to pass on to any subsequent owner.

The National Fire Protection Association (NFPA) and the manufacturer recommend

replacing this alarm ten years from the date code on back of alarm.

Date Code (on back): ___________________

Date of Purchase: ___________________

Where Purchased: ___________________

Date to Replace: ___________________

Product Support: 1-800-880-6788

Please write down the below information

and have this at hand when you call.

Contents

1. Smoke Alarm: What To Do When The Alarm Sounds . . . . . . . . . . . . 4

2. Other Alarm Visual And Audible Indicators . . . . . . . . . . . . . . . . 5

3. Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . 6

4. Introduction, Product Features And Specifications . . . . . . . . . . . . . 7

5. Limitations Of Smoke Alarms . . . . . . . . . . . . . . . . . . . . . 8

6. Recommended Locations For Smoke Alarms . . . . . . . . . . . . . . . 10

7. Locations To Avoid . . . . . . . . . . . . . . . . . . . . . . . . . 14

8. Installation And Activation . . . . . . . . . . . . . . . . . . . . . . 15

9. Operation And Testing . . . . . . . . . . . . . . . . . . . . . . . 16

10. Recognizing Nuisance Alarms . . . . . . . . . . . . . . . . . . . . 17

11. Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

12. Cleaning Your Alarm . . . . . . . . . . . . . . . . . . . . . . . . 19

13. Good Safety Habits . . . . . . . . . . . . . . . . . . . . . . . . 20

14. Service And Warranty . . . . . . . . . . . . . . . . . . . . . . . 23

1. Smoke Alarm: What To Do When The Alarm Sounds

The smoke alarm pattern is three long beeps, a 1.5 second pause, and three long beeps

repeating. The red LED blinks in time with the alarm pattern.

•Alert small children in the home as well as anyone else that might have difficulty

recognizing the importance of the alarm sounding or that might have difficulty leaving

the area without help.

•Leave immediately by your escape plan. Every second counts, so don’t waste time

getting dressed or picking up valuables.

•While leaving, don’t open any inside door without first feeling its surface. If hot, or if

you see smoke seeping through cracks, don’t open that door! Instead, use your alter-

nate exit. If the inside of the door is cool, place your shoulder against it, open it slightly

and be ready to slam it shut if heat and smoke rush in.

•If the escape route requires you to go through smoke, stay close to the floor where the

air is cleaner. Crawl if necessary, and breathe shallowly through a cloth, wet if possible.

•Once outside, go to your selected meeting place and make sure everyone is there.

•Call the fire department or 911 from your cell phone outside, or from your neighbor’s

home-not from yours!

•Don’t return to your home until the fire officials say that it is all right to do so.

NOTE: See Section RECOGNIZING NUISANCE ALARMS, for nuisance alarm situations.

2. Other Alarm Visual And Audible Indicators

Operational Mode Visual Indications Audible Indications Action/Note

Normal (standby) Green LED blinks

approx every

60 sec.

Test (button press

when no alarm

condition is

present)

(Note: Test is very

loud, stand a few

feet away.)

Red LED blinks in time

with alarm pattern.

• Single beep.

•3 long beeps, pause,

3 long beeps.

• Single beep.

Perform button press once

a week to verify proper

alarm operation.

Smoke Alarm

Memory (unit has

experienced a

smoke alarm event)

Red LED blinks every

15 sec.

NOTE: Alarm memory is

only retained for 24 hrs.

Push test button to clear

Alarm Memory.

Smoke Alarm Hush

Mode (SMART

HUSH®

CONTROL)

Red LED blinks every

2 sec.

Smoke alarm pattern

stops.

(If there is too much

smoke to allow Hush:

Smoke alarm pattern

continues.)

This feature is to be used

only when a known alarm

condition, such as smoke

from cooking, activates

the alarm.

If you require further information please contact Product Support at 1-800-880-6788 or write us at:

Kidde, 1016 Corporate Park Drive, Mebane, NC 27302. Our internet address is www.kidde.com.

3. Troubleshooting Guide

Trouble

Condition

Visual

Indications Audible Indications Action

Low

Battery

Amber LED

blinks every

30 sec.

Chirp every 60 sec. * Push button once to silence for 24 hrs.

(Push button again to clear Hush and

perform a test.)

* Replace battery as soon as possible.

Note: 7 days after Low Battery begins, the

chirps cannot be silenced.

Photo Fault Amber LED

blinks 4 times

every 30 sec.

Chirp every 30 sec. * See Cleaning Your Alarm section.

* Push button once to attempt to reset

the unit.

* If error continues, remove, dispose unit,

and replace as soon as possible.

Memory

Fault

Amber LED

blinks 3 times

every 30 sec

Chirp every 30 sec. * Push button once to attempt to reset

the unit.

* If error continues, remove, dispose unit,

and replace as soon as possible.

End of Unit

Life

Amber LED

blinks twice

every 30 sec.

Double chirp every

30 sec.

* Push button once to silence for 24 hrs.

(Push button again to clear Hush.)

Note: 7 days after End of Unit Life begins,

the chirps cannot be silenced.

* Remove, dispose unit, and replace as soon

as possible.

Stuck Button Amber LED

blinks every

4 sec.

Chirp every 4 sec. * Push button to dislodge it from being

stuck. If button cannot be unstuck,

remove, dispose unit, and replace

as soon as possible.

MCU Failure None Constant Tone * Remove, dispose unit, and replace as soon

as possible.

4. Introduction, Product Features And Specifications

Introduction

This alarm detects products of combustion using a multi-criteria optical sensor.

Ten (10) years after the unit was installed, this unit will automatically alert you that it is time

to replace the unit. This is called “End of Unit Life” mode. See Troubleshooting Guide.

To help identify the date to replace the unit, a label has been affixed to the side of the alarm.

Write the “Install date” in the space provided, and then write in the “Replace by” date (10

years from initial power up) in permanent marker on the label prior to installing the unit.

Product Features and Specifications:

•Temperature Operating Range: 40°F (4.4°C) to 100°F (37.8°C)

•Humidity Operating Range: up to 95% RH non-condensing

•Audible Alarm: 85+ dB at 10’, 3.0 to 3.5 KHz pulsing alarm

•Smoke Sensor: Multi-Criteria Optical

•Smoke Alarm SMART HUSH® Control

•Powered by 9V battery

•Model 2040-DSR-5B uses an oversized (5 in) mounting bracket.

5. Limitations Of Smoke Alarms

WARNING: PLEASE READ CAREFULLY AND THOROUGHLY

•Life safety from fire in residential occupancies is based primarily on early notification to occu-

pants of the need to escape, followed by the appropriate egress actions by those occupants.

•There are situations where a smoke alarm may not be effective to protect against fire as

stated in the NFPA Standard 72.

For instance:

a) smoking in bed

b) leaving children home alone

c) cleaning with flammable liquids, such as gasoline

•Fire warning systems for dwelling units are capable of protecting about half of the occupants

in potentially fatal fires. A smoke alarm may not be effective in some situations, such as

during incendiary fires where the fire grows so rapidly that an occupant’s egress is blocked

even with properly located smoke alarms, or when victims are intimate with the fire (for

example, when a person’s clothes catch fire while cooking), too old or young, or physically or

mentally impaired such that they cannot escape even when warned early enough that es-

cape should be possible. For these people, additional strategies such as protection-in-place

or assisted escape or rescue are necessary.

•For maximum detection of the various types of fires that can occur within the home, includ-

ing fast flaming and slow smoldering, it is recommended that multi criteria smoke alarms

be installed. This model meets the latest residential smoke alarm standards, which includes

enhanced resistance to nuisance alarms from cooking.

•A battery powered alarm must have a battery of the specified type, in good condition and

installed properly.

•Smoke alarms must be tested regularly to make sure the battery and the alarm circuits are in

good operating condition.

•Smoke alarms cannot provide an alarm if smoke does not reach the alarm. Therefore, smoke

alarms may not sense fires starting in chimneys, within walls, on roofs, on the other side of a

closed door or other obstruction.

•If the alarm is located outside the bedroom or on a different floor, it may not wake up a

sound sleeper.

•The use of alcohol or drugs may also impair one’s ability to hear the smoke alarm. For

maximum protection, a smoke alarm should be installed in each sleeping area on every level

of a home.

This alarm is not intended to alert hearing impaired individuals.

6. Recommended Locations For Smoke Alarms

•Locate smoke alarms in all sleeping areas. Try to monitor the exit path as the bedrooms

are usually farthest from the exit. If more than one sleeping area exists, locate

additional alarms in each sleeping area.

•Locate additional alarms in stairways, because stairways act like chimneys for smoke

and heat.

•Locate at least one alarm on every floor level.

•Locate an alarm in every bedroom.

•Locate an alarm in every room where electrical appliances are operated (i.e. portable

heaters or humidifiers).

•Locate an alarm in every room where someone sleeps with the door closed. The closed

door may prevent an alarm not located in that room from waking the sleeper.

•Smoke, heat, and combustion products rise to the ceiling and spread horizontally.

Mounting the smoke alarm on the ceiling in the center of the room places it closest to

all points in the room. Ceiling mounting is preferred in ordinary residential construc-

tion.

NFPA 72 states: “Smoke alarms in rooms with ceiling slopes greater than 1 ft in 8 ft (.3m in

2.4 m) horizontally shall be located on the high side of the room.” NFPA 72 states: “A row of

detectors shall be spaced and located within 3 ft (0.9m) of the peak of the ceiling measured

horizontally.”
