Karpo Prolaser 896 5-DOT User manual
896 Prolaser®5-DOT
Self-Leveling Laser Pointer
Puntero láser autonivelante
Самовыравнивающийся лазерный указатель
User Manual
Manual del usuario
Руководство по эксплуатации
Up to 100' (30m)
2 AA
2
Thank you for purchasing the Prolaser®896 5-DOT Self-Leveling Laser
Pointer. You are now the owner of one of our innovative range of state of
the art tools. These tools incorporate new laser technology, enabling the
professional user and the serious D.I.Y. enthusiast to achieve accurate
results and reduce valuable work time.
Applications
The Prolaser®896 5-DOT laser pointer can be used for:
Wall stud layout and partition installation•
Electrical outlet and switch layout•
Framing rooms, doors and windows•
Finish carpentry•
Transferring points•
Vertical and horizontal alignments•
Keep this user manual in a safe place for future
reference.
Note
3
Features 4
Safety Instructions 5
Overview 6-7
Battery Installation 8
Operating Instructions 9
Care and Maintenance 10
Field Calibration Test 11-12
Specications 13
Warranty 14
Contents
4
• Fivehighlyvisiblelaserdots:Plumbup&down,3leveldotsat
90° angles
• Smallcrossprojectedateachlaserdot
• Selflevelingrange±4°
• Toughrubberoverlay
• Quick&easyone-buttonoperation
• Laserrange:upto100'(30m)withlasertarget
• Includes:Magneticmulti-functionalbase,lasertarget,softcarrycase
Features
5
The Prolaser®896 is a Class II Laser. It is manufactured to
comply with IEC international rules of safety.
Read this user guide thoroughly before using your Prolaser®
Laser Pointer. Always operate the laser according to the
procedures and warnings in this manual.
LaserRadiation:Seriouseyeinjurycouldbecausedby
lookingdirectlyintothebeamorbyprojectingthebeam
into the eyes of others.
•Theuseofprotectiveeyewearisrecommended.
• Donotlookintoalaserbeamusingmagnifyingoptical
equipment, such as binoculars or telescope, as this will increase
thelevelofeyeinjury.
• Alwayspositionthelaserbeamsothatitdoesnotcauseanyone
to directly stare into it.
• Donotoperatethelaserlevelnearchildrenorletchildren
operate the laser level.
Safety Instructions
WARNING
6
Laser Unit
Overview
1.Keypad
2. Laser output window
(plumbup)
3.Laseroutputwindow(right)
4.Laseroutputwindow(front)
5.Laseroutputwindow(left)
6. Pendulum locking knob
7. Laser output window
(plumbdown)
8. ¼" tripod thread
9. Battery cover
21
3
4
5
6
7
8
9
7
Multifunctional base
1.Fineadjustmentscrew
2. Rare-earth magnets
3.5/8"tripodthread
4.¼"tripodthread
5.Mount
6. ¼" screw
7. Grooves for strap
Keypad
1.ON/OFFKey
2. Power Indicator
3.LaserIndicator
71
1
2
2
6
5
4
3
3
8
The Power Indicator on the keypad
willashwhenbatteryislow.
Note
1.Openthebatterycover.
2.Insert2newAAbatteriesofthesamebrand(regularorgoodquality
rechargeable)accordingtopolaritymarkedinsidethebattery
compartment.
3.Replacethebatterycover.
Battery Installation/Replacement
9
Operating Instructions
Avoid setting up the laser level near
heavy machinery or sources of vibration that may adversely
affect the leveling of the laser.
Note
To get the most out of your Prolaser®896 5-DOT Laser Pointer, please
adhere carefully to the following instructions.
1.OpentheLockingKnob.ThePowerIndicatoronthe
keypad will light red.
2.PresstheON/OFFkeyonthekeypad.TheLaserIndicator
will turn green.
3.Iftheunitisoutoflevelingrange(±4°),theLaserIndicatorandthe
laserbeamswillblink.Adjusttheunituntilblinkingceases.
10
Care and Maintenance
Preventative Maintenance
• Storeinacleandryplace,between5°F–131°F(-15°C–55°C).
• Beforemovingortransportingtheunit,ensurethatitisturnedoffand
thePendulumLockingKnobislocked.
• Ifthelaserunitiswet,dryoffwithadrycloth.Donotsealthelaserin
the carrying case until completely dry.
• Donotattempttodrythelaserunitwithreorwithanelectricdryer.
• Donotdropthelaserunit,avoidroughtreatment,andavoidconstant
vibration.
• Periodicallycheckthecalibrationofthelaserunit.
• Cleanwithasoftcloth,slightlydampenedwithasoapandwater
solution. Do not use harsh chemicals, cleaning solvents or strong
detergents.
• Keepthelaseraperturescleanbywipingthemgentlywithasoft
lint-free cloth.
• Removebatteriesfromthelaserunitduringlengthyperiodsof
non-use, and store in carrying case.
• Ensurethatthelaserunitisturnedoffbeforeremovingbatteries.
Repairs
• SeetheWarrantysectionattheendofthismanual.
• DonottaketheProlaser®896 5-DOT Laser Pointer apart or permit
anyunqualiedpersontotakethelaserunitapart.Unauthorized
servicingmaycausebodilyinjury,irreparablydamagethelaserunit,
and invalidate the warranty.
