Before You Begin 1

JUNIPER NETWORKS STRM

UPGRADING TO STRM 2008.2

RELEASE 2008.2

JUNE 2008

This document provides information for upgrading to STRM 2008.2 including:

•Before You Begin

•Upgrading to STRM 2008.2r2

•Troubleshooting Your Upgrade

•Installing Japanese Support

•Clearing the Cache

You must upgrade the systems in your deployment in the following order:

•Console

Caution: The upgrade process must be complete on your STRM Console and you

must be able to access the STRM user interface on your system hosting the

Console before you upgrade any other systems in your deployment.

•Remote Event Processors

•Remote Event Collectors

•Classification Engines

•Flow Processors

•Flow Collectors

Caution: If your deployment consists of non-standard hardware configurations,

please contact Juniper Networks Customer Support for assistance with your

upgrade. Non-standard hardware configurations may include non-Dell based Intel

servers, unsupported network interface cards, hardware RAID controllers, or

external data storage. For information on STRM appliances and hardware, see the

STRM Installation Guide.

Before You Begin Before you upgrade to STRM 2008.2, note the following:

•To upgrade to STRM 2008.2, you must be running STRM 2008.1. If you are not

running STRM 2008.1, contact Juniper Networks Customer Support for

assistance with your upgrade.

•Make sure you log out of STRM and any instance of the STRM Administration

Console.

•Make sure all browsers are closed during the upgrade process.

2UPGRADING TO STRM 2008.3

•Make sure you upgrade all systems in your deployment hosting VIS

components. If you do not upgrade these systems, error messages may appear

in the log files until the affected systems are upgraded.

•Custom configuration to the crontab is not maintained after the upgrade. The

default crontab configuration is applied by the upgrade process. We

recommend that you backup your crontab configuration prior to the upgrade

using the crontab –l > /tmp/crontab_backup command. However, after

the upgrade, do not replace the default crontab configuration with the backup

version since this results in lost changes for STRM 2008.2. You must re-apply

your custom crontab configuration after the upgrade process.

•Make sure that all systems upgrading to STRM 2008.2 include a minimum of 36

GB drives.

•We recommend that all systems include a minimum of 8 GB of memory. Note

that most STRM appliances will not complete the upgrade process if your

system includes less than 8 GB of memory.

•Make sure that you have Java Runtime Environment installed on your system.

You can download Java version 1.5.0_12 at the following web site:

http://java.com/.

Upgrading to STRM

2008.2 To upgrade to STRM 2008.2 from STRM 2008.1:

Note: Before you begin the upgrade process, make sure you review the Before

You Begin section. This section outlines requirements that must be satisfied before

you begin the upgrade process.

Step 1 Go to the Juniper Networks web site to access the STRM 2008.2 software:

http://www.juniper.net/support

Step 2 Click the Management Software link and log in. Go to the Security Threat

Response Manager Link to download the software.

Step 3 Copy the file to the /tmp folder on your system.

Note: Make sure you copy the appropriate upgrade file for your operating system

to the /tmp folder.

Step 4 Log in as root.

Step 5 Create the folder /media/cdrom as follows:

mkdir /media/cdrom

Step 6 Run the following command:

mount –t iso9660 –o loop /tmp/STRM2008.2.iso /media/cdrom

Step 7 Enter the following command:

./media/cdrom/setup

Step 8 Read the messages and answer the prompts.

The following prompt appears:

Troubleshooting Your Upgrade 3

About to upgrade your STRM from 2008.1 to 2008.2. Continue

(Y/[N])?

Step 9 To continue, enter Y.

If STRM was previously upgraded, a prompt appears informing you that a previous

backup was found.

Step 10 Enter yto proceed with the upgrade.

If the current operating system kernel is older than the version in the upgrade, a

prompt appears informing you this kernel will be replaced.

Step 11 Enter yto proceed with the upgrade.

Wait for upgrade process to complete. This process may require up to several

minutes, depending on your system. When the process is complete, a message

appears:

Upgraded Security Threat Response Manager from version

2008.2.0.41 to version 2008.2.r2.45.

Troubleshooting

Your Upgrade If there are problems with the upgrade, you may encounter one of the folowing

error messages. If you do, follow the solution provided:

•ERROR: Failed to run ‘licenseconverterrunner.sh’ script !

Please contact customer support for assistance with this

error.

Solution: Contact customer support for assistance with this error.

•ERROR: Failed to run upgrade process!

Solution: Go to Step 7 and restart the upgrade process. However, if after you

run the ./setup command, the following error appears:

•Kernel mismatch, running is 2.6.9-55.0.6.ELsmp and installed

is 2.6.9-67.ELsmp. Please reboot and try again.

Solution: Enter the reboot command to reboot your system. Once the system

has rebooted, go to Step 3 and restart the upgrade process.

For additional assistance, contact Juniper Networks Customer Support.

Installing Japanese

Support You can install a separate plug-in to provide Japanese character support in the

STRM Reports interface. Once you install the plug-in located on the Qmmunity

web site, your Report templates will be replaced to ensure the appropriate font and

characters appear in the Reports interface.

Note: To display reports in PDF format, Adobe Acrobat may require the installation

of a Japanese plug-in to view your reports. For more information, see your Adobe

documentation.

4UPGRADING TO STRM 2008.3

To install the Japanese plug-in on an STRM appliance:

Step 1 Upgrade STRM.

Step 2 Go to the Juniper Networks web site to download the plug-in:

http://www.juniper.net/support

Step 3 Click the Management Software link and log in. Go to the Security Threat

Response Manager Link to download the plug-in.

Step 4 Install the plug-in:

rpm -Uvh <path to RPM>/japanese-support-6.1.2-<build>_ctrh.i386.rpm

Clearing the Cache You need to clear your cache before you access the STRM interface:

Note: Make sure that you have Java Runtime Environment installed on your

system. You can download Java version 1.5.0_12 at the following web site:

http://java.com/.

To clear your Java cache:

Step 1 On your desktop, select Start > Run. The Run window appears.

Step 2 In the Open field, enter javaws.The Java Application Cache Viewer appears.

Step 3 Click OK.

Step 4 Click the User tab.

Step 5 Select all STRM Admin Console entries.

Step 6 Click Remove Selected Entries.

To clear the cache of your web browser:

Note: Before you clear the cache, make sure you only have one instance of your

browser open. If you have multiple versions of your browser open, the cache fails

to clear.

Step 1 If you are using Internet Explorer 6.0, select Tools > Internet Options > Delete

Files.

Step 2 If you are using Internet Explorer 7.0, select Tools > Internet Options > General

> Delete > Delete Files.

Step 3 If you are using Mozilla Firefox, select Tools > Options > Advanced > Network >

Clear Now.

Note: If you are using Mozilla Firefox, you must clear the cache in Internet

Explorer as well as in Mozilla Firefox.

Now you can log in to STRM.

For more information on accessing and using STRM, see the STRM Users Guide

or STRM Administration Guide.

Clearing the Cache 5

trademarks of Juniper Networks Inc. in the United States and other countries. All other trademarks, service marks, registered

trademarks, or registered service marks in this document are the property of JuniperNetworks or their respective owners. All

specifications are subject to change without notice. Juniper Networks assumes no responsibility for any inaccuracies in this

document or for any obligation to update information in this document. Juniper Networks reserves the right to change,

modify, transfer, or otherwise revise this publication without notice.

Part Number 530-25622-01
