Jenn-Air JGC8536BDB10 User manual

COOKTOP, BURNER AND GRATE PARTS

For Models: JGC8536BDW10, JGC8536BDB10, JGC8536BDS10

(White) (Black) (Stainless)

5−12 Litho in U.S.A (CCS)(bay) Part No. W10203797 Rev. C

36" GAS COOKTOP

COOKTOP, BURNER AND GRATE PARTS

For Models: JGC8536BDW10, JGC8536BDB10, JGC8536BDS10

(White) (Black) (Stainless)

W10203797

Illus. Part

No. No. DESCRIPTION

1 Literature Parts

W10203467

Installation

Instructions

W10203466

Use & Care Guide

2 Cooktop

74007732 White

74007729 Black

74007731 Stainless

3 Cap, Burner

7504P165−60

LR & RF

7504P202−60

LF & RR

7504P204−60

CTR

4 Grate, Burner

W10203775

Left

W10203774

Right

5 74007705 Grommet

W10203520

Knob, Control

7 Burner, Base

W10203534

Small 5K LF, RF

W10203537

Large 12.5K RF,LR

8215559 XLarge 15K CTR

8 74009336 Ignitor

9 74009337 Screw,Self Tapping

W10203776

Grate, Center

11 Venturi

74010092 Large

W10203539

XLarge

BURNER BOX, GAS VALVES, AND SWITCHES

For Models: JGC8536BDW10, JGC8536BDB10, JGC8536BDS10

(White) (Black) (Stainless)

W10203797

BURNER BOX, GAS VALVES, AND SWITCHES

For Models: JGC8536BDW10, JGC8536BDB10, JGC8536BDS10

(White) (Black) (Stainless)

W10203797

Illus. Part

No. No. DESCRIPTION

W10203777

Burner Box

2 74005976 Rail,Burner (CTR)

3 74005952 Rail,Burner(Side)

7513P297−60

Pipe, Manifold

W10110573

Module, Spark

W10203556

Cover,Spark Mod

7 74007747 Regulator, Prsr

8 74007755 Tube, Burner (LF)

9 74007756 Tube, Burner (LR)

10 74007757 Tube, Burner (RF)

11 74007758 Tube, Burner (RR)

12 74007757 Tube, Burner (CTR)

13 71003231 Screw, Valve

14 550707 Relief, Strain

15 74009553 Holder W/ Orfice

5K (LF, RR)

16 74007765 Holder W/ Orfice

12.5K (RF, LR)

17 74007766 Holder W/ Orfice

15K (CTR)

18 74007753 Switch,Ignitor(LT)

19 74007774 Switch,Ignitor(RT)

20 74007773 Switch,Igntr(CTR)

21 200758 Screw

7101P426−60

Screw

W10175142

Brkt, Hold Down

OPTIONAL PARTS (NOT INCLUDED)

For Models: JGC8536BDW10, JGC8536BDB10, JGC8536BDS10

(White) (Black) (Stainless)

W10203797

Illus. Part

No. No. DESCRIPTION

Following Parts Not Illustrated

74007903 Cord, Power

Miscellaneous

74007746 Kit, LP Orfice

WIRING HARNESS PARTS

74007769 Harness, Main

W10173477

Harness, Spark
