INSTRUCTION MANUAL
www.jbctools.com
CL6217
Metal Brush
2
Metal Brush ............... 4 units Manual ........................... 1 unit
Ref. 0027085
Metal Brush replacement in Compact Stations *
This manual corresponds to the following reference:
CL6217
Packing List
The following items are included:
* Note: To join 2 brushes the connection clip is needed. Ref.
CL 6217 does not include any clip. Reuse the clip of your worn
brushes.
The replacement Ref. CL6220 instead carries the clip built.
As replacement for CP-A and CF-A there is no connection clip
needed.
3
Improve thermal transfer by cleaning the tip after each solder joint.
CL8499 ESD Tip Cleaner
Brass Wool
Ref. CL6210 Sponge
Ref. S0354
Tip Tinner
Ref. T T-A
Brushes
Ref. CL6220
Optional
Inox Wool
Ref. CL6205
Metal Brush replacement in CL8499 *
1. Unlock 2. Remove and replace
ESD Tip Wiper
Ref. CL0240
Splashguard
Ref. 0 017576
Antisplash
Membrane
R ef. 0 0 175 74
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic
equipment at the end of its life must be collected and returned to an
authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against all manufacturing defects,
including the replacement of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must be returned, postage paid, to
the dealer where it was purchased.
www.jbctools.com
0027085-0421
Specifications
- Total Net Weight: 16.9 gr / 0.037 lb
- Total Package Dimensions: 90 x 55 x 40 mm
(L x W x H) 3.54 x 2.17 x 1.57 in
- Total Package Weight: 18.1 gr / 0.04 lb
Complies with CE standards
ESD protected
