Jacuzzi Bianca F500 User manual

bianca®whirlpool bath and soaking bath

With clean lines and an uncomplicated

aesthetic, the Bianca®is pure style.

whirlpool features:

• 4 fully adjustable TheraPro™ jets

• 3 directionally adjustable AccuPro™ jets

• Contoured backrest

• Electronic on/off control

• Drain included on whirlpool baths

• Patented Fixed Air Flow System

bianca®whirlpool bath

model number: F500

exterior dimensions:

72" long x 48" wide x 20½" high

interior dimensions at waterline:

44" long x 32" wide x 28" wide(mid)

# of Jets/type of Jets:

4 TheraPro™ Jets

3 AccuPro™ Jets

operating gallons:

73 gallons

meaning literally “white” in Italian, the bianca®whirlpool evokes—embodies—purity and cleansing.

bianca®soaking bath

model number: F505

exterior dimensions:

72" long x 48" wide x 20½" high

interior dimensions at waterline:

44" long x 32" wide x 28" wide(mid)

Detail: The Bianca®whirlpool‘s gentle curves

cozily cradle the body, while Jacuzzi’s exclusive,

adjustable TheraPro™ and AccuPro™ jets deliver

rousing massage.

Bianca® Whirlpool Bath

Model: F500

Bianca® Bath

Model: F505

Installation Notes

Refer to installation instructions included with ﬁxture before beginning installation.

Please conﬁrm product availability and speciﬁcations before commencing with any

installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE WITHOUT

NOTICE.

Electrical Components and Electrical Speciﬁcations do not apply to non-jetted baths.

Ordering Information

Product Code:

F500 Bianca® Whirlpool Bath

Left Hand

F505 Bianca® Bath

• Left Hand Drain Location

• Accessories / Hardware:

Trip-Lever Drain Kit: #X559

Rotary Drain Kit, 26” Cable: #8730

1 X TheraPro™ Jet Rings #D095

2 X AccuPro™ Jet Rings #J869

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(849) – Oil Rubbed Bronze

Technical Speciﬁcations

Dimensions

72”L x 48”W x 20-1/2”H

(1829 mm) L x (1219 mm) W x (514 mm) H

Drain/Overﬂow

A: 16” (406 mm) B: 8-1/2” (216 mm)

Cutout

70” x 46”

Total Weight

F500: 993 lb. (450 kg) / 41 lb/sq. ft. (202 kg/m2)

F505: 948 lb. (430 kg) / 40 lb/sq. ft. (193 kg/m2)

Operating Gallonage

73 U.S. Gal. (276 liters)

Product Weight

F500: 135 lb. (61 kg)

F505: 90 lb. (41 kg)

Skirt Mounting

Optional U-Frame

Electrical Speciﬁcations Model F500 Only

Requires a dedicated GFCI protected separate circuit.

Motor/Pump: 120 VAC, 15 AMP, 60 Hz.

RapidHeat™: 120 VAC, 15 AMP, Hz

Heater (Optional) Model F500 Only

Requires a dedicated GFCI protected separate circuit.

RapidHeat™: P/N S750000

*72"

24"

48"

8-1/2"

13-3/4"

13-1/2" x 4"

Motor

12" H x 18" L

Service Access

Opt. Service Access

END VIEW

SIDE VIEW

#FR24 07/07

DRAIN/OVERFLOW

Product Shown: Bianca®Whirlpool Bath Left Hand Shown Model: F500

* Measurements inside unit represent cutout in ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.
