Jabra Move Style Edition User manual

User manual

Jabra

Move Style Edition

JABRA MOVE STYLE EDITION

1. WELCOME........................................3

2. WHAT’S IN THE BOX...................... 4

3. HOW TO WEAR................................5

3.1 HEIGHT ADJUSTMENT

4. HOW TO CHARGE........................... 6

4.1 BATTERY STATUS

5. HOW TO CONNECT..........................7

5.1 BLUETOOTH CONNECT TO A NEW OR SECOND

MOBILE DEVICE

5.2 CONNECT TO 3.5 MM JACK CONNECTOR

6. HOW TO USE ................................. 9

6.1 MUSIC & CHAT

6.2 TURN HEADPHONES ON/OFF

6.3 MULTIPLE CALL HANDLING

6.4 VOICE GUIDANCE

7. SUPPORT.......................................13

7.1 FAQ

7.2 FACTORY RESET

7.3 HOW TO CARE FOR YOUR HEADPHONES

8. TECHNICAL SPECIFICATIONS ........14

JABRA MOVE STYLE EDITION

1. WELCOME

Thank you for purchasing the Jabra Move Style

Edition. We hope you will enjoy it!

JABRA MOVE STYLE EDITION FEATURES

Premium wireless sound experience - amplifies

without distortion. Brings out the depth and

clarity of your music

Seals the sound - angled earcups allow you to

hear all the music

Easily connect with any device via Bluetooth 4.0

Life proof - lightweight, comfortable

headphones built & tested for life on the move

Premium materials - stainless steel

Wired option - detachable cord for when you

need to be wired

JABRA MOVE STYLE EDITION

2. WHAT’S IN THE BOX

Audio cable

Micro-USB cable

On/Off/

Pairing

switch

Volume up

button

3.5 mm Jack

Connector

Micro-USB Port

(charging only)

Battery and

Connection

Status Lights

Adjustable

Headband

Multi-function

button

Volume down

button

JABRA MOVE STYLE EDITION

3. HOW TO WEAR

3.1 HEIGHT ADJUSTMENT

Get the perfect fit by adjusting the headband, as

illustrated.

JABRA MOVE STYLE EDITION

4. HOW TO CHARGE

Plug the headphones into any available USB port

on your PC using any micro-USB cable.

4.1 BATTERY STATUS

Tap the Multi-function button when not on a call to

see the battery status. It takes 1-2 hours to fully

charge the headphones.

LED COLOR BATTERY LEVEL

Green Medium/High

Red Low

Flashing red Critically low

JABRA MOVE STYLE EDITION

5. HOW TO CONNECT

The Jabra Move Style Edition will automatically

attempt to Bluetooth connect to a mobile device

whenever it is powered on (unless already

connected to a Bluetooth device). Simply follow

the voice-guided connection instructions.

5.1 BLUETOOTH CONNECT TO A NEW OR

SECOND MOBILE DEVICE

1. Hold the On/Off/Pairing switch in the Pairing

position for 3 secs.

2. Pairing mode will be announced in the

headphones, and the Bluetooth light will flash

blue.

3. Follow the voice-guided instructions to connect

to your Bluetooth device.

JABRA MOVE STYLE EDITION

NOTE: If two mobile phones have been connected to the

Jabra Move Style Edition, you may need to select which

phone will be used for calls/music. Simply open the

Bluetooth menu on the mobile phone you wish to use

for calls/music and select the Jabra Move Style Edition

from the list of devices.

5.2 CONNECT TO 3.5 MM JACK CONNECTOR

Connect the headphones to a 3.5 mm jack

connector on your mobile device or PC using the

supplied audio cable.

NOTE: Bluetooth connections are disabled when

connected to the 3.5 mm Jack Connector.

JABRA MOVE STYLE EDITION

6. HOW TO USE

6.1 MUSIC & CHAT

The buttons on the headphones enable you to

control your music and phone calls.

On/Off/

Pairing

switch

Volume up

button

Multi-function

button

Volume down

button

JABRA MOVE STYLE EDITION

FUNCTION HOW TO DO IT

Pause/play music Tap the Multi-function

button

Adjust volume Tap the Volume up or

Volume down button

Skip track

Press and hold either the

Volume up or Volume

down button

Battery status

Tap the Volume up or

Volume down button,

when not on a call

Answer/end call Tap the Multi-function

button

Reject call Press and hold (1 sec) the

Multi-function button

Redial last number Double-tap the Multi-

function button
