Jabra JX20 - Pura - Headset User manual
Eargel
JX20 PURA
JX20 PURA
JX20 PURA
what the lights mean
1a: First time pairing:
Turn headset on - automatically
goes into pairing mode.
2. Activate Bluetooth on you phone.
3. Press‘Yes’on the phone and conrm with PIN code 0000 (4 zeros).
4. Typical view in mobile phone.
Pairing the headset with your Phone using your headset wearing style
Control volume
Press volume up
Press volume down
Answer a call
End call
With earhook1b: Later pairing:
Turn headset on - Press and hold
the answer / end button until
the LED on the back shines
continuously.
Without earhook
On/o switch
(rotate earpiece
90 degrees).
Place eargel over earpiece
Charge and turn on your headset
When the device is fully
charged all 5 steps of
the LED are lit.
Fig. 1
What you see Whatthis meansaboutyour
headset
Solid light The headset is in pairing
mode
Quick ash every 5 seconds for
1 minute
Connected and not on active
call (reappears if you have
asked for battery status)
LED ashing for 1 second, then
1½ second pause then repeats
Incoming call
LED ashing twice and then
turning o
Pairing succeeded
LED ashes once then solid white Pairing failed
LED ashes once 0-25% charged
LED ashes twice 25-50% charged
LED ashes three times 50-75% charged
LED ashes four times 75%-100% charged
LED soild white Fully charged
attaChing earhook
JX20 PURA deskstand
1
LIght indicator
2Charging socket
1
Light indicator (LED)
2
Charging socket
3
On/o switch (rotate earpiece 90 degrees)
4
Answer/end button
5
Volume up/down
6
Earhook connection
JX20 PURA
Eargels Earhooks
1
2
3
4
1
2
6
5
getting started
www.jabra.com
Made in China
Type: JX20
NEED MORE HELP?
Access website www.jabra.com for full user manual
CUSTOMER CONTACT DETAILS:
1. Web: www.jabra.com/nasupport
(for the latest support info and online User Manuals)
2. Phone: 1 (800) 327-2230 (U.S. toll free) 1 (800) 489-4199 (Canada)
Register your Jabra at jabra.com/nasupport
– for news, support and competitions
© 2007 GN Netcom, Inc. All rights reserved. Jabra® is a registered trademark of GN A/S.
All other trademarks included herein are the property of their respective owners.
The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by GN Netcom, Inc. is under license. (Design and specications subject to
change without notice).
8101691 C
