Jabra BT2080 - Headset - Ear-bud User manual

jab

User manual

www.jabra.com

Jabra BT2080

USER MANUAL - LANGUAGES

ENGLISH - EUROPE (click here for manual)..........................4

ENGLISH - NORTH AMERICA (Click here for manual) . . . . . . . . . . . . . . . 20

ENGLISH - ASIA PACIFIC (Click here for manual)....................37

DANSK (Klik her for at se vejledningen) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

FRANÇAIS (Cliquez ici pour le manuel). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

FRANÇAIS - NORTH AMERICA (Cliquez ici pour le manuel) . . . . . . . . . 84

DEUTSCH (Klicken Sie hier für Handbuch) . . . . . . . . . . . . . . . . . . . . . . . .102

РУССКИЙ (Щёлкните здесь, чтобы скачать

руководство) ..................................................120

YКРАЇНА (Клацніть тут для завантаження посібника) ......138

NEDERLANDS (Klik hier voor de handleiding).....................156

SUOMI (Avaa käyttöohje napsauttamalla tässä) . . . . . . . . . . . . . . . . .173

SVENSKA (Klicka här för bruksanvisning) .........................189

ITALIANO (Fare clic qui per il manuale) . . . . . . . . . . . . . . . . . . . . . . . . . . .205

PORTUGUÊS - NORTH AMERICA (Clique aqui para

acessaromanual)...............................................221

ESPAÑOL (Haga clic aquí para obtener el manual)................238

ESPAÑOL - NORTH AMERICA (Haga clic aquí para

accederalmanual)..............................................255

ČESKY (Zde klikněte pro manuál).................................273

POLSKI (Kliknij tutaj, żeby przejść do instrukcji) . . . . . . . . . . . . . . . . . . .289

ΕΛΛΗΝΙΚΑ (Κάντε κλικ εδώ για το εγχειρίδιο) . . . . . . . . . . . . . . . . . . . . .307

TÜRKÇE (Kullanım kılavuzu için buraya tıklayın)..................325

MAGYAR (Kattintson ide a kézikönyvért) . . . . . . . . . . . . . . . . . . . . . . . . .341

ROMÂNĂ (Faceţi clic aici pentru manual) . . . . . . . . . . . . . . . . . . . . . . . .358

简体中文（单击此处查看手册）

............................403

繁體中文（按下此處檢視手冊）

............................418

日本語 (取扱説明書をご覧になるには、ここをクリック

してください )

..................................................433

한국어(설명서를 보려면 여기를 클릭하십시오)

............450

BAHASA MELAYU (Kullanım kılavuzu için buraya tıklayın) . . . . . . . .466

ภาษาไทย (คลิกที่นี่เพื่ออ่านคู่มือ) .......................................483

english

JABRA BT2080

Contents

THANK YOU....................................................2

ABOUT YOUR JABRA BT2080 ...................................2

WHAT YOUR HEADSET CAN DO ................................3

GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

CHARGE YOUR HEADSET.......................................4

TURNING YOUR HEADSET ON AND OFF . . . . . . . . . . . . . . . . . . . . . . . . 4

PAIRING IT WITH YOUR PHONE .................................4

CONNECTING WITH YOUR PHONE .............................5

WEAR IT HOW YOU LIKE IT .....................................6

HOW TO .......................................................6

HOW THE STATUSDISPLAY™ WORKS............................7

TROUBLESHOOTING & FAQ ....................................8

NEED MORE HELP?.............................................9

TAKING CARE OF YOUR HEADSET .............................10

WARNING! ....................................................10

SAFETY INFORMATION! .......................................11

BUILTIN BATTERY CARE: ......................................11

CHARGER CARE: ..............................................12

WARRANTY ...................................................13

CERTIFICATION ...............................................15

GLOSSARY ....................................................16

english

JABRA BT2080

tHAnK YoU

Thank you for purchasing the Jabra BT2080 Bluetooth® headset.

We hope you enjoy it! This instruction manual will get you started

and ready to make the most of your headset.

ABoUt YoUR JABRA Bt2080

A. Answer/end button

B. On/o button

C. StatusDisplayTM

With battery indicator and Bluetooth connection indicator

D. Charging socket

E. Volume up/down

F. Ear hook

jabra

english

JABRA BT2080

WHAt YoUR HeADset CAn Do

Your Jabra BT2080 lets you do all this:

- Answer calls

- End calls

- See battery status

- See Bluetooth connection status

- Reject calls*

- Voice dialling*

- Last number redial*

- Mute

- Transfer calls

- Adjust volume

Specications

- Talk time 6 hours

- Standby time 8 days

- Bluetooth specication version 2.1 with EDR and eSCO

- Weight 8 gram

- Operating range up to 10 meters (approximately 33 feet)

- Supported Bluetooth proles: HFP, HSP

- Internal rechargeable battery charged by wall charger

- Always see your battery and connection status on the

Jabra StatusDisplay™

GettInG stARteD

You should follow three steps before using your headset

1 Charge your headset

2 Activate Bluetooth on your mobile phone (refer to the

manual for your mobile phone)

3 Pair your headset to your mobile phone

The Jabra BT2080 is easy to operate. The answer/end button on

the headset performs dierent functions depending on how long

you press it.

* Phone dependent

english

JABRA BT2080

Instruction Duration of press

Tap Press briey

Press Approx: 1 second

Press and hold Approx: 5 seconds

CHARGe YoUR HeADset

Make sure that your headset is fully charged for two hours before

you start using it. Use the AC power supply to charge from a

power socket. When the battery indicator has a solid red light,

your headset is charging. When the headset is fully charged the

battery indicator turns solid green for ve minutes and is then

turned o.

Use only the charger provided in the box - do not use chargers

from any other devices as this may damage your headset.

Please note: The lifetime of the battery will be signicantly reduced

if your device is left uncharged for a long period. We therefore

recommend that you recharge your device at least once a month.

tURnInG YoUR HeADset on AnD oFF

To turn on your headset please press the ON/OFF button for

2 seconds until both indicators ash on the Jabra StatusDisplay™.

PAIRInG It WItH YoUR PHone

Headsets are connected to phones using a procedure called

‘pairing’. By following a few simple steps, a phone can be paired

with a headset in a matter of minutes.

1 Put the headset in pairing mode

- When you turn on your Jabra BT2080 for the rst time, the

headset will automatically start up on pairing mode – i.e. it is

discoverable for your phone. When the headset is in pairing

mode the Bluetooth status indication on the StatusDisplay™ is

ashing.

english

JABRA BT2080

2 Set your Bluetooth phone to‘discover’ the Jabra BT2080

- Follow your phone’s instruction guide. First make sure that

Bluetooth is activated on your mobile phone. Then set your

phone to discover new devices. This usually involves going

to a‘setup,’‘connect’ or‘Bluetooth’menu on your phone and

selecting the option to‘discover’or ‘add’a Bluetooth device.*

3 Your phone will nd the Jabra BT2080

- Your phone will nd the headset under name“Jabra BT2080”.

Your phone then asks if you want to pair with the headset.

Accept by pressing‘Yes’or‘OK’on the phone. You may be asked

to conrm with a passkey or PIN. Then use 0000 (4 zeros). Your

phone will conrm when pairing is complete and the Bluetooth

status indication on the StatusDisplay™ will shift from ashing

light to steady light.

CONNECTIVITY

SELECT

MobilSurf

BLUET O OT H

Infrared port

Wap options

Synchronization

Networks

DEVICES FOUND

Jabra BT2080

Passkey:

****

HANDSFREE

SELECT

Jabra BT2080

added.

The handsfree is

now ready for use

SELECT

Manual pairing mode

If you wish to use the headset with a dierent phone, or if the

pairing process was interrupted, you can manually set the headset

to pairing mode.

Make sure the headset is on. Press and hold the answer/end

button for approximately 5 seconds until the Bluetooth icon turns

from a steady light to a ashing light. Then repeat steps 2 and 3 in

the above pairing guide.

ConneCtInG WItH YoUR PHone

Pairing is only needed the rst time a headset and phone are

used together. When the headset and phone have been paired

once, they will automatically connect when the headset is on and

Bluetooth is activated on the phone. The headset can be used

when it is“connected” to the phone. If the devices are paired, but

do not immediately connect, tap the answer/end button. When

your headset is connected the Bluetooth connection icon in the

StatusDisplay™ will be constant on for 3 seconds.

* Phone dependent

english

JABRA BT2080

WeAR It HoW YoU LIKe It

The Jabra BT2080 can be worn on either ear with or without

earhook. Simply remove the earhook if you prefer this wearing

style or attach the earhook to t left or right ear depending on

your preference.

HoW to

Answer a call

- Tap (less than 1 sec) the answer/end button on your headset to

answer a call.

End a call

- Tap the answer/end button to end an active call.

Reject a call*

- Press (approx 1 sec) the answer/end button when the phone

rings to reject an incoming call. Depending on your phone

settings, the person who called you will either be forwarded to

your voice mail or will hear a busy signal.

Make a call

- When you make a call from your mobile phone, the call will

(subject to phone settings) automatically transfer to your

headset. If your phone does not allow this feature, tap on the

Jabra BT2080’s answer/end button to transfer the call to the

headset. Press answer/end button and volume up button at the

same time, you can transfer the call back to phone.

Activate voice dialling*

- Press the answer/end button. For best results, record the voice

dialling tag through your headset. Please consult your phone’s

user manual for more information about using this feature.

Redial last number*

- Double tap the answer/end button when the headset is

connected to your phone.

Adjust sound and volume*

- Tap the volume up or down to adjust the volume.

* Phone dependent

english

JABRA BT2080

Mute/un-mute

- To mute, press both volume up and down at the same time.

A low beep alert plays during a muted call.

- To un-mute, tap either of the volume buttons.

Call waiting and placing a call on hold*

- This lets you put a call on hold during a conversation and

answer a waiting call.

- Press the answer/end button once to put the active call on hold

and answer the waiting call.

- Press the answer/end button to switch between the two calls.

- Tap the answer/end button to end the active conversation.

HoW tHe stAtUsDIsPLAY™ WoRKs

Bluetooth

Indicator

Indicates if your headset is connected to your

phone

- Solid light means headset is connected to your

phone

- Flashing light means headset is in‘pairing

mode’ and ready to be connected to a new

phone

Battery

Indicator

Indicates battery level and if headset is

turned ON

- Green light indicates that the headset has more

than 10 minutes of talk time remaining

- Red light indicates that the headset has less

than 10 minutes of talk time remaining

To save battery the Jabra StatusDisplay™ is turned o after 3 seconds.

Get an instant status from the Jabra StatusDisplay™ by a tap on

any button on the headset when you are not on a call.

* Phone dependent

Other manuals for BT2080 - Headset - Ear-bud

Table of contents

Popular Headset manuals by other brands

Sena

Sena SMH10 quick start guide

IASUS

IASUS Stealth IA-NT4-BASIC-BT manual

Sennheiser

Sennheiser EPOS ADAPT 230 user guide

Doro

Doro Flexus HS2005 user guide

GE 98971 datasheet

Hama

Hama 00184070 quick start guide

Plantronics

Plantronics Blackwire 3200 Series user guide

Blue Tiger

Blue Tiger Advantage PLUS user manual

Jawbone

Jawbone Icon user manual

Roxcore

Roxcore Flow A+ manual

Turtle Beach

Turtle Beach XP 510 user guide

Philips

Philips SHB6101 Specification sheet

HyperX

HyperX HyperX Cloud Flight manual

Bose

Bose MIE2 Mobile owner's guide

HyperX

HyperX cloud ii quick start guide

Southwing

Southwing SA505 Specifications

Plantronics

Plantronics VOYAGER 520 user guide

Blueant

Blueant X5i user manual
