IOGear MiniView GCS612A User manual

Installation Manual (GCS612A)

MiniView™ Micro Audio

2 Port KVM Switch with Built-in KVM Cables

IOGEAR®, the IOGEAR logo, MiniView, VSE are trademarks or registered trademarks of IOGEAR®,

Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. IBM is a registered

trademark of International Business Machines, Inc. Macintosh, G3/G4 and iMac are registered

trademarks of Apple Computer, Inc. IOGEAR®makes no warranty of any kind with regards to the

information presented in this document. All information furnished here is for informational purposes

only and is subject to change without notice. IOGEAR®, Inc. assumes no responsibility for any

inaccuracies or errors that may appear in this document.

Thank you for purchasing one of the most feature-rich keyboard, video, and mouse switches

on the market.IOGEAR®’s MiniView™ Micro Audio switches are first-rate connectivity

accessories designed to help reduce the frustration of managing multiple computer systems.

With the MiniView™ Micro Audio by IOGEAR®, you can access two to four computers from a

single console (keyboard, mouse and monitor), and allow them share multimedia speakers.

MiniView™ Micro Audio allows you to change ports easily by entering Hot Key combinations

from the keyboard.Setup is fast and easy;plugging cables into their appropriate ports is all

that is entailed.

We hope you enjoy using your MiniView™ Micro Audio, yet another first-rate connectivity

solution from IOGEAR®.

Package Contents

Overview

Features

Requirements

Pictorial Introduction

Installation

Operation

Specification

Troubleshooting

Troubleshooting Con’d

Tech Support

Radio & TV Interference Statement

Limited Warranty

Table of Contents

○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○

This package contains:

1 MiniViewTM Micro Micro Audio 2 Port KVM Switch

1 User Manual

1 Quick Start Guide

1 Warranty Registration Card

If any items are damaged or missing, please contact your dealer.

Package Contents

Introducing the twor port MiniView™ Micro Audio KVM switch from IOGEAR®– A simple

solution for those with more PCs than hands.Use one keyboard, one monitor and one

mouse to control two PCs or Macintosh systems*, and share the multimedia speakers

among them.This self-powered KVM switch features mouse & keyboard emulation to

ensure smooth operation, as well as support for Plug-n-Play monitors and most wheel mice.

Our patentedVSEVideo Signal Enhancement®technology provides rich, 32-bit color at

resolutions up to 2048 x 1536. With KVM cables (6' long) molded into the unit, all you need

to do is to plug it into your computers, and you’ve got a complete KVM solution from

IOGEAR®.

* Macintosh support requires IOGEAR®’s Mac Adapter. [Part # GCV160 for Mac with ADB,

Part # GUC10KM for USB Mac.]

Overview

• The smallest 2 port KVM switch with audio support available.

• Use one keyboard, monitor and mouse to control 2 computers.

• Share multimedia speakers among two computers.

• 6' long molded-in cables to simplify setup.

• Microsoft Intellimouse, Logitech FirstMouse+, and the scrolling wheel on most mice

• Port selection through convenient Hot Keys.

• PS/2 mouse emulation for error-free boot-up.

• Save space and reduce desktop clutter.

• Plug-n-Play monitor support.

• Support video resolutions up to 2048 x 1536

• No software required.

• Built in AutoScan mode.

• LEDs allow for easy status monitoring.

• 3Year LimitedWarranty.

Features

Requirements

Console

• A VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be

using on any computer in the installation.

• A PS/2 Style Mouse.

• A PS/2 Keyboard.

Computers

The following equipment must be installed on each computer that is to be connected to the

system:

• AVGA, SVGA or Multisync video card.

• A 6-pin mini-DIN (PS/2 style) mouse port.

• A 6-pin mini-DIN (PS/2 Style) keyboard port.

Cables

For optimum signal integrity and to simplify the layout, high-quality 4-in-1 Custom KVM

cables have been designed into the GCS612A.There is no need for a separate cable

purchase.

Note:

The KVM cables have PS/2 style keyboard and mouse connectors.The GCS612A does not

support AT keyboards or serial mice.

Requirements

1.KVM Cables

These 4-in-1 cables connect to the keyboard, video,

mouse, and audio ports on the computers you are

installing.

2.Port LEDs

A LED lights to indicate its corresponding port is the one

that has the KVM focus.Depending on the port’s status,

the LED may flash according to a specific pattern.

3.Speaker Jack

The cable from your speakers (optional) plugs in here.

4.Console Ports

Your keyboard, monitor, and mouse, plug in here.Each

port is marked with an appropriate icon to indicate itself.

○○○○

○○○○○○

Pictorial Introduction
