IOGear GUWH104 User manual
1
GUWH104
PART NO. M0426
Installation
Installation
Installation Guide
Wireless USB Hub
3
Welcome
Thank you for purchasing one of the most user-friendly Wireless USB devices on the market. IOGEAR’s
Wireless USB Hub is top of the line when it comes to Wireless USB connectivity, implementing the use of
Ultra-Wideband (UWB) to achieve data transfer speeds comparable to USB 2.0 without the need of wires
between peripherals and the computer.
To better serve you, IOGEAR offers an array of additional USB 2.0, USB 1.1, FireWire, KVM, and other
peripheral products. For more information or to purchase additional IOGEAR products, visit us at www.
IOGEAR.com
We hope you enjoy using your IOGEAR Wireless USB Hub, another first-rate connectivity solution from
IOGEAR.
4
Table of Contents
Welcome 3
Introduction 5
Features 6
Requirements 7
Package Contents 8
Device Overview 9
Installation 10
Hardware Preparation 11
Software Installation 12
Driver Installation 16
Frequently Asked Questions 17
Technical Support 20
Limited Warranty 22
Federal Communications Commission
(FCC) Statement
23
Contact 24
5
Introduction
IOGEAR’s Wireless USB allows you to connect your USB peripherals and computer with all the ease and
speed of USB 2.0 without the use of USB cables and extenders between the PC and your Wireless USB
Hub. Gain all of the advantages of USB 2.0 without the hassle of wires cluttering up your workspace. Plug
your USB devices into the Wireless USB Hub and within seconds you have wireless access and control
over the devices with no delay, purely plug-and-play.
The Ultra-Wideband Hub provides the ability for in-room Wireless USB connectivity at distances of up to
30 feet. It offers a data transmission speed of up to 480 Mbit/s at distances of up to 3 meters.
6
Features
Wireless USB 2.0 speed through UWB medium•
Simple hardware interface•
Easy Installation has you connected in minutes•
Solid 3-year limited warranty•
7
Requirements
Available AC outlets in the room•
Available USB ports•
Software requires Windows and CD-ROM drive•
8
Package Contents
1 x Wireless USB Hub GUWH104
1 x Wireless USB Hub Antenna
1 x Wireless USB Hub Power Supply
1 x USB Type A to mini-B Cable
1 x Software CD (with Electronic Manual)
9
Device Overview
Side View:
Top View:
1. Host Selection button
2. Active Host LEDs
3. Power LED
The default and recommended setting is to operate in
Auto Association mode. In this mode, the Wireless USB Hub
will automatically connect to the Wireless USB Host Adapter.
The Host Selection button is used in Manual Association mode.
This mode is only needed if your Wireless USB Hub has already
been successfully associated with more than one Wireless
USB Host Adapter-PC combination. The Wireless USB Hub
can support up to three such associations. Set S2 to Manual
Association mode and then use the Host Selection button to
manually cycle through the three choices for which Wireless
USB Host Adapter-PC combination to connect to. Using this
button, you can force the Wireless USB Hub to connect to one
of three pre-associated PCs of your choosing.
HUB
HUB
ASSOC
ASSOC.
WIRED
WIRED
WIRELESS
WIRELESS
MANUAL
MANUAL
AUTO
AUTO
1
4 5
23
4. Switch 1 (S1)
5. Switch 2 (S2)
S1 S2
Wired Wireless
(recommended)
Auto
(recommended)
Manual
10
Installation
Before we get started, please NOTE:
Do not place Wireless USB devices under direct sunlight or near high heat emitting devices;
Do not place Wireless USB devices near water or wet surfaces to avoid electric hazards;
Do not place Wireless USB devices on any moving or unstable surfaces;
