Intermec 4630 User manual
Coax/Twinax
Interface Card
User’s Manual
Norand Mobile System Division
P/N 065099-002
IntermecCorporation
6001 36th Avenue West
P.O. Box 4280
Everett, WA 98203-9280
U.S. service and technical support: 1-800-755-5505
U.S. media supplies ordering information: 1-800-227-9947
Canadian service and technical support: 1-800-688-7043
Canadian media supplies ordering information: 1-800-268-6936
Outside U.S. and Canada: Contact your local Intermec service
supplier.
The information contained herein is proprietary and is provided solely
for the purpose of allowing customers to operate and/or service
Intermec manufactured equipment and is not to be released,
reproduced, or used for any other purpose without written permission
of Intermec.
Information and specifications in this manual are subject to change
without notice.
1997 by Intermec Corporation
All Rights Reserved
The word Intermec, the Intermec logo, JANUS, IRL, TRAKKER,
Antares, Duratherm, Precision Print, PrintSet, Virtual Wedge, and
CrossBar are either trademarks or registered trademarks of Intermec
Corporation.
Command Pass-Thruis a trademark of I-O Corporation. The
information in this manual is based on copyrighted material contained
in the I-O 4000 User’s Guide, published by I-O Corporation, Salt Lake
City, Utah.
Throughout this manual, trademarked names may be used. Rather
than put a trademark (or ) symbol in every occurrence of a
trademarked name, we state that we are using the names only in an
editorial fashion, and to the benefit of the trademark owner, with no
intention of infringement.
Contents
iii
Contents
Before You Begin vii
Warranty Information vii
Safety Summary vii
About This Manual viii
Coax Configuration
Using the Interface Card 1-3
Setting the Rotary Switch 1-4
Sending Commands to the Interface Card 1-5
Using a PC to Configure the Interface Card 1-6
Coax Command Listing 1-7
01: Buffer Size 1-8
07: Print Case 1-8
08: LU1 Language 1-9
34: Intervention Required (IR) Timeout 1-10
39: Ending Delimiter Characters 1-10
40: Beginning Delimiter Characters 1-11
41: Alternate Command Identifier 1-12
42: Buffer Hex Dump 1-12
45: SCS TRN Translate 1-13
55: Custom User Strings 1-13
60: Output Protocol 1-14
65: Character Set Selection 1-15
66: Output Port 1-15
70: Overwrite EBCDIC (SCS/LU1)
Translation Table 1-16
71: Overwrite DSC (LU3) Translation Table 1-16
72: Serial Out Baud Rate 1-17
73: Serial Out Word Length 1-17
1
4630 and 4830 Coax/Twinax Interface Card User’s Manual
iv
74: Serial Out Stop Bits 1-17
75: Serial Out Parity 1-18
98: Restore Factory Defaults, Print Self-Test, or
Restore Previously Defined Settings 1-18
99: Save Configuration in Nonvolatile Memory 1-18
Using the Advanced Features of the Interface Card 1-19
Command Pass-Thru 1-19
Custom User Strings 1-20
SCS Mode Transparent Data 1-20
Twinax Configuration
Configuring the Host 2-3
Using the Interface Card 2-3
Setting the Rotary Switch 2-4
Sending Commands to the Interface Card 2-6
Using a PC to Configure the Interface Card 2-7
Twinax Command Listing 2-8
00: Twinax Address 2-8
01: Alternate CPT Start Delimiter 2-9
02: Alternate CPT End Delimiter 2-9
04: User-Defined Strings 2-10
05: Host Language 2-11
17: Character Set 2-11
24: IBM Printer Emulation 2-12
42: Buffer Hex Dump 2-12
60: Output Protocol 2-13
66: Output Port 2-13
72: Serial Out Baud Rate 2-14
73: Serial Out Word Length 2-14
74: Serial Out Stop Bits 2-14
75: Serial Out Parity 2-15
2
Contents
v
98: Restore Factory Defaults, Print Self-Test, and
Restore Previously Defined Settings 2-15
99: Save Current Settings 2-16
Working With User-Defined Command Strings 2-16
Using Command Pass-Thru 2-17
Troubleshooting
Technical Support 3-3
Interface Self-Test 3-3
Buffer Hex Dump 3-4
Diagnostic Loopback 3-5
Twinax Self-Diagnostics 3-6
Common Problems 3-6
3
Before You Begin
vii
Before You Begin
This section introduces you to standard warranty provisions, safety
precautions, and sources of additional product information.
Warranty Information
To receive a copy of the standard warranty provision for this product,
contact your local Intermec support services organization. In the U.S.
call 1-800-755-5505, and in Canada call 1-800-688-7043. Otherwise,
contact your local Intermec sales organization.
Safety Summary
Your safety is extremely important. Read and follow all warnings and
cautions in this book before handling and operating Intermec
equipment.
Do not repair or adjust alone Do not repair or adjust energized
equipment alone under any circumstances. Someone capable of
providing first aid must always be present for your safety.
First aid Always obtain first aid or medical attention immediately
after an injury. Never neglect an injury, no matter how slight it seems.
Resuscitation Begin resuscitation immediately if someone is injured
and stops breathing. Any delay could result in death. To work on or
near high voltage, you should be familiar with approved industrial
first aid methods.
Energized equipment Never work on energized equipment unless
authorized by a responsible authority. Energized electrical equipment
is dangerous. Electrical shock from energized equipment can cause
death. If you must perform authorized emergency work on energized
equipment, be sure that you comply strictly with approved safety
regulations.
4630 and 4830 Coax/Twinax Interface Card User’s Manual
viii
About This Manual
This manual contains all of the information necessary to operate,
configure, and troubleshoot the 4630 and 4830 coax/twinax interface
card.
What You Will Find in This Manual
For Information On Refer To
Coax configuration Chapter 1, “Coax Configuration,” tells you
how configure the interface card to
communicate with a 3270-type host system
and how to use host download commands to
access the advanced features of the interface
card.
Twinax configuration Chapter 2, “Twinax Configuration,” tells you
how to configure the interface card to
connect to an AS/400 or System 3X host and
how to use host download commands to
access the advanced features of the interface
card.
Troubleshooting Chapter 3, “Troubleshooting,” instructs you
on how to clear error messages and to
troubleshoot programming and
configuration problems with the interface
card.
Other Intermec Documents
The following documents provide additional information about the
interface card and your bar code label printer.
Document Intermec P/N
4630 and 4830 Coax/Twinax Interface Card
Service Technician Instructions 065100-002
4630 and 4830 Bar Code Label Printers User’s Manual 063879
Data Communications Reference Manual 044737
Coax Configuration
1
