Intermec Sabre 1555 User manual

P/N 3-740049-01

Sabre 1555 RFID &

Bar Code Reader

Getting Started Guide

Anleitung für Einsteiger

Guia de IniciaçãoGuide de Démarrage

GuidaIntroduttivaGuía de Iniciación

Introduction

Use this Getting Started Guide to set up the Sabre 1555 RFID and Bar Code Reader for

most terminal connections and symbologies. If necessary, use the EasySet setup

software for additional configuration possibilities and terminal connections.

Basic setup

Configuración básica

Configuration de base

Grundkonfiguration

Configurazione di base

Getting Started Guide

EasySet

Full setup

Configuración completa

Configuration complète

Vollständige Konfiguration

Configurazione completa

Configuração completa

EasySet setup software

Operating

Uso

Utilisation

Betrieb

Utilizzazione

Operator’s Guide

Programmer’s

Reference Manual

Programming Information

Connect scanner cable

Scanner cable depends

on your terminal

Cables

Accessories

Standard

Version

PDT

Version

RS-232 C

Connect cable

Scanner power ON

Direct RS-232 C cable

(155557D)

P/N3-614032-00

System power OFF

System power ON

Read this code

(standard RS-232 C

PC serial port

compatible)

19200 baud, 7 data bits, even parity, 2 stop

bits, postamble = carriage return + line feed

Power supply

P/N 070826

ÎSwitch to Barcode Read Mode (PDT version shown)

Standard version -- press mode button, read display

PDT version -- press mode button + pull trigger, read display

Customize parameters (optional)

(*) = default value

9600 baud

19200 baud (*)

7 data bits (*)

8 data bits

No parity

Postamble = Carriage Return

Postamble = none

Even parity (*)

Odd parity

Postamble = Carriage Return + Line Feed (*)

RS-232 TTL

Connect cable

System power OFF

System power ON

Select RS-232 TTL

Direct RS-232 TTL cable

P/N3634032-01

Scanner power ON

19200 baud, 7 data bits, even parity, 2 stop

bits, postamble = carriage return + line feed

ÎSwitch to Barcode Read Mode (PDT version shown)

Standard version -- press mode button, read display

PDT version -- press mode button + pull trigger, read display

Customize parameters (optional)

(*) = default value

9600 baud

19200 baud (*)

7 data bits (*)

8 data bits

No parity

Postamble = Carriage Return

Postamble = none

Even parity (*)

Odd parity

Postamble = Carriage Return + Line Feed (*)

EAN 13

1234567890128

Code 128

CODE-128

Code 39

CODE-39

UPC-A, UPC-E, EAN-8, EAN-13

(UPC-A -> EAN-13)

UPC-A, UPC-E, EAN-8, EAN-13

(UPC-A -> UPC-A)

Code 39

Code 128 / EAN 128

Symbology

Disable all symbologies

Select symbology

Test

UPC-A

EasySet

Direct RS-232 C cable

(155557D)

P/N3-614032-00

Power supply

P/N 070826

Full setup with EasySet

Default setup

Connect RS-232 C cable

Scanner power ON

System power OFF

System power ON

Start EasySet software

CAUTION – Use of controls or adjustments or performance of procedures other than those specified herein may

result in hazardous radiation exposure.

VORSICHT – Bei einer anders als hier beschriebenen Verwendung der Bedienelemente oder Veränderungen oder

einer anderen Ausführung der Arbeitsabläufe kann es zu entsteht gefährlichen Strahlungen kommen.

ATTENTION – L’utilisation de contrôles/commandes ou de réglages ou l’exécution de procédures autres que ceux

précisés dans le présent document peuvent provoquer une exposition dangereuse aux radiations.

Laser warnings

Fix these warning labels onto the product if they are not already present.

The Sabre 1555 has a maximum laser output of 1mW at 630-680 nm and complies with the following safety

standards:

USA: CDRH - Class II Laser Product (CFR 21 Subpart J)

IEC 825-1 EN 60825-1 - Class 2 Laser Product

Cole as etiquetas de precaução no equipamento.

Un’etichettadiavvisoperillaserèdaapplicaresulprodotto.

Collez les étiquettes d’avertissement sur votre produit.

Bringen Sie Warnetiketten auf dem Produkt an.

Fije la etiqueta de advertencia en el producto.
