Intermec IV6 User manual

Installation

IV6

Portable Reader

Instructions

Power Cable Kit

2 IV6 Portable Reader Power Cable Kit

Power Cable Kit (p/n: 203-714-001)

Packing List

Ensure you have received these items:

SIV6 Power Cable Kit Installation Instructions

S17-Position cable assembly (p/n: 236-040-001)

SFuse holder

S5 Amp./250 volt fast acting fuse

S3/8” heat shrink tubing (6 inches)

S1/4” heat shrink tubing (6 inches)

SCable ties (6)

SAdjustable cable clip

S2-Pin circular connector

3

IV6 Portable Reader Power Cable Kit

Instructions

1Cut back the cable assembly jacket about 18 inches.

2Cut the purple wire and solder in the fuse holder. Install the

5 amp. fuse into the holder.

3Attach heat shrink tubing to the connections on the fuse

holder. Use a heat gun to seal the heat shrink tubing.

4Usethetiewrapsonthecableassemblywires.Attachthe

cord clip to an appropriate location to ensure the cables are

not obstructing the user’s operation of the equipment.

5Attach the purple wire and blue wire to the 2-pin connector.

Attach heat shrink tubing where the connector and wire as-

sembly meet. Use a heat gun to seal the heat shrink tubing.

6Connect the 2-pin connector to the Intermec power supply

(p/n: 851-041-002). Connect the circular data connector to

the Reader.

7The remaining wires on the cable are data lines (RS-232) and

general purpose input/output lines. Refer to the GPIO Pin

Function/Assignment Table in the IV6 Portable Reader

Quick Start Guide (p/n: 962-054-119) for details.

8Connectthecablefromthepowersupplytothevehiclepow-

er source.

Corporate Headquarters

6001 36th Avenue West

Everett, Washington 98203

U.S.A.

tel 425.348.2600

fax 425.355.9551

www.intermec.com

IV6 Power Cable Kit Installation Instructions

*962-054-127A*

P/N 962-054-127A

e2005 by Intermec Technologies Corporation. All rights reserved.
