Insignia NS-LED4W18 User manual
BRIGHT
DIM
PACKAGE CONTENTS
• LED tape light
• Double-sided tape
• Quick Setup Guide
FEATURES
• Premium white LEDs produce bright, natural light
• Multi-step dimmer adjusts to the brightness level you
want
• Self-adhesive backing attaches to TVs, cabinets, or other
spaces for quick, custom lighting
• Reduces eye strain from TVs and monitors while
enhancing image contrast
• Lights powered through USB (on your TV or computer) or
with a USB power adapter (not included)
Before using your new product, please read these instructions to prevent any damage.
USING YOUR TAPE LIGHT
Shortening your tape light
• Use a pair of scissors to cut on a cut line. Cut lines are
about 1.3 in. (3.3 cm) apart.
Warning: Do not cut the silver solder markings. Only cut in the
center of the copper-colored pads, as shown.
Attaching your lights
1Peel the adhesive backing o the lights, then adhere the
lights where you want them.
2Attach the double-sided tape to the back of the light
control, then adhere it where you want it. (optional)
Connecting to power
• Place the tape light where you want it, then connect the
USB connector to your TV, computer, or other USB power
source.
QUICK SETUP GUIDE
LED Tape
Light
NS-LED4W18
USB
connector
Wire
Light
controls
LED
light strip
Cut
line
Brighten lights
Turn on/o
Dim lights
Light controls Cut line
V2 ENGLISH 17-0453
Adjusting the lights
Note: Tape light will retain the last brightness setting used
when turned o, then back on.
• Press (POWER) to turn the tape light on and o.
• Press (BRIGHT) or (DIM) to increase or decrease
the brightness. There are eight light levels.
SPECIFICATIONS
• Input: 5V DC, 1A
Minimum specications for USB power supply (not
included): 5V DC, 0.5A (1.0A or greater recommended)
• Length: 4 ft. (1.2 m)
TROUBLESHOOTING
LEDs will not turn on.
• Press the power button to make sure your light is turned
on, then press (BRIGHT) to increase the brightness.
• Make sure that your lights are connected to a working
USB port or power outlet. If connected to a computer,
turn on your computer.
LEDs icker or turn on and o.
• Make sure that your lights are plugged into a working
power outlet or USB port. Try plugging into a dierent
power source.
• Make sure that the cable is not damaged.
SAFETY INFORMATION
• To avoid damage to the light strip, do not twist or bend
the light strip 90° sharply.
• Do not cut the silver solder markings. Only cut in the
center of the copper-colored pads.
• Do not plug in your lights when they are coiled. This can
generate excess heat which can damage the product or
connected device.
ONEYEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
For customer service, call 1-877-467-4289 (U.S. and
Canada) or 01-800-926-3000 (Mexico)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2017 Best Buy. All rights reserved.
Made in China
