Insignia 10-1089 User manual

8" Digital Picture Frame

NS-DPF8IP

User Guide

www.insigniaproducts.com

NS-DPF8IP

Digital Picture Frame

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Setting up your frame . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Using your frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

6-month limited warranty . . . . . . . . . . . . . . . . . . . . . . .51

Introduction

Congratulations on your purchase of a high-quality Insignia

product. Your new digital picture frame is designed for

reliable and trouble-free performance.

NS-DPF8IP

www.insigniaproducts.com

Safety information

Always follow these basic safety precautions when using

your digital picture frame. This will reduce the risk of fire,

electric shock, and injury.

Placement—To prevent fire or electric shock, do not expose

this digital picture frame to rain or moisture. To prevent it

from falling do not place it on an unstable cart, stand, tripod,

bracket, or table. Keep the unit away from strong magnets,

heat sources, direct sunlight, and excessive dust.

Installation—Make sure that the digital picture frame is used

in accordance with the instructions and illustrations

provided in this manual.

Objects and liquids—Do not push objects of any kind into

the digital picture frame through openings. Do not spill or

spray liquid of any kind on or in the digital picture frame (this

may result in a fire or electric shock). Do not place anything

heavy on the unit. To ensure proper ventilation and proper

operation, never cover or block the slots and openings with

a cloth or other material.

Disassembly—Do not attempt to disassemble the frame.

There is a risk of electric shock. Contact qualified service

personnel if your digital picture frame is in need of repair.

Cleaning the digital picture frame—When cleaning, make

sure the frame is unplugged from the power source. Use the

supplied cleaning cloth, or a cloth slightly dampened with

water for cleaning the exterior of the frame only.

Warnings

To reduce the risk of fire or shock hazard, do not expose the

frame to rain or moisture and unplug the frame during

lightning storms.

To prevent the risk of electric shock, do not remove the

cover. There are no user-serviceable parts inside. Refer all

servicing to qualified personnel.

There is a risk of explosion if the battery is incorrectly

replaced. Replace only with the same or equivalent type of

battery.

www.insigniaproducts.com

Features

• iPod®/iPhone® docking with audio/video playback.

• 2 GB internal memory.

• Displays digital pictures and plays music and videos

without a computer.

• Displays pictures directly from an inserted memory

card or USB device (not included).

•Built-inalarmclock.

• Bright, clear TFT LCD screen.

• Compatible with a wide variety of memory cards,

including:

• Secure Digital™ (SD)

•SDHC™

•CompactFlash®

• MultimediaCard (MMC™)

•MemoryStick®

• Memory Stick PRO Duo™ (requires the supplied

adapter)

•xD™

• microSD™ (requires an adapter - not included)

• Compatible with USB flash drives.

• Mini-USB connector to connect the digital picture

frame to your PC.

• Multi-image mode displays multiple pictures at the

same time in a slideshow.

• Auto Rotate–pictures are rotated based on picture

file EXIF data.

• On-frame storage for the supplied infrared remote

control.

Package contents

• Digital picture frame

• AC power adapter

• Memory Stick PRO Duo adapter

•QuickSetupGuide

• Remote control with battery (CR2025)

•Cleaningcloth

NS-DPF8IP

www.insigniaproducts.com

Connectors

#Description

1 Memory card slot, supports:

• Secure Digital™ (SD)

•SDHC™

• MultimediaCard (MMC™)

•MemoryStick®

• Memory Stick PRO Duo™

•xD™

•microSD™

2 Memory card slot. Supports CompactFlash (CF)

3 Headphone jack (does not operate with iPhone)

4 iPod/iPhone dock

5USBport

6MiniUSBport

7 Line in connector

Right side view Left side view

Back view

www.insigniaproducts.com

Top view

You can access most of the frame’s features by using either

the buttons on top of the frame or by using the remote

control. Selecting files for copying, deleting, or viewing

requires the remote control, and the instructions in this

guide refer to remote control buttons (except where noted).

8 DC 5 V power connector.

9 Remote control slot

# Button Description

1 STANDBY/ON Press to turn your digital picture frame on. Press

again to enter standby mode.

2 VOL +/– Press to increase (+) or decrease (–) the volume

during music/video playback.

3 SNOOZE/

ALARM SET

Press to enter alarm clock setup or activate the

snooze feature.

#Description

11 12

NS-DPF8IP

www.insigniaproducts.com

4 Light sensor Adjusts the display brightness or auto standby to

room lighting.

5 Back Press to return to the previous menu.

6 / / / Press to navigate through the menus or to select

the next or previous picture/song/video.

7 (enter) Press to select menu items.

8 (play/

pause)

During playback, press to pause or resume the

video, audio, or iPod file slideshow.

9 SLEEP TIMER Press to set up the sleep timer function, which

automatically puts the digital picture frame into

Clock/Alarm mode after a preset period of time.

10 HOME Press to return to the main menu or to exit from

iPod Direct Control.

11 DISPLAY Press to choose the display mode. Options are

Normal, Multi-Image, Clock, and so on.

12 MENU Press to open the Setup menu.

# Button Description

www.insigniaproducts.com

Remote control

# Button Description

1 DISPLAY Press to choose the display mode.

Options are Normal, Multi-Image, and

three different photo + clock or clock/

Date display modes.

2 BACK Press to go back a screen or to close

setup menus.

NS-DPF8IP

www.insigniaproducts.com

3 ENTER Press to select the highlighted option.

4 / / / Press to navigate through the menus

or to select the next or previous

picture/song/video.

5 MENU Press to display the Setup menu.

6 SELECT Press to select a picture or file to copy

or delete.

7 (play/pause) Press to pause or resume playback.

8 (thumbnail/folder) Press to enter Thumbnail mode, or to

display files and folders.

9 HOME Press to return to the main menu.

10 ZOOM Press to magnify the picture.

11 VOL +/– Press to increase (+) or decrease (–) the

volume during music/video playback.

12 SLEEP TIMER Press to set up the sleep timer

function, which automatically puts the

digital picture frame into standby

mode after a preset period of time.

# Button Description
