Insignia NS-DPF8TR User manual

8" Digital Picture Frame

NS-DPF8TR

User Guide

NS-DPF8TR_10-0794_MAN_ENG_V3.fm Page 1 Wednesday, July 28, 2010 8:40 AM

NS-DPF8TR_10-0794_MAN_ENG_V3.fm Page 2 Wednesday, July 28, 2010 8:40 AM

www.insigniaproducts.com

NS-DPF8TR

Digital Picture Frame

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Setting up your frame . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Using your frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

6-month limited warranty . . . . . . . . . . . . . . . . . . . . . . .49

Introduction

Congratulations on your purchase of a high-quality Insignia

product. Your new digital picture frame represents the state

of the art in digital picture frame design and is designed for

reliable and trouble-free performance.

NS-DPF8TR_10-0794_MAN_ENG_V3.fm Page 3 Wednesday, July 28, 2010 8:40 AM

NS-DPF8TR

www.insigniaproducts.com

Safety information

Always follow these basic safety precautions when using

your digital picture frame. This will reduce the risk of fire,

electric shock, and injury.

Placement—To prevent fire or electric shock, do not expose

this digital picture frame to rain or moisture. To prevent it

from falling do not place it on an unstable cart, stand, tripod,

bracket, or table. Keep the unit away from strong magnets,

heat sources, direct sunlight, and excessive dust.

Installation—Make sure that the digital picture frame is used

in accordance with the instructions and illustrations

provided in this manual.

Objects and liquids—Do not push objects of any kind into

the digital picture frame through openings. Do not spill or

spray liquid of any kind on or in the digital picture frame (this

may result in a fire or electric shock). Do not place anything

heavy on the unit. To ensure proper ventilation and proper

operation, never cover or block the slots and openings with

a cloth or other material.

Disassembly—Do not attempt to disassemble the frame.

There is a risk of electric shock. Contact qualified service

personnel if your digital picture frame is in need of repair.

Warnings

To reduce the risk of fire or shock hazard, do not

expose the frame to rain or moisture and unplug

the frame during lightning storms.

To prevent the risk of electric shock, do not remove

the cover. There are no user-serviceable parts inside.

Refer all servicing to qualified personnel.

There is a risk of explosion if the battery is

incorrectly replaced. Replace only with the same or

equivalent type of battery.

NS-DPF8TR_10-0794_MAN_ENG_V3.fm Page 4 Wednesday, July 28, 2010 8:40 AM

www.insigniaproducts.com

Cleaning the digital picture frame—When cleaning, make

sure the frame is unplugged from the power source. Use

only cleaners specifically designed to clean LCD panels, or a

cloth slightly dampened with water for cleaning the exterior

of the frame only.

Features

• Displays digital pictures (JPEG format) and digital

slideshows without a computer.

• Multi-image mode displays multiple pictures at the

same time in a slideshow.

• Plays music (MP3, AAC, or WMA formats) alone or

with a picture slideshow.

• Plays videos (MJPEG and MPEG4 in .AVI and .MOV

formats)

• Bright, clear TFT LCD screen.

• Compatible with a wide variety of memory cards,

including SD, SDHC, MMC, MS Pro Duo, CF, and xD.

• Compatible with USB flash drives.

• On-frame button controls and infrared remote

control.

• 1 GB internal memory.

Package contents

•8”Digitalpictureframe

• AC power adapter

• User Guide

• Quick Setup Guide

• Remote control with battery (CR2025)

• Remote control holder

• Cleaning cloth

•USBcable

• Black and white picture mats

• Two interchangeable frames

• MS Pro Duo adapter

NS-DPF8TR_10-0794_MAN_ENG_V3.fm Page 5 Wednesday, July 28, 2010 8:40 AM

NS-DPF8TR

www.insigniaproducts.com

Connectors

#Description

1 Power On/Off switch

2 DC 9 V power connector. Plug the AC adapter in here.

3 Memory card slot. Supports: Memory Stick, Memory Stick

Duo, Memory Stick PRO, Memory Stick PRO Duo, Multimedia

Card (MMC), Secure Digital (SD and SDHC), microSD, miniSD,

and xD.

4 Mini USB port

5CFcardslot

6 Standard USB port

ON OFF

NS-DPF8TR_10-0794_MAN_ENG_V3.fm Page 6 Wednesday, July 28, 2010 8:40 AM

www.insigniaproducts.com

Front and back

IR sensor

NS-DPF8TR_10-0794_MAN_ENG_V3.fm Page 7 Wednesday, July 28, 2010 8:40 AM

NS-DPF8TR

www.insigniaproducts.com

Top

You can access most of the frame’s features by using either

the buttons on top of the frame or by using the remote

control. Selecting files for copying, deleting, or viewing

requires the remote control, and the instructions in this

guide refer to remote control buttons (except where noted).

#Description

1Speaker.

2 Remote control holder.

3 Holes for mounting the holder or for mounting the digital

picture frame on a wall.

4 Slot for clock backup battery (CR2025).

# Button Description

1 MENU Press to open the Setup menu.

2 Left arrow Press to move the menu selection left or up, to

display the previous picture, or to play the previous

music file.

3 Right arrow Press to move the menu selection right or down, to

display the next picture, or to play the next music

file.

NS-DPF8TR_10-0794_MAN_ENG_V3.fm Page 8 Wednesday, July 28, 2010 8:40 AM

www.insigniaproducts.com

4 Enter/

Play/Pause

Press to select menu items. During a slideshow,

press to pause or resume.

5 Up arrow In Menu mode, press to navigate up. In Playback

mode, press to increase the volume.

6 Down arrow In Menu mode, press to navigate down. In

Playback mode, press to decrease the volume.

7 Back Go back to previous selection or screen.

# Button Description

NS-DPF8TR_10-0794_MAN_ENG_V3.fm Page 9 Wednesday, July 28, 2010 8:40 AM

NS-DPF8TR

www.insigniaproducts.com

Remote control

#Button Description

1 MENU Press to display the Setup menu.

2 SLIDE SHOW Press to start a slideshow or toggle the

multi-image Display mode.

3 (Up) VOL+ Press to move the selection up or to

raise the volume.

NS-DPF8TR_10-0794_MAN_ENG_V3.fm Page 10 Wednesday, July 28, 2010 8:40 AM
