Read me ﬁrst

Payzone iCT250 Terminal

Installation Guide

We hope you enjoy

using your new Payzone

iCT250 Terminal!

iCT250

A Quick Guide to Your New

Payzone iCT250 Terminal

Hello…

welcome to Payzone, glad to have

you on board.

What’s inside…

Plugging in the power supply

Connect the correct connection

Going through installation steps

Need More Help?

Let’s get you started

Step 1 - Plugging in the power supply

Plug the power supply into the junction box in the circular connection, as

per below;

Step 2 - Establish how the terminal needs to be set up (Phone Line or Broadband)

Decide how you would like to use the machine, either through the phone

line or broadband?

Step 3 - Connect the correct connection method

Phone Line

Connect the phone line into the below port (labelled with ‘phone symbol

and IN’on the junction box), shown below.

Power Supply

Phone Line

Broadband

Connect the Ethernet cable into the broadband router and the other end into

the port (labelled ‘ETH’), shown below.

Step 4 - Going through the installation mode steps

Phone Line Connection

Does the Tel. Line have

Call Waiting or 1571?

Enter=Yes Clear=No

Press ENTER on

Telephone(PPP).

Is there call waiting or

1571?

Type in the *6 digit

Payzone Merchant

number and press ENTER.

Press ENTER.

Is there a dial preﬁx on

the line?

The terminal will then

dial GEMS.

Terminal Installation

Plug in Phone Line

and then press ENTER

Terminal Installation

Key In Merchant No.

(6 digit number)

and then press ENTER

Dial Preﬁx Required?

Enter=Yes Clear=No

Dialing GEMS

Tel: 08431 786527

DPP 100 Preﬁx NONE

Please Wait…

Ethernet port

Connection method

Telephone(PPP)

Local Network

Once this has been completed the terminal will display the READY prompt

showing the merchant number. Please try a test transaction of 1p to ensure

the terminal is fully installed.

*6 digit Payzone Merchant number can be found on your ‘Payzone Welcome’

email.

Broadband Connection

Dialing GEMS

Tel: 08431 786527

DPP 100 Preﬁx NONE

Please Wait…

Press ENTER on local

network.

The terminal will then

dial GEMS.

Press ENTER.

Type in the *6 digit

Payzone Merchant

number and press ENTER.

Terminal Installation

Plug in Newtork

and then press ENTER

Terminal Installation

Key In Merchant No.

(6 digit number)

and then press ENTER

2 3

Connection method

Telephone(PPP)

Local Network

Once this has been completed the terminal will display the READY prompt

showing the merchant number. Please try a test transaction of 1p to ensure

the terminal is fully installed.

*6 digit Payzone Merchant number can be found on your ‘Payzone Welcome’

email.

0018 • BSG • PZ iCT250 V1 • 01/17

We’re here to help.

For any installation queries, please get in touch with

our installation team on:

01472 255 750

Opening Hours: Monday – Thursday 08:30am - 19:30pm

Friday 08:30am - 17:00pm.

Get in touch

01472 255 750

Keep updated…

www.payzone.co.uk
