Ikelite 9523.61 User manual

Tray with Handle(s)

Instruction Manual

9523.61 Tray with Single Handle

9523.62 Tray with Dual Handles

Thank you for choosing Ikelite equipment. Please read this instruction

manual completely before attempting to operate or dive with this product.

Package Contents

12-24 houlder Washer (Qty. 2)

1/4” Nut (Qty. 2 with Dual Tray)

12-24 x 1/2” crew (Qty. 2)

Flat Washer (Qty. 2 with Dual Tray)

plit Lock Washer

1/4-20 x 1/2” crew

(Qty. 2)

3/8-16 Nut

(Qty. 2)

1/4-20 houlder Washer (Qty. 2)

Quick Release Handle

(Qty. 2 with Dual Tray)

OLYMPUS

CANON A

CANON B

CANON C

SONY B

SONY A

Panasonic

Tray Inserts

Front o Tray

mall Flat Washer

(Qty. 2 with Dual Tray)

Insert handle into the tray as shown below. Attach and tighten to tray

using flat washer and 1/4” nut. The handle is removable in the event that

replacement is necessary. The handle is not intended to be removed for

travel. The completed assembly may be removed and replaced easily for

travel.

Attaching Handle to the Tray

1/4” Nut

Threaded Handle tem

Flat Washer

Handle

Guide

Quick

Release

Handle

tem Hole

mall Hole

mall Flat Washer

Match your housing

to the correct tray

insert as shown.

The insert cut-out

should match the

bottom of the

housing tripod mount base plate,

diagram A. Remove protective backing to expose adhesive and attach

insert to recess in the center of the tray, diagram B. Attach tray to

housing through Center Hole using 1/4-20 x 1/2” crew and plit Lock

Washer, diagram C.

Canon, Olympus, Panasonic, and Sony Housings

OLYMPUS

CANON A

CANON B

CANON C

SONY B

SONY A

Panasonic

SONY B

SONY A

Panasonic

Diagram A Diagram B

SONY B

SONY A

Panasonic

Protective

Backing

Diagram C

plit Lock Washer

1/4-20 x 1/2” crew

Front o Tray

Tray Inserts

Center

Hole

1/4-20

Threaded

Mounting

Hole

Attach tray to Ikelite housing using two 12-24 x 1/2” crews and

houlder Washers for housings with female-threaded mounting systems.

For male-threaded mounting systems with a housing serial number

less than 37,101, order spacer 9523.09. Tighten tray with spacer using

the two 3/8-16 nuts. 12-24 x 1/2” crew

houlder Washer

Housing Mount

This product is warranted against any manufacturing defects for a period

of one (1) year from the original date of purchase. Defective products

should be returned to Ikelite postage paid. Ikelite will, at its sole

discretion, repair or replace such products, and will return to customer

postage paid. All other claims of any nature are not covered. Except as

mentioned above, no other warranty expressed or implied applies to this

Ikelite product.

Ikelite Underwater Systems

50 West 33rd Street

Indianapolis, IN 46208 USA

9523.61.62_Tray_Handle(s)_4-0113

Limited Warranty

Accessory Mounting Points

The bottom of the tray features two 1/4-20 threaded mounting holes for

attachment of a Pro-Video battery pack, diagram B, page 3.

Ikelite Housings
