Igloohome RM2F User manual
1
Version 0.1 07/22
User guide
Gate Lock.
We’re always updating our guides because we want to keep things fresh! You can visit
igloohome.co/support periodically to view the latest version, unless, this is the latest
version. Hello you, igloohomie from the future, wow!
Hi there!
We’re so glad you’ve decided to join us on this journey to create a world
without keys. You’re officially an igloohomie!
In this guide, you’ll find everything you need to get started with your lock.
We hope that we’ve been as comprehensive and informative as possible.
Afterall, we’re here to make life easier for you (at least when it comes to
your home’s access).
If you do not find what you’re looking for, we’re working on updating it.
Or… you could reach out to us at support@igloohome.co because we
love interacting with you! Speaking of interaction, let’s stay connected
regardless. Why don’t you join the community of igloohomies worldwide?
Watch us on
YouTube
Maybe network
with us on LinkedIn
Follow us on
Facebook
Or stalk us on
Instagram
Table of Contents
What’s Included 4
Specifications 5
Lock Anatomy 6
Installing/Replacing Batteries 7
User Guide
Features 8
Modes of Access 10
App Onboarding 14
Managing Access 16
Manage Ecosystem 20
Manage Lock Features 22
Manage Lock Settings 24
View Activity Logs 25
Audio and LED Indications 26
Intergrations 27
Other services 28
Troubleshooting 31
4
What’s Included
Front Assembly Back Assembly Base Plate
AA Alkaline Batteries x4
Installation Guide & Drill Sheet Screws
RFID Tags x2
RFID Stickers x2
Shim Plates
Striker & Striker Cover
X 4
X 4
X 2
X 2
X 2
X 6
Quick Start Guide (QSG)
Mechanical keys x 2
1.5mm 2.5mm 3.5mm
5
Model RM2F (With Fingerprint) / RM2 (Non-fingerprint)
Weight Net: 1.7kg, Gross: 1.8kg
Front Assembly Material ABS, Aluminum DC, Acrylic
Back Assembly Material ABS, Aluminum DC, EPDM, Zinc die-cast
Modes of Access (Entry) PIN codes, Bluetooth keys, RFID tags & stickers,
Fingerprint (only applicable to RM2F)
Modes of Access (Exit) Bluetooth keys, Key Fob, Mechanical keys
Provided RFID Tags & Stickers RFID tags - 1 pair | RFID stickers - 1 pair
RFID Tags & Stickers Capacity 100
Fingerprint capacity 100 (only applicable to RM2F)
Power Type 4 AA alkaline batteries
Battery Life Up to 10 months
Emergency Power 9V Alkaline Battery
Battery Operating Temp. -10°C to 50°C / 14°F to 122°F
Operation Temp. -25°C to 55°C / -77°F to 131°F
Certifications IP54
Protocols Bluetooth 4.2, algoPIN™ technology
Usage Advised to be installed under sheltered areas,
not to be exposed to wet weather conditions.
Specifications
Tip: Use recommended battery brands such as Duracell, Energizer, or Panasonic for the best performance and
lifespan of the lock. Do not use heavy duty, Everready, GP, or rechargeable batteries.
Side
24mm 40mm
Front
179mm
73mm
Back
197mm
77mm
6
Front & Back Assembly
Touch Screen
Keypad
Unlock
9V Jumpstart
Clear
Multi-Function
Button / Lock
Fingerprint
Module*
*Fingerprint function available for Gate Lock with Fingerprint only.
Low Battery
Indicator Battery Cover
User Guide
Lock Anatomy
LED Indicator
RFID Reader
Battery Cover Release
Keyhole
7
Installing/Replacing Batteries
Install or replace with 4 new
AA alkaline batteries
Loosen the screw with Philips screwdriver
(not provided) and remove battery cover.
Put back the battery cover and secure it with the screw.
Battery Cover
8
Features
Auto Lock
Automatically locks once the gate is
shut to give you greater peace of mind.
Sequential Unlock
Unlock both your gate and door at the
same time.
Master Bluetooth Key
The lock unlocks with Bluetooth via
the app.
Master PIN Code
The lock unlocks with a permanent
Master PIN Code.
Guest PIN Code
The igloohome mobile app can
generate multiple types of Guest Pin
codes, e.g. One-Time, Permanent,
Recurring & Duration.
PIN / Bluetooth Unlock
RFID
The lock is able to register up to 100
key cards.
Guest Bluetooth Key
The igloohome mobile app can
generate and share Bluetooth Guest
keys.
Lock
Battery
Low Battery Alert
Intuitive audio and visual alerts will
prompt you to change the batteries
when it runs low.
Emergency Jumpstart
Easily jumpstart the lock with a 9V
battery if batteries are drained.
Fingerprint
The lock is able to register up to 100
unique fingerprints. Only available on
RM2F.
Auto Unlock
Automatically unlock your door when
the lock senses your app within the set
Bluetooth range.
9
Features
Security Lockout
Keypad is disabled after several
incorrect access attempts to ensure
your property is always secure.
Others
Security / Alarms
Decoy PIN Code
Heighten security and throw o
onlookers by entering random digits
before your actual PIN code.
Tamper Alarm
The lock will sound an alarm if it is
being pried from the door to alert and
deter potential tampering attempts.
Volume Control
Adjust the volume according to your
preference. Select from levels 0
(mute) to 5 (loudest).
Privacy Mode
Disable all modes of access except
the Master Bluetooth key to prevent
unwanted entries into your property.
Obstruction Alarm
The lock will sound an alarm if the
bolt tongue cannot be extended or
retracted fully to alert the user of any
obstructions.
Intrusion Alarm
The lock will sound o when the door
is forced open while the bolt is still
extended.
Quiet Unlock
Mute audio indicators while unlocking
for quieter access to prevent
disturbance.
Learn how to access, activate, and deactivate these features from pages 22 - 23.
10
Modes of access
1. Wake the lock up by pressing the touchscreen keypad.
2. Enter a valid PIN code, with or without decoy digits, followed by
3. The LED indicator on the lock will flash green when it is successfully unlocked. You will
also hear four ascending tones.
Modes of access (Entry) PIN codes, Bluetooth keys, RFID tags & stickers,
Fingerprint (only applicable to RM2F)
Modes of access (Exit) Bluetooth keys, Key Fob, Mechanical keys
Master PIN Code Permanent PIN code that works every time.
Can be customized via Bluetooth by lock owner.
Guest PIN Code
Generated via algoPIN™ technology or customized via
Bluetooth by lock owner. Includes One-Time, duration,
permanent and recurring PIN codes.
PIN Code
As the owner of the lock, you can use the Master PIN code, issue Guest PIN codes, and test
the lock during set-up with the Factory PIN code.
