Configure a Huawei router to connect to the Internet using GigSky - 1

Configure a Huawei router to connect to the Internet using GigSky

The Huawei E5776s Wi-Fi router purchased from GigSky is pre-configured with the correct APN

(Access Point Name) setting of gigsky, which enables it to connect to the Internet correctly.

Sometimes, when moving between countries, the APN will be reset to the factory default. When

this happens, the router will not connect properly, and you will either get no data, or you may see a

web page prompting you to set the APN on your computer or mobile device. If you experience

either of these conditions, then you will need to select the correct APN on the router. To do this,

carry out the following steps:

Connect to the router's Wi-Fi network

Connect to the router’s Wi-Fi network using your computer, tablet or smartphone.

Note: The default Service Set IDentifier (SSID) and wireless network encryption key are engraved

into the bottom of the device.

Connect to the router's admin interface

1. Open http://192.168.1.1 in your web browser

2. Click the “Log In” link: Username - admin, Password - admin

Note: If the device determines that your password is too weak, it will prompt to change the

password. You can choose to ignore this prompt.

Configure a Huawei router to connect to the Internet using GigSky - 2

Check the Profile (APN) settings

1. Click Settings

2. Click Profile Management

3. Verify that the Profile name is set to GigSky.

Note: If the Profile name is something else, select GigSky from the Profile name dropdown menu

and click Apply. If there is no profile named GigSky, refer to the step called Set up a new profile for

instructions on how to create it.

Configure a Huawei router to connect to the Internet using GigSky - 3

Set up a new profile

Click New Profile.

Configure a Huawei router to connect to the Internet using GigSky - 4

Enter profile values

1. Profile name - GigSky

2. APN - Static

3. APN name - gigsky

4. Leave the User name and Password fields blank, and click Save.

Configure a Huawei router to connect to the Internet using GigSky - 5

Ensure that GigSky is the default profile and is selected

Verify Network Settings

1. Network - Auto

2. Network Search - Auto

Configure a Huawei router to connect to the Internet using GigSky - 6

Verify Mobile Connection

1. Connection mode - Auto

2. Data roaming - Enable

Configure a Huawei router to connect to the Internet using GigSky - 7

Reboot the device

1. Click System

2. Click Reboot

3. Click the button labeled Reboot

Configure a Huawei router to connect to the Internet using GigSky - 8

Verify that the device is connected to the Internet using the admin interface

When the router has restarted, reconnect to the router’s Wi-Fi network using your computer, tablet

or smartphone and open http://192.168.1.1 in your web browser. If the globe symbol is blue, the

device is connected to the Internet.

Verify that the device is connected to the Internet using the LCD screen

If the globe symbol is displayed on the LCD screen of the device, it is connected to the Internet.
