Huawei RT-16ASE User manual

Quidway® AR 28 Router Asynchronous Serial Port Module

Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 1

http://datacomm.huawei.com

Quidway® AR 28 Router Asynchronous Serial Port Module

Overview

The asynchronous serial port module of the AR28 router includes 3-port AS module and 8-/16-port

ASE module.

The function of ASE module is the same as that of AS module, mainly responsible for transmitting

and processing the asynchronous serial port data flow. The largest rate of each asynchronous

serial port reaches 115.2 Kbps. It can support terminal access service and asynchronous private

line. Moreover, the asynchronous serial port can serve as the middle-/small-sized ISP dialup

access server. It can interconnect multiple LANs through the asynchronous dialup line.

Specifications

The specifications of asynchronous serial port module of the AR28 router are shown in the table.

Product Number Interface Type Description

RT-SIC-3AS RJ45

3-port asynchronous serial port card

RT-8ASE RJ45

8-port asynchronous serial port enhanced module (RJ45)

RT-16ASE RJ45

16-port asynchronous serial port enhanced module (RJ45)

Interface property

The properties of 3AS interface are shown in the following:

SIC-3AS interface property

Attribute Description

Connector type RJ45

Connector quantity 3

Cable type AUX cable

Quidway® AR 28 Router Asynchronous Serial Port Module

Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 2

http://datacomm.huawei.com

Attribute Description

Interface standard and

working mode RS232

Minimum baud rate(bps) 300

Maximum baud rate(bps) 115.2k

Service supported

Modem dialup

Backup

Terminal access service

Asynchronous leased line

The properties of 8ASE and 16ASE interfaces are shown in the following:

Description

Attribute FIC-8ASE FIC-16ASE

Connector type RJ45

Connector quantity 8 (FIC-8ASE)

16 (FIC-16ASE)

Interface standard and working

mode RS232

Cable type AUX cable

Ethernet standard network cable

FIC-8ASE/FIC-16ASE dumb terminal cable

Minimum baud rate(bps) 300

Maximum baud rate(bps) 115.2k

Service supported

Modem dialup

Backup

Terminal access service

Asynchronous leased line
