Huawei HG532D User manual

Modem Conguration Guide

HG532D

Conguring in Layer2 PPPoE for Windows 7

IMPORTANT MESSAGE

Your modem has been pre-conﬁgured, you do not need to follow each step of the set-up guide but should retain this

document in case you need to manually conﬁgure your equipment.

To conﬁgure your PC/Laptop with your wireless password including changing your wireless password, please

proceed to step 4.

Contents

1. Physical Connection

2. Network Conﬁguration

3. Conﬁguring Internet

4. Conﬁguring Wireless

5. IPTV

6. Change of Password

1. PHYSICAL CONNECTION

Have your router powered on and connected directly to your PC via Ethernet Cable before you begin, as these

instructions are based on wired Ethernet connection

2. NETWORK CONFIGURATION

PPPoE connection does not require you to have an IP address or DNS settings manually encoded on your network card.

PPPoE connection uses authentication to establish the Internet connection and once connected your modem will be

assigned an IP and DNS settings from TPG.

To begin, your PC needs to receive a private IP address from the router. Most ADSL routers have DHCP enabled by

default that will take care of this.

To ensure your Network Card is ready for this, please follow the following steps:

A. Click Start -> Control Panel -> Network and Internet ->

Network and Sharing Center -> Change adapter settings

B. Right click on Local Area Connection and select Properties

HG532D

Modem Conguration Guide

C. Click on Internet Protocol Version 4 (TCP/IPv4), and then click

Properties

D. Ensure “Obtain an IP address automatically” is selected

E. Ensure “Obtain DNS server address automatically” is selected

F. Click OK

3. CONFIGURING ROUTER

A. Open your browser and in the address bar type

http://192.168.1.1 and press Enter

B. Enter admin for both the username and password and click Login.

If you have changed the login credentials, please enter the current

username and password for your router interface.

HG532D

C. You will see the screen as shown on the right.

D. Enter your TPG username and password. Click Next.

E. You can change your WiFi details or elect to keep the default settings. The default WiFi SSID is printed on the

sticker underneath your modem. The WiFi password is set to your TPG ADSL password by default. Click Next

F. Quick Setup complete!

Modem Conguration Guide HG532D

4. CONFIGURING WIRELESS

Things you need to know before you begin:

By default the modem that you purchased from TPG is conﬁgured with the following wireless security settings:

SSID (name for the wireless connection): TPG-xxxx (xxxx is a random 4 digit alphanumeric code printed on the sticker

underneath your modem)

Authentication Type: WPA-PSK/WPA2-PSK

Encryption: TKIP/AES

Pre Shared Key: initially conﬁgured to be the same as your TPG password. You can enter your own text as an option.

To use Wireless, ensure that you already have set up your wireless adapter.

A. Click Start -> Control Panel -> Network and Internet -> Network and Sharing Center -> Change adapter settings

B. Right click on Wireless Network Connection and

click ‘Connect/Disconnect’

Modem Conguration Guide

C. Find the SSID (network name) of your router and click

Connect. By the default, the network name should be

TPG-xxxx (xxxx is a random 4 digit alpha numeric code).

D. You will now be prompted to enter your WPA Key /

wireless password. This is the same as your TPG

password if you did not change it on the router.

E. Click OK.

F. You should now see your status as ‘Connected’.

HG532D

5. IPTV

Your modem is pre-conﬁgured with TPG IPTV settings.

Should you require further assistance please contact the TPG Helpdesk on 13 14 23 option 2.

6. CHANGE OF PASSWORD

For security purposes we highly recommend that you change your password if you are using your default or if you believe your

password security has been compromised.

For password information, please visit: www.tpg.com.au/support

PLEASE NOTE:

Each time your router is powered on, it will initialize this automated authentication process after which your router will receive

a public IP address (ﬁxed or dynamic depending on your plan) and DNS settings from TPG.

13 14 23tpg.com.au/support
