Huawei E8231 Technical specifications

Product Description

HUAWEI E8231 HSPA+ Wingle

V100R001

Issue

Date

2013-08-05

HUAWEI TECHNOLOGIES CO., LTD.

Issue 03(2013-08-05)

Commercial in Confidence

Page 1 of 24

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service.

Please feel free to contact our local office or company headquarters.

Huawei Technologies Co., Ltd.

Address:

Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website:

http://www.huawei.com

Email:

[email protected]

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute the warranty of any kind, express or implied.

HUAWEI E8231 HSPA+ Wingle V100R001

Product Description

Issue 03(2013-08-05)

Commercial in Confidence

Page 2 of 24

About This Document

Summary

This document provides information about the major functions, supported services,

system architecture, and technical references of HUAWEI E8231 HSPA+ Wingle

(hereinafter referred to as the E8231).

The following table lists the contents of this document.

Chapter

Describes

1 Overview

The supported network modes, basic services and functions,

and the appearance of the E8231.

2 Features

The supported features and technical specifications of the

E8231.

3 Services and Applications

The services and applications of the E8231.

4 System Architecture

The architecture of the E8231.

5 Technical Reference

The technical references of the E8231.

6 Packing List

The items contained in the package of the E8231.

A Acronyms and Abbreviations

The acronyms and abbreviations mentioned in this document.

HUAWEI E8231 HSPA+ Wingle V100R001

Product Description

Issue 03(2013-08-05)

Commercial in Confidence

Page 3 of 24

History

Issue

Details

Date

Author

Approved by

Initial draft completed.

2013-08-05

HUAWEI E8231 HSPA+ Wingle V100R001

Product Description

Issue 03(2013-08-05)

Commercial in Confidence

Page 4 of 24

Contents

1 Overview..........................................................................................................................5

2 Features...........................................................................................................................7

2.1 Main Features .................................................................................................................................. 7

2.2 Technical Specifications ................................................................................................................... 8

2.2.1 Hardware ................................................................................................................................. 8

2.2.2 Software Specifications ........................................................................................................... 9

3 Services and Applications ........................................................................................... 11

3.1 Packet Data Service........................................................................................................................11

3.1.1 USB Modem ...........................................................................................................................11

3.1.2 Wireless Modem.....................................................................................................................11

3.2 SMS................................................................................................................................................ 13

4 System Architecture .....................................................................................................14

4.1 System Architecture ....................................................................................................................... 14

4.2 Functional Modules ........................................................................................................................ 15

5 Technical Reference .....................................................................................................17

5.1 Standards/Protocols for Data product ............................................................................................ 17

5.2 Standards/Protocols for wireless Um interface .............................................................................. 17

6 Packing List...................................................................................................................21

HUAWEI E8231 HSPA+ Wingle V100R001

Product Description

Issue 03(2013-08-05)

Commercial in Confidence

Page 5 of 24

1 Overview

The E8231 supports the following standards:

High Speed Packet Access Plus (HSPA+)

High Speed Uplink Packet Access (HSUPA)

High Speed Downlink Packet Access (HSDPA)

Universal Mobile Telecommunications System (UMTS)

Enhanced Data Rates for Global Evolution (EDGE)

General Packet Radio Service (GPRS)

Global System for Mobile Communications (GSM)

Wireless local area network as WiFi AP(WLAN)

The E8231 provides the following services:

HSPA+ packet data service，the maximum rate up to 21.6Mbit/s;

HSPA (HSUPA/HSDPA)/UMTS packet data service, the maximum rate up to

14.4Mbit/s;

EDGE/GPRS packet data service, the maximum rate up to 236.8Kbit/s;

UMTS/GSM Short Message Service (SMS)

You can connect the E8231 with the USB interface of a computer, or with the power

adapter/in car also by USB interface.

In the service area of the HSPA+/HSPA/UMTS/EDGE/GPRS/GSM network, you can

surf the Internet and send/receive messages/emails cordlessly. The E8231 is fast,

reliable, and easy to operate. Thus, mobile users can experience many new features

and services with the E8231. These features and services will enable a large number

of users to use the E8231 and the average revenue per user (ARPU) of operators will

increase substantially.

Figure 1-1 shows the profile of the E8231.

HUAWEI E8231 HSPA+ Wingle V100R001

Product Description

Issue 03(2013-08-05)

Commercial in Confidence

Page 6 of 24

Figure 1-1 E8231 profile

HUAWEI E8231 HSPA+ Wingle V100R001

Product Description

Issue 03(2013-08-05)

Commercial in Confidence

Page 7 of 24

2 Features

2.1 Main Features

The E8231 mainly supports the following features:

HSPA+/HSPA/UMTS 2100MHz (E8231s-1)、2100/900MHz(E8231s-2),

EDGE/GPRS/GSM 1900MHz/1800MHz/900MHz/850MHz

Equalizer

Receive diversity

HSPA+ downlink data service of up to 21.6Mbps

HSDPA data service of up to 14.4Mbps

HSUPA data service of up to 5.76Mbps

UMTS PS domain data service of up to 384 kbps

EDGE packet data service of up to 236.8 kbps

GPRS packet data service of up to 85.6 kbps

SMS based on CS/PS domain of GSM and UMTS

Wi-Fi AP and WPS

Inner DHCP server, DNS RELAY and NAT

Plug and Play

Standard USB interface

UMTS and WLAN inner antenna

Wi-Fi AP, supports up to 10 users

Windows XP SP3, Windows Vista SP1/SP2, Windows 7, Windows 8(Does not

support Windows RT), Mac OS X 10.6, 10.7 and 10.8 with latest upgrades

HUAWEI E8231 HSPA+ Wingle V100R001

Product Description

Issue 03(2013-08-05)

Commercial in Confidence

Page 8 of 24

2.2 Technical Specifications

2.2.1 Hardware

Table 2-1 lists the hardware specifications.

Table 2-1 Hardware specifications

Item

Specifications

Technical standard

GSM/GPRS/EGPRS R99

WCDMA/HSDPA R5, HSUPA R6, HSPA+ R7

WLAN: IEEE 802.11b/g/n

Operating frequency

HSPA+/HSPA/UMTS

2100MHz (E8231s-1),

2100/900MHz(E8231s-2)

EDGE/GPRS/GSM: 1900MHz/1800MHz/900MHz/850MHz

WLAN：2412MHz～2472MHz

Maximum

transmitter power

WCDMA/HSPA+：+24dBm (Power Class 3)

GSM/GPRS 850M/900MHz：+33dBm (Power Class 4)

GSM/GPRS 1800MHz/1900MHz：+30dBm (Power Class 1)

EDGE 850M/900MHz：+27dBm (Power Class E2)

EDGE 1800MHz/1900MHz：+26dBm (Power Class E2)

WLAN:

802.11b：13（＋/-3）dBm

802.11g：11（＋/-3）dBm

802.11n：11（＋/-3）dBm

Static receiver

sensitivity

WCDMA/HSPA/HSPA+: Compliant with 3GPP TS

25.101(R7)

GSM/GPRS/EDGE: Compliant with 3GPP TS 05.05 (R99)

WLAN：

802.11b：-85（＋/-3）dBm

802.11g：-71（＋/-3）dBm

802.11n：-70（＋/-3）dBm

WLAN speed

802.11b: up to 11Mbit/s

802.11g: up to 54Mbit/s

802.11n: supporting MCS0～MCS7, up to 72.2Mbit/s

Maximum power

consumption

HUAWEI E8231 HSPA+ Wingle V100R001

Product Description

Issue 03(2013-08-05)

Commercial in Confidence

Page 9 of 24

Item

Specifications

Power supply

DC: 5V/1A

External interfaces

USB 2.0 High Speed

SIM card: standard 6-pin SIM card interface

Key

Reset key

Antenna

Inner GSM/UMTS main antenna

Inner UMTS diversity antenna

Inner WLAN antenna

Size

88×27×11.5 mm

Weight

<30g

Temperature

Operating: –10℃to +45℃

Storage: –20℃to +70℃

Humidity

5% to 95%

Notes:

EGPRS = enhanced GPRS

SIM = subscriber identity module

USIM = UMTS subscriber identity module

2.2.2 Software Specifications

Table 2-2 lists the dashboard specifications.

Table 2-2 Software specifications

Item

Description

SMS

Writing/Sending/Receiving

Sending/Receiving long messages

Group sending

Storage: The messages are saved up to 500 items.

Sorting

New message prompt

Network connection

setup

APN management

Set up network connection
