Huawei IDEOS User manual

Quick Start

1. What is in your box

Your phone box contains the following items:

• Mobile phone • Battery

• Charger • USB cable

• Headset • Quick start guide

• Safety information

2. Phone at a glance

• : Press to open the menu on an active screen.

• : Touch and hold to open the Recent panel.

• : Press to go to the Call log screen.

Earpiece

Touch

screen

Home

Back OK

Send End

Microphone

Navigation

Headset jack Power

Volume keys

Charge/Data port Wrist strap hold

Speaker

Camera

Status indicator

3. Before getting started

Installing the SIM card

Installing the microSD card* and the battery

★

★*microSD★card★is★optional.

4. Charging the battery

1 2

The color of the status indicator tells the battery status of

your mobile phone.

• Green: Fully charged (when connected to charger).

• Orange: Charging (when connected to charger).

• Red: Battery low.

5. Powering on or off your mobile phone

Powering on your mobile phone

Press to power on your mobile phone. The ﬁrst time you

do this, you will be asked to sign in to your account and set

up your mobile phone.

LNote:LYouLneedLanLInternetLconnectionLtoLsetLupL

accounts.

Powering off your mobile phone

Press and hold to open the Phone options menu, and

then touch Power off.

6. Using the Touchscreen

• Touch: Touch a desired item with your ﬁnger to conﬁrm

your selection or start an application.

• Touch and hold: Touch and hold the screen until your

mobile phone responds. For example, you can always

touch and hold the screen to open the options menu of

the active screen.

• Flick: Flick your ﬁnger vertically or horizontally across the

screen.

• Drag: Touch and hold your desired item with your ﬁnger.

Then, drag the item to any part of the screen to move the

item.

7. Home screen

Home screen view

★

★Touch★and★hold★the★small★dots★on★the★lower★left★or★

right★of★the★screen★to★view★thumbnails★of★the★Home★

screen★and★its★extensions,★which★you★can★touch★to★

open.

Locking the screen

• When your mobile phone is on, press to lock the

screen. When the screen is locked, you can still receive

messages and calls.

• If you leave your mobile phone idle for a while, the screen

will lock automatically.

10:23 AM

Touch to open the Phone screen.

Touch to open the Launcher screen.

Touch to open Browser.

Notifications bar:

Displays the reminders and status icons of your

phone. Flick down to open the notifications panel.

Display area:

Shows the operation and display areas of your phone.

Interface switching dots:

Indicate the number of the screens on the left or

right. Touch the left or right dots to switch between

the screens.

Unlocking the screen

1. Press , , or to wake up the screen.

2. Drag the lock icon from left to right to unlock the screen.

Adding a new screen item

1. Touch and hold a blank area on the Home screen until

the Add to Home screen menu is displayed.

2. Select an item to add it to the Home screen.

8. Getting your contacts into the phone

Importing contacts from a SIM card

1. In the contact list, press , and then touch Import/

Export.

2. Touch Import from SIM card. Wait for the SIM card

contents to be loaded.

3. Select the check boxes of the contacts you want to

import.

★You can press , and then touch Import all to

import all contacts from SIM card.

Adding a contact

1. In the contact list, press , and then touch New contact.

2. Enter the contact's name, and then add detailed

information such as phone number or address.

3. When you are ﬁnished, touch Done to save the contact

information.

9. Making a call

Making a call with the dialer

1. To make a call, you can use the Phone application.

2. Touch the appropriate numeric keys to enter the phone

number.

3. Press or touch to initiate the call.

4. When ﬁnished, press .

Answering an incoming call

• Press or drag to the right to answer the call.

Rejecting an incoming call

• Press or drag to the left to reject a call.

10. Entering text

Using the onscreen keyboard

• Touch the space where you will enter your text to show

the keyboard.

• Press to hide the keyboard.

Switching the input method

Touch and hold the space where you enter your text until the

Edit text menu is displayed. Touch Input method.

11. Sending a message

1. Touch Launcher > Messaging > New message.

2. Enter a phone number in the To ﬁeld.

3. Touch the Type to compose text box to start entering

your message.

★On the edit messages screen, press to display the

options panel. Touch Add subject to add the

message subject or touch Attach to add a picture,

music, or video le.

4. When you ﬁnished editing message, touch Send to send

the message.

12. Getting connected

Connecting to a wireless network

1. On the Home screen, press > Settings.

2. Touch Wireless & networks > Mobile networks, and

then select the Data enabled check box to turn on date

services.

★If you do not need a wireless network, you can

uncheck the Data enabled check box to save data

trafc costs.

Connecting to a Wi-Fi network

1. On the Home screen, press > Settings.

2. Touch Wireless & networks, and then select the Wi-Fi

check box to turn on Wi-Fi.

3. Touch Wi-Fi settings. You will see a list of detected Wi-

Fi networks in the Wi-Fi networks section.

4. Touch a Wi-Fi network to connect to it.

When you connected to a Wi-Fi network, will display on

the notiﬁcations bar.

Sharing data connection as a portable Wi-Fi

hotspot

1. On the Home screen, press > Settings.

2. Touch Wireless & networks > Tethering & portable

hotspot.

3. Select the Portable Wi-Fi hotspot check box to share

your data connection.

★When Portable Wi-Fi hotspot is selected, you can

touch Portable Wi-Fi hotspot settings to change its

network name or secure it.

Opening a web page

On the Home screen, touch to open the browser.

★

★When★both★of★the★known/open★Wi-Fi★networks★and★the★

wireless★networks★are★available,★your★phone★selects★a★

Wi-Fi★network★for★internet★access.
