Инструкция для
Huawei G5000
Перейти в карточку товара
8 800 775 98 98
Copyright © Huawei Technologies Co., Ltd. 2012. All
rights reserved.
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned
are the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO
CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY
SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,
OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR
ANTICIPATED SAVINGS.
i
Contents
Your Phone ..........................................................................1
Keys and Functions...............................................................2
Screen Icons.........................................................................5
Installing the SIM Cards and the Battery................................6
Removing the Battery and the SIM Cards ..............................6
Installing the microSD Card...................................................7
Charging the Battery ............................................................7
Navigating the Main Menu...................................................7
Phone Lock ..........................................................................8
PIN and PUK ........................................................................8
Locking and Unlocking the Keypad .......................................9
My Files ...............................................................................9
Dual-Card Management .......................................................9
Making a Call .....................................................................10
Answering a Call ................................................................10
SOS....................................................................................11
Name 1/2...........................................................................11
Changing the Text Input Mode ...........................................12
Entering a Word.................................................................12
Entering a Digit ..................................................................13
Entering a Symbol ..............................................................13
ii
Writing and Sending a Text Message ..................................13
Writing and Sending a Multimedia Message .......................14
Creating a Contact .............................................................15
Searching for a Contact......................................................15
FM Radio ...........................................................................16
Camera ..............................................................................16
Image Album .....................................................................17
Audio Player.......................................................................17
Video Recorder ..................................................................18
Video Player .......................................................................18
Sound Recorder..................................................................18
Relative Call........................................................................19
Magnifier ...........................................................................19
Connecting a Bluetooth Headset to Your Phone..................20
Transferring Data................................................................20
Network Settings................................................................21
Connecting to a Network ...................................................22
1
1 Getting to Know Your Phone
Your Phone
The following figure shows the appearance of your phone.
1
2
3
4
5
6
11
7
8
9
10
13
14
15
16
12
17
1 Torch 10 Microphone
2 Earpiece 11 Number keys
3 Charger jack 12 End/Power key
4 Screen 13 Name 2 key
5 Volume/Scroll key 14 Confirm key
6 Navigation keys 15 Keypad lock key
7 Name 1 key 16 Torch key
2
8 SOS key 17 Headset
9 Call/Answer key
Keys and Functions
Press…
To…
Make a call from the Subscriber Identity Module
(SIM) card.
Answer a call.
Access in standby mode.
Power the phone on or off (press and hold this key
for about 3 seconds).
End or reject a call.
Return to standby mode.
Select the option displayed in the lower left corner of
the screen.
Access in standby mode.
Select the option displayed in the lower right corner
of the screen.
Access in standby mode.
Access the main menu in standby mode.
Confirm a selection.
3
Press…
To…
Access (press ) in standby mode.
Access (press ) in standby mode.
Access (press ) in standby mode.
Access (press ) in standby mode.
Customize the navigation keys. Access the main
menu and select > >
.
Adjust the volume when calling, listening to FM Radio,
or playing music.
Access in any mode.
Turn the torch on or turn off in any mode.
Lock or unlock the keypad in standby mode
Enter the number 0 or a space.
Access in standby mode (press and hold
this key for about 3 seconds).
4
Press…
To…
through
Enter numbers, letters, and symbols.
Call voicemail in standby mode (press and hold this
key for about 3 seconds).
Speed-dial phone numbers in standby mode (press
and hold one of the number keys from
through for about 3 seconds).
Select an option labeled with the corresponding
number.
Enter (press this key once), (press this key twice),
(press this key three times), and W(press this key
four times) in standby mode.
Display the symbol list in editing mode.
Access in standby mode (press and hold
this key for about 3 seconds).
Enter #.
Switch between text input methods in editing mode.
5
Screen Icons
Icon Indicates…
Signal strength.
General Packet Radio Service (GPRS) signal.
enabled.
enabled.
enabled.
enabled.
profile activated.
profile activated.
Missed calls.
Call forwarding enabled.
New text messages.
New multimedia messages.
Alarms enabled.
Keypad locked.
Battery level.
Bluetooth activated.
6
2 Getting Started
Installing the SIM Cards and the Battery
You can install up to two SIM cards in the phone at the same time.
When installing a SIM card, ensure that the gold contact area faces
down, and that the beveled edge of the SIM card aligns with that of
the SIM card slot.
Removing the Battery and the SIM Cards
Before removing the battery and the SIM cards, ensure that your
phone is powered off.
