Huawei G3620 User manual

G3620

GSM Mobile Phone

User Guide

rights reserved.

Trademarks and Permissions

, , and are trademarks or

registered trademarks of Huawei Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned

are the property of their respective owners.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT

AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY

KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED

TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE

ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO

CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY

SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,

OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR

ANTICIPATED SAVINGS.

Features marked with "optional" are optional. These features

may vary according to service providers. For details, contact

your service provider.

1 Getting to Know Your Phone

Your Phone

The following figure shows the appearance of your phone.

1 Torch 8 Microphone

2 Earpiece 9 Number keys

3 Screen 10 End/Power key

4 Navigation keys 11 Music key

5 Left soft key 12 Right soft key

6 Call/Answer key 2 13 Confirm key

7 Call/Answer key 1 14 Charger jack

Keys and Functions

Press…

To…

Make a call from subscriber identity module (SIM)

card 1.

Answer a call.

View call logs for SIM card 1 in standby mode.

Make a call from SIM card 2.

Answer a call.

View call logs for SIM card 2 in standby mode.

Power the phone on or off (press and hold the key

for about 3 seconds).

End or reject a call.

Return to standby mode.

Access the audio player in standby mode.

Access the main menu in standby mode.

Select the option displayed in the lower left corner of

the screen.

Access Contact list in standby mode.

Select the option displayed in the lower right corner

of the screen.

Access the main menu in standby mode.

Confirm a selection.

Press…

To…

Access Calendar (press ) in standby mode.

Access Alarm (press ) in standby mode.

Access User profiles (press ) in standby mode.

Access Write message (press ) in standby mode.

Increase the volume (press ) during a call.

Decrease the volume (press ) during a call.

through

Enter numbers, letters, and symbols.

Call voicemail in standby mode (press and hold the 1

key for about 3 seconds).

Speed-dial phone numbers in standby mode (press

and hold the 2–9keys for about 3 seconds).

Select an option labeled with the corresponding

number.

Enter * (press the key once), + (press the key twice), P

(press the key three times), and W(press the key four

times) in standby mode.

Display the symbol list in editing mode.

Turn the flashlight on or off in standby mode (press

and hold the key for about 3 seconds).

Enter #.

Switch between text input methods in editing mode.

Lock the keypad in standby mode (press and hold the

key for about 3 seconds).

Screen Icons

Icon Indicates…

Signal strength.

General Packet Radio Service (GPRS) signal.

Ring only enabled.

(optional) Vib. only enabled.

(optional) Vib. and ring enabled.

(optional) Vib. then ring enabled.

Silence profile activated.

Headset profile activated.

Missed calls.

Call forwarding enabled.

New text messages.

New multimedia messages.

New push messages.

Alarms enabled.

Keypad locked.

Battery level.

(optional) Bluetooth activated.

2 Getting Started

Installing the SIM Cards and the Battery

You can install up to two SIM cards in the phone at the same time.

When installing a SIM card, ensure that the gold contact area faces

down, and that the beveled edge of the SIM card aligns with that of

the SIM card slot.

Removing the Battery and the SIM Cards

Before removing the battery and the SIM cards, ensure that your

phone is powered off.

Installing the microSD Card

Before installing or removing a microSD card, power the

phone off. When the phone is powered back on, it indicates

whether the microSD card has been installed correctly.

You can expand your phone's memory capacity by installing a

microSD card. When installing a microSD card, ensure that the gold

contact area faces down.

Charging the Battery

1. Connect the charger to an AC power socket.

2. Connect the charger to the charger jack on the phone.

3. Wait until the battery is completely charged.

During the charging process, the charging icon is displayed in

animation. When the charging icon becomes static, the battery is

fully charged.

4. Disconnect the charger from the phone.

5. Disconnect the charger from the AC power socket.

Navigating the Main Menu

1. In standby mode, press (Menu) or .

2. Press to scroll to the desired application and press

(OK) or to access the application.

3. Press or to scroll to the desired option, and press

(OK) or to access the option.

4. Press (Back) to return to the previous menu.

To return to standby mode, press .

Phone Lock

The phone lock protects your phone from unauthorized use. By

default, the phone lock is disabled. Once the phone lock is enabled,

you must enter the phone unlock code each time you power on the

phone. The preset phone unlock code is 1234. You can change this

code into any numeric string between four and eight digits.

If you forget the phone unlock code, contact your service provider.

PIN and PUK

The personal identification number (PIN) protects your SIM card from

unauthorized use. The PIN unblocking key (PUK) unlocks a blocked

PIN. Both the PIN and the PUK are provided with the SIM card. For

details, contact your service provider.

To enable the PIN lock:

1. Select Menu > Settings > Security settings > SIM1 or SIM2

security >PIN lock.

2. Enter the PIN and press (OK).

If you enter the incorrect PIN a specified number of times, the phone

prompts you to enter the PUK.

If you enter the incorrect PUK a specified number of times, the SIM

card will become permanently invalid. If this occurs, contact your

service provider for a new SIM card.

Locking and Unlocking the Keypad

To lock the keypad, press and hold in standby mode. To

unlock the keypad, press (Unlock) and .

If the Auto keypad lock function is enabled and the phone is in

standby mode for a preset period, the phone automatically locks the

keypad.

When the keypad is locked, you can press and

to answer a call or make an emergency call.

My Files

The My Files manages multimedia files stored on the phone and its

microSD card. Using My Files, you can view the size and creation

date of an ebook, image, or audio clip and open a multimedia file.

3 Voice Services

Making a Call

1. In standby mode, enter the phone number.

To make an international call, press twice to enter the

plus sign (+). Then enter the country or region code, area code,

and phone number.
