Huawei G2800S User manual
G2800S
GSM Mobile Phone
User Guide
Copyright © Huawei Technologies Co., Ltd. 2011. All
rights reserved.
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned
are the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO
CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY
SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,
OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR
ANTICIPATED SAVINGS.
1
Features marked with "optional" are optional. These features
may vary according to service providers. For details, contact
your service provider.
1 Getting to Know Your Phone
Your Phone
The following figure shows the appearance of your phone and is
provided for your reference only.
1 Earpiece 7 Microphone
2 Charger/Headset
interface(O
p
tional)
8 Torch
3 Screen 9 Number keys
2
4 Navigation keys 10 End/Power key
5 Left soft key 11 Right soft key
6 Call/Answer key 12 Confirm key
Keys and Functions
Press …
To …
Make a call.
Answer an incoming call.
View call logs in standby mode.
Power the phone on or off (press and hold the key
for about 3 seconds).
End or reject a call.
Return to standby mode.
Select the option displayed in the lower left corner of
the screen.
Select the option displayed in the lower right corner of
the screen.
Access the main menu in standby mode.
Confirm a selection.
Access the functions assigned to the navigation keys
in standby mode.
Customize the functions assigned to the navigation
keys, select Menu > Settings > Phone settings >
Dedicated key.
3
Press …
To …
–
Enter numbers, letters, and symbols.
Call voicemail in standby mode (press and hold the 1
key for about 3 seconds).
Speed-dial phone numbers in standby mode (press
and hold the 2–9 keys for about 3 seconds).
Select an option labeled with the corresponding
number.
Enter * (press the key once), +(press the key twice), P
(press the key three times), and W(press the key four
times) in standby mode.
Display the symbol list in editing mode.
Turn the torch on or off in standby mode (press and
hold the key for about 3 seconds).
Enter #.
Switch between text input methods in editing mode.
Lock the keypad in standby mode (press and hold the
key for about 3 seconds).
Screen Icons
Icon Indicates …
Signal strength.
The alert type is Ring.
The alert type is Vibrate .only enabled.
The alert type is Vibrate and ring.
4
Icon Indicates …
The alert type is Vibrate then ring
The alert type is Light only.
The earphone is plugged (Optional).
Missed calls.
Call forwarding enabled.
New text messages.
Alarms activated.
Keypad locked.
Battery level.
2 Getting Started
Installing the SIM Cards and the Battery
You can install up to two subscriber identity module (SIM) cards in
the phone at the same time.
When installing a SIM card, ensure that the gold contact area faces
down, and that the beveled edge of the SIM card aligns with that of
the SIM card slot.
Before removing the battery and the SIM cards, ensure that your
phone is powered off.
5
To enable dual-SIM mode, power on the phone, select Dual SIM
open.
Installing a microSD Card
Charging the Battery
1. Connect the charger to an AC power socket.
2. Connect the charger to the phone's charger jack.
3. Wait until the battery is fully charged.
While the battery is charging, the charging icon blinks. When the
charging icon stops blinking, the battery is fully charged.
When you charge a completely exhausted battery, the
charging icon may appear several minutes later.
6
4. Disconnect the charger from the phone.
5. Disconnect the charger from the AC power socket.
Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock is disabled. You can change the preset
phone unlock code (1234) to any number of four to eight digits.
If you forget the phone unlock code, contact your service provider.
PIN and PUK
The personal identification number (PIN) protects your SIM card from
unauthorized use. The PIN unblocking key (PUK) unlocks a blocked
PIN. Both the PIN and the PUK are provided with the SIM card. For
details, contact your service provider.
If you enter the incorrect PIN a specified number of times, the phone
prompts you to enter the PUK.
If you enter the incorrect PUK a specified number of times, the SIM
card will become permanently invalid. If this occurs, contact your
service provider for a new SIM card.
Locking and Unlocking the Keypad
To lock the keypad, press and hold for about 3 seconds in
standby mode. To unlock the keypad, press (Unlock) then
in quick succession.
If the Auto keypad lock function is enabled, the phone will lock the
keypad automatically after being idle in standby mode for a
pre-defined period.
When the keypad is locked, you can press to answer
a call or make an emergency call.
7
3 Voice Services
Making a Call
1. In standby mode, enter a phone number.
To make an international call, press twice to enter the plus
sign (+). Then enter the country code or region code, area code,
and phone number.
To call an extension, enter the phone number, press three
times to enter P, and enter the extension number.
2. Press to dial the number.
3. Press to end the call.
You can also make a call from call logs, contacts, and
messages.
During a call, you can press or to adjust the in-call
volume.
Answering a Call
When there is an incoming call:
Press to answer the call.
Press to reject the call.
8
Press (Silence) to mute the speaker, and then press
(Reject) to reject the call.
If the any key answer function is enabled, you can press any key
except or to answer a call.
4 Text Input
Changing the Text Input Mode
The current text input mode indicator is displayed in the upper left
corner of the screen. Press to switch between text input modes.
Indicator Text Input Mode
ABC and abc Multi-tap input modes
123 Number input mode
Press (Clear) once to delete the last character
entered. Press and hold (Clear) for about 3
seconds to delete all the characters.
In any input mode, press to display the commonly used
symbol list.
In any input mode (except the number input mode), press
to enter a space. Press twice to enter 0.
