HTC FUZE User manual

Getting Started Guide

Welcome to AT&T

Your device controls are

shown on this foldout.

Please use our interactive Web tutorial available at

att.com/WirelessTutorials

for most complete and up-to-date information available to set up your device

and services. The on-line tutorials include detailed step-by-step instructions

and screen shots to assist your learning.

Or use this simple Getting Started Guide to quickly get an overview of the

major features and services available with your smartphone.

Thanks again for choosing AT&T.

Table of Contents

Welcome to AT&T 2

Table of Contents 3

What’s in the box 5

Device setup 6

Insert the SIM card 6

Insert the battery 6

Install a microSD card 7

Charge the battery 7

Turn on your HTC FUZE™ 8

Sleep Mode 8

Get to know your HTC FUZE™ 9

Check device status, make calls, and set up voice

mail 12

Before making a call 12

Make a phone call 13

Set up your voicemail 13

Make a Video Share call 14

Receive a Video Share call 14

The TouchFLO™ 3D 15

Home 18

Change the date and time 18

Enter Information 18

Add a contact to your device 19

Copy all SIM card contacts to your device 19

Schedule an appointment 20

People 21

Add a favorite in the People tab 21

Use the People tab 22

Email 23

Table of Contents

About email 24

Set up a personal email with Xpress Mail 24

Send and receive personal email 25

Corporate email setup with Xpress Mail 25

Set up IT managed corporate email 26

Synchronize information 26

Text Messages 27

Compose and send a text message 27

AT&T Services 28

Use MEdia Net to access the Web and shop online 29

AT&T Music 30

Use Instant Messaging 30

AT&T Navigator 31

CV 33

Push to Talk 33

Internet 35

While in the Web browser (Opera® Mobile) 35

Add your favorite Web site as a bookmark 36

Music Player 37

Transfer music 37

Weather 38

Add a new location 38

Programs 39

Photos and Videos 40

Take a picture of your contact 40

Use the camera and send a Multimedia Message (MMS) 41

Settings 42

Frequently Asked Questions 44

Tips and Tricks 45

What’s in the box

USB Sync Cable

AC Charger

Rechargeable Battery

Getting Started CD

Includes User Manual,

Microsoft ActiveSync,

and Warranty

information for your

AT&T device.

Extra Stylus

HTC FUZE™

3.5 mm Audio Adapter

Insert the SIM card

The SIM card contains your phone number,

service details, and phonebook/message

memory. Make sure that your device is turned

off before you remove the back cover and

insert the SIM card, microSD card, and battery.

1. Hold the device with both hands and the

front panel facing down.

2. Push the back cover up with your thumbs

until it disengages from the device and

then slide it up to remove.

3. Locate the SIM card slot, then insert the

SIM card with its gold contacts facing down

and its cut-off corner facing out the card

slot.

4. Slide the SIM card completely into the slot.

Note: To remove the SIM card, remove theTo remove the SIM card, remove the

battery if it is installed, then slide the

SIM card out from the SIM card slot with

your thumb.

Insert the battery

Your device comes with a rechargeable

Lithium-ion or Lithium-ion polymer battery and

is designed to use only manufacturer-specified

original batteries and accessories.

1. Align the battery’s

exposed copper

contacts with the

battery connectors

inside the battery

compartment.

2. Insert the contact’s side of the battery

first and then gently push the battery into

place.

3. Replace the back cover.

To remove the battery

1. Make sure your device is turned off.

2. Remove the back cover.

3. Lift the protruding grip at the bottom right

side of the battery to remove the battery.

Battery grip

Device setup

2Cut-off

corner

Install a microSD card

To have additional storage for your images,

videos, music, and files, you can purchase a

microSD™ card and install it into your device.

Insert the microSD card into the slot with its

gold contacts facing down, then replace the

back cover.

Note: To remove the microSD card, press it to

eject it from the slot.

Charge the battery

New batteries are shipped partially charged.

Before you start using your device, it is

recommended that you install and charge

the battery. Some batteries perform best after

several full charge/discharge cycles.

To charge the battery

•Connect the USB connector of the AC

adapter to the PC and to the sync connector

on your device, or

•Plug in the AC adapter to an electrical outlet

to start charging the battery.

Note: Only the AC adapter and USB sync

cable provided with your device must be

used to charge the device.

Charging is indicated by a “breathing” white

light around the Navigation Control. As the

battery is being charged while the power is

on, a charging icon also appears in the

title bar of the Home screen. After the battery

has been fully charged, the Navigation Control

LED shows a solid white light and a full battery

icon appears in the title bar of the Home

screen.

Warning! Do not remove the battery from

the device while you are charging it

using the AC or car adapter.

As a safety precaution, the battery

stops charging when it overheats.

Turn on your HTC FUZE™

Press the POWER button to turn on the device.

It may take several minutes for the TouchFLO

3D interface to load during initial setup. Do not

press any buttons or turn off the device while

TouchFLO 3D is loading.

Sleep Mode

Your device will go to Sleep Mode after 30

seconds or more of inactivity. Sleep Mode

suspends your device to a low power state

while the display is off in order to save battery

power.

You will still be able to receive messages and

calls while your device is in Sleep Mode. To

wake up your device, press the POWER button

again. Incoming calls or messages will also

wake up your device from Sleep Mode.

Tip: You can change how long before your

device goes into Sleep Mode by touching

Start > Settings > System tab > Power >

Advanced tab.

Power button

Get to know your HTC FUZE™

Start menu

Access more

programs and

settings.

Open Call History.

Open Contacts.

Open the Quick

menu.

Time

Adjust the time or

set alarms.

Open Calendar.

END

Press to end a call or

return to the Home screen.

TALK/SEND

Press to answer an

incoming call or dial a

number.

HOME

Press to return to

the Home screen.

BACK

Press to return to the

previous screen.

TouchFLO 3D tabs

Page 17

Status Indicators

Page 12

Check out the Navigation Control

On the Home screen and in many programs on

your device, you can use the Navigation Control

for directional control.

Press the directional arrows to navigate up,

down, left, and right on the screen. When an

item has been selected on the screen, press the

ENTER button (the center button) to confirm

your selection.

Up arrow ENTER button

Left arrow Down arrow

Right

arrow

Open the keyboard

Hold the device sideways with the control

buttons on your right, then slide the screen

panel up to reveal the keyboard.

Tasks screen

The Tasks screen displays when you open the

hardware keyboard while on any of the TouchFLO

3D tabs. The Tasks screen lets you quickly start a

task such as compose an email or text message,

create a new appointment, open the Web

browser, and more.
