HTC 001HT User guide

Getting Started

Package Contents

Parts & Functions

■Front

■001HT Handset ■Battery (HTBAH1)

■AC Adapter (HTCAG1) ■Micro USB Cable (HTDAF1)

■Headset with Microphone

(HTLAF1)

■

microSD Memory Card (Sample)

■Battery Cover

■Back Cover (USIM/Memory

Card)

■Quick Start Guide (Japanese)

■Safety Precautions (Japanese)

①Optical Sensor ⑥Home Key

②Earpiece ⑦Menu Key

③Power Key ⑧Back Key

④Notification LED ⑨Search Key

⑤Touchscreen Display

②

Earpiece

①Optical

Sensor

③

Power Key

④

Notification

LED

⑤

Touchscreen

Display

⑥

Home Key

⑦

Menu Key

⑧

Back Key

⑨

Search Key

■Back USIM Card Installation

Turn off handset before inserting/removing USIM Card.

■Inserting USIM Card

1. Insert USIM Card

With IC chip down, insert USIM Card into slot on the right.

■Removing USIM Card

1. Slide USIM Card out

⑩Camera ⑮Battery Cover

⑪LED Flash ⑯Back Cover

(USIM/Memory Card)

⑫Speaker ⑰3.5 mm Audio Jack

⑬Volume Up ⑱External Device Terminal

⑭Volume Down ⑲Microphone

⑫Speaker

⑬Volume

⑭

Volume

Down

⑩Camera

⑯Back Cover

(USIM/Memory

Card)

⑮Battery

Cover

⑪

LED Flash

⑲

Microphone

⑱

External Device Terminal

⑰

3.5 mm Audio Jack

Memory Card Installation

Turn handset power off before inserting/

removing Memory Card.

■Inserting Memory Card

1. Remove Back Cover

Slide Back Cover off to remove it.

2. Insert Memory Card

With contacts down, push Memory Card

into slot on the left until it clicks.

3. Replace Back Cover

■Removing Memory Card

1. Remove Back Cover

2. Push Memory Card in to eject it

Memory Card pops out slightly.

3. Carefully remove Memory Card

4. Replace Back Cover

Battery Installation

■Inserting Battery

1. Remove Battery Cover

Use fingernail to lift Battery Cover up.

2. Insert battery

With

htc

logo up, insert battery.

3. Replace Battery Cover

Put back Battery Cover, pushing battery

all the way in.

■Removing Battery

1. Remove Battery Cover

2. Remove battery

3. Replace Battery Cover

Charging Battery

1. Insert USB plug into AC Adapter

2. Insert microUSB plug into External

Device Terminal

3. Plug AC Adapter into 100V AC

outlet

As battery charges, Notification LED

lights solid orange. When battery is fully

charged, LED lights solid green.

4. When battery is fully charged,

disconnect AC Adapter

5. Unplug AC Adapter, then

disconnect handset

Specifications

*Approximate Value

Charging Time*

(AC Adapter) 150 minutes

Continuous

Standby Time*

3G: 401 hours

GSM: 384 hours

Continuous

Talk Time*

3G: 320 minutes

GSM: 371 minutes

Dimensions 123 mm (H) x 68 mm (W) x

11.8 mm (D)

Weight

(including

battery)

164 g

Handset Power On/Off

■Power ON

1. Press

Home Screen appears.

■Power OFF

1. Press and hold ＞Power off

Initial Handset Setup

The first time handset powers on, tutorials/

guides appear for the following items:

･Handset language

･Internet connection type

･Scheduled sync type

･Wi-Fi Access point

･Google location option

･HTC Sense account

･Email accounts

･Social network accounts

･Current time

1. Press

2. Follow onscreen instructions

Handset Language

1. ＞Settings ＞Language &

keyboard ＞Select language ＞

English or 日本語

Clock

1. ＞Settings ＞Date &time

2. Set automatic/manual option, date

and time, time zone, and date or

time format

Sound Profile

Vibration/Silent Mode

1. ＞Settings ＞Sound ＞Sound

profile ＞Select a profile

Touchscreen Operations

●Tap

Tap application/settings icons, or onscreen

buttons to select them.

●Press and Hold

To open available options for an item, simply

press and hold the item.

●Flick

Swipe finger vertically to view webpages,

Contacts, or lists, etc.

●Pan

Touch and hold Display, then drag finger to see

a zoomed photo, webpage, or document.

●Rotate

In most applications, rotating the handset

automatically changes Display orientation.

●Pinch

Ｗhen viewing images or webpages, pinch

your fingers together/apart to zoom in/out.

･The first time handset powers on, handset

setup prompt appears.

･Alternatively, complete setup later:

Tap then tap Setup.

･Alternatively, press Volume Down Key to

set Vibrate mode.

USIM PINs

USIM Card has two 4- to 8-digit security

codes.

Use PIN to prevent unauthorized use.

･It is set to 9999 by default.

･Set handset to require PIN entry at power on to

prevent unauthorized use.

PIN2

PIN2 provides personal authentication for

online services.

･PIN2 cannot be changed on handset.

Set Up SIM Card Lock

Require PIN entry at power on for handset

use.

1. ＞Settings ＞Security ＞Set

up SIM card lock

2. Check “Lock SIM card” box

3. Enter default USIM PIN ＞OK

Canceling PIN Lock (PUK/PUK2 Code)

Entering an incorrect PIN three consecutive

times activates PIN Lock. Enter PUK (Personal

Unblocking Key) code to cancel PIN Lock.

･For details about PUK code, contact SoftBank

Mobile Customer Service.

Security Codes

Phone Password, Center Access Code and

Network Password are required to use

handset.

Phone Password

4-digit number required to use or change

handset functions.

Center Access Code

4-digit number specified at subscription; use

to subscribe to fee-based information/access

Voice Mail via landline.

Network Password

4-digit number specified at subscription; use

for Call Barring, etc. Entering it incorrectly

three consecutive times locks Call Barring

settings. To resolve, Network Password and

Center Access Code must be changed.

･For details, contact SoftBank Mobile Customer

Center, General Information.

Phone Calls

My Phone Number

1. ＞Settings

2. About phone ＞Phone identity

Handset number appears in Owner

Information.

Making Voice Calls

1. Phone

2. Use Keypad to enter a phone

number

3. Call

4. To end call, End call

International Call

1. Phone ＞Tap and hold “0”

2. Enter Country Code →Recipient’s

phone number (omitting first “0”*)

*Include 0 when calling landlines in Italy

(Country Code: 39)

3. Call

4. To end call, End call

Emergency Call (110, 119, 118)

When calling is barred, follow these steps to

call emergency numbers:

1. Phone ＞Emergency phone

number ＞Call

Adding a new Contacts Entry

1. ＞People ＞Add contact

2. Select Contact type

3. Enter each item ＞Save

Receiving Calls

1. When a call arrives, Answer

2. To end call, End call

Overseas Handset Use

Global Roaming

■Setting Network Type

Select Network and Band type for overseas

carriers if necessary.

1. ＞Settings ＞Wireless &

networks ＞Mobile networks ＞

Network Mode

2. Select network type

■Setting Carriers

If there are multiple carriers in the region,

handset automatically selects a carrier.

Alternatively, select a carrier manually.

1. ＞Settings ＞Wireless &

networks ＞Mobile networks ＞

Network operators

2. Search networks or Select

automatically

Making Calls while Overseas

Landlines & Handsets Anywhere

1. Phone ＞Tap and hold “0”

2. Enter Country Code →Recipient’s

phone number (omitting first “0”*)

*Include 0 when calling landlines in Italy

(Country Code: 39)

3. Call

Domestic Landlines & Handsets

Enter phone number, including first 0; do

not enter Country Code.

1. Phone ＞Enter phone number

2. Call

Optional Services

*Requires a separate subscription.

Text Entry

Using Onscreen Keyboard

1. Tap and hold Text Entry window

2. Tap to toggle Input mode

Adjusting Touch Input Settings

1. ＞Settings ＞Language &

keyboard ＞iWnn IME

2. Set the followings:

Service Description

Call

Forwarding

Forward incoming calls to

specified phone number

Voicemail

Forward calls to Voicemail

Center; callers can leave

messages

Call Waiting*

Answer calls while line is

engaged; switch between

lines

Conference

Calls (Merge

Call)*

Use up to six lines

simultaneously; switch

between lines

Call Barring Block incoming/outgoing calls

Caller ID Show or hide your number

when making calls

Indicator Input Mode

Hiragana/kanji

Double-byte katakana

Single-byte katakana

Double-byte alphabets

Single-byte alphabets

Double-byte numbers

Single-byte numbers

Input

mode

Item Description

Sound on

Key Press Enable key click sound

Vibrate on

Key Press Enable key click vibration

Key Preview Enable key preview

Auto

Capitalization

Automatically capitalize first

character of sentences in

Alphabet mode

Keyboard

Image Change keypad layout

Input Word

Learning Learn input words

Word

Prediction

Show predicted words as

conversion candidates

Typing Error

Correction

Show predicted words to

correct typing errors

Wildcard

Prediction

Use Wildcard prediction

function

Japanese

User

Dictionary

Add words to the predictive

text dictionary in Hiragana/kanji

mode

Messaging

Mail Type

■SMS (Short Message Service)

Send short text messages to SoftBank

handsets. Enter up to 140 single-byte (70

double-byte) characters.

■Gmail

Gmail (Google Mail) is Google’s web-based

mail service. Handset Gmail automatically

synchronizes with one or more Gmail

accounts on the web.

■Internet Mail (POP3/IMAP4)

Exchange messages the same way as on PC.

･Set up a mail account.

Using SMS

1. ＞Messages

2. Compose message

3. Tap “To” (Recipient field) ＞Enter

recipient

4. Tap Text field ＞Enter message

5. Send

Using Gmail

1. ＞Gmail

2. ＞Compose

3. Tap “To” (Recipient field) ＞Enter

recipient

4. Tap Subject ＞Enter subject

5. Tap Compose Mail ＞Enter

message

6. Send

Using Internet Mail

Setting Up Internet Mail

1. ＞Mail

2. Microsoft Exchange ActiveSync or

Other (POP3/IMAP)

English User

Dictionary

Add words to the predictive

text dictionary in the Single-

byte alphabets mode

Clear

Learning

Dictionary

Reset learning dictionary

Item Description
