Datasheet

HP ProCurve Switch 2610 Series

The HP ProCurve Switch 2610 Series consists of five switches—the HP ProCurve Switch 2610-24 and

2610-48 provide 24 and 48 ports of 10/100 connectivity. The HP ProCurve Switch 2610-24 is fanless, providing

quiet operation and making it ideal for deployment in open spaces. The HP ProCurve 2610- 24/12PWR,

2610-24-PWR, and 2610-48-PWR are IEEE 802.3af-compliant for Power over Ethernet (PoE) and provide up

to 15.4 W for 12, 24, and 48 ports. The 2610-24/12PWR has 24 10/100 ports and provides 12 ports of PoE. All

switches include two 10/100/1000Base-T ports and two mini-GBIC slots for Gigabit uplink connectivity. An

optional redundant external power supply is also available to provide redundancy in the event of a power

supply failure. With static routing, robust security and management features, free lifetime warranty, and free

software updates, the 2610 series is a cost-effective solution for customers who are building converged

enterprise edge networks.

HP ProCurve Switch 2610 Series

Features and benefits

Industry-leading warranty

♦ For as long as you own the product, with next-business-day advance replacement (available in most countries). The following hardware products and their related series modules have a one-year

hardware warranty with extensions available: HP ProCurve Routing Switch 9300m series, HP ProCurve Switch 8100fl series, HP ProCurve Network Access Controller 800, and HP ProCurve DCM

Controller. The following hardware mobility products have a one-year hardware warranty with extensions available: HP ProCurve M111 Client Bridge, HP ProCurve MSM3xx-R Access Points, HP

ProCurve MSM7xx Mobility and Access Controllers, HP ProCurve RF Manager IDS/IPS Systems, HP ProCurve MSM Power Supplies, HP ProCurve 1 Port Power Injector, and HP ProCurve CNMS

Appliances. Disk drives in the HP ProCurve ONE Services zl modules have a five year hardware warranty. Standalone software, upgrades, or licenses may have a different warranty duration. For details,

refer to the ProCurve Software License, Warranty, and Support booklet at http://www.procurve.com/warranty.

Connectivity

• IEEE 802.3af Power over Ethernet: provides up to 15.4 W per

port to IEEE 802.3af compliant PoE powered devices such as IP

phones, wireless access points, and security cameras

• Pre-standard PoE support: detects and provides power to

pre-standard PoE devices; see list of supported devices in the

product FAQ at www.ProCurve.com

• Gigabit Uplink Connectivity: two 10/100/1000BASE-T ports

and two mini-GBIC ports for connectivity such as Gigabit (SX, LX,

LH, 1000BaseT) and 100Base-FX

• ProCurve Auto-MDIX: automatically adjusts for straight-through

or crossover cables on all 10/100 ports

• Jumbo packet support: supports up to 9,216 byte frame size to

improve performance of large data transfers

Resiliency and high availability

• IEEE 802.3ad Link Aggregation Protocol (LACP) and

ProCurve trunking: support up to 24 trunks, each with up to 8

links (ports) per trunk

• IEEE 802.1s Multiple Spanning Tree: provides high link

availability in multiple VLAN environments by allowing multiple

spanning trees; provides legacy support for IEEE 802.1d and

IEEE 802.1w

• Optional redundant power supply: provides uninterrupted

power (provided by HP ProCurve 600 RPS/EPS)

Manageability

• RMON, XRMON, and sFlow: provide advanced monitoring and

reporting capabilities for statistics, history, alarms, and events

• Uni-Directional Link Detection (UDLD): monitors a link

between two switches and blocks the ports on both ends of the

link if the link goes down at any point between the two devices

• Command authorization: leverages RADIUS to link a custom

list of CLI commands to individual network administrator's login;

also provides an audit trail

• Multiple configuration files: allow multiple configuration files to

be stored to flash image

• Dual flash images: provides independent primary and

secondary operating system files for backup while upgrading

• Stacking capability: single IP address management for a virtual

stack of up to 16 switches, including the HP ProCurve Switch

2500 Series, 2510 Series, 2600 Series, 2610 Series, 2810 Series,

2900 Series, 3400cl Series, 3500l Series, 4200vl Series, 6108,

6200yl-24G-mGBIC, and 6400cl Series

• Friendly port names: allow assignment of descriptive names to

ports

• Find-Fix-and-Inform: finds and fixes common network problems

automatically, then informs administrator

• Software updates: free downloads from the Web

• Troubleshooting: ingress/egress port monitoring enables

network problem-solving

Layer 2 switching

• VLAN support and tagging: supports the IEEE 802.1Q (4,094

VLAN IDs) and 256 VLANs simultaneously

• GARP VLAN Registration Protocol: allows automatic learning

and dynamic assignment of VLANs

Layer 3 routing

• Basic IP routing: enables automatic routing to the connected

VLANs and up to 16 static routes--including one default route--in

IP networks

Security

• Multiple user authentication methods:

- IEEE 802.1X: industry-standard method of user authentication

using an IEEE 802.1X supplicant on the client in conjunction with

a RADIUS server

- Web-based authentication: similar to IEEE 802.1X, provides a

browser-based environment to authenticate clients that do not

support the IEEE 802.1X supplicant

- MAC-based authentication: client is authenticated with the

RADIUS server based on the client's MAC address

HP ProCurve Switch 2610 Series

• Authentication flexibility:

- Multiple IEEE 802.1X users per port: provides authentication of

up to eight IEEE 802.1X users per port; prevents user

"piggybacking" on another user's IEEE 802.1X authentication

- Concurrent IEEE 802.1X and Web or MAC authentication

schemes per port: switch port will accept any of IEEE 802.1X

and either Web or MAC authentications

• Access control lists (ACLs): provide IP Layer 3 filtering based

on source/destination IP address/subnet and source/destination

TCP/UDP port number

• Identity-driven ACL: enables implementation of a highly

granular and flexible access security policy and VLAN assignment

specific to each authenticated network user

• Dynamic ARP protection: blocks ARP broadcasts from

unauthorized hosts, preventing eavesdropping or theft of network

data

• Port security: allows access only to specified MAC addresses,

which can be learned or specified by the administrator

• MAC address lockout: prevents configured particular MAC

addresses from connecting to the network

• Source-port filtering: allows only specified ports to

communicate with each other

• RADIUS/TACACS+: eases switch management security

administration by using a password authentication server

• Secure Shell (SSHv2): encrypts all transmitted data for secure,

remote command-line interface (CLI) access over IP networks

• Port monitoring for network threats: Provides sampled port

traffic using sFlow technology to the HP ProCurve Network

Immunity Manager application for Network Behavior Anomaly

Detection (NBAD) analysis to detect threats and mitigate threats at

the port where the threat originated

• Secure Sockets Layer (SSL): encrypts all HTTP traffic, allowing

secure access to the browser-based management GUI in the

switch

• Secure FTP: allows secure file transfer to/from the switch;

protects against unwanted file downloads or unauthorized copying

of switch configuration file

• Switch management logon security: can require either

RADIUS or TACACS+ authentication for secure switch CLI logon

• DHCP protection: blocks DHCP packets from unauthorized

DHCP servers, preventing denial-of-service attacks

• STP BPDU port protection: blocks Bridge Protocol Data Units

(BPDUs) on ports that do not require BPDUs, preventing forged

BPDU attacks

• STP Root Guard: protects root bridge from malicious attack or

configuration mistakes

Convergence

• IEEE 802.1AB Link Layer Discovery Protocol (LLDP):

automated device discovery protocol for easy mapping by network

management applications

• LLDP-MED (Media Endpoint Discovery): a standard extension

of LLDP that stores values for parameters such as QoS and VLAN

to automatically configure network devices such as IP phones

• IP multicast snooping and data-driven IGMP: automatically

prevents flooding of IP multicast traffic

Quality of Service (QoS)

• Class of Service (CoS): sets the IEEE 802.1p priority tag based

on IP address, IP Type of Service (ToS), L3 protocol, TCP/UDP

port number, source port, and DiffServ

• Layer 4 prioritization: enables prioritization based on TCP/UDP

port numbers

• Traffic prioritization (IEEE 802.1p): allows real-time traffic

classification into eight priority levels mapped to eight queues

Monitor and diagnostics

• Port mirroring: enables traffic on a port to be simultaneously

sent to a network analyzer for monitoring

Warranty and support

• ProCurve Lifetime Warranty: for as long as you own the

product, with next-business-day advance replacement (available

in most countries).

• Electronic and telephone support: limited electronic and

telephone support is available from HP. Refer to the HP Web site

at www.procurve.com/support for details on the support provided

and the period during which support is available.

• Software releases: refer to the HP Web site at

www.procurve.com/support for details on the software releases

provided and the period during which software releases are

available.

HP ProCurve Switch 2610 Series

Specifications

HP ProCurve Switch 2610-48 (J9088A) HP ProCurve Switch 2610-24 (J9085A) HP ProCurve Switch 2610-24-PWR

(J9087A)

Ports

48 auto-sensing 10/100 ports (IEEE 802.3

Type 10Base-T, IEEE 802.3u Type

100Base-TX); Media Type: Auto-MDIX;

Duplex: half or full

24 auto-sensing 10/100 ports (IEEE 802.3

Type 10Base-T, IEEE 802.3u Type

100Base-TX); Media Type: Auto-MDIX;

Duplex: half or full

24 auto-sensing 10/100 ports (IEEE 802.3

Type 10Base-T, IEEE 802.3u Type

100Base-TX); Media Type: Auto-MDIX;

Duplex: half or full

1 RJ-45 serial console port 1 RJ-45 serial console port 1 RJ-45 serial console port

2 auto-sensing 10/100/1000 ports (IEEE

802.3 Type 10Base-T, IEEE 802.3u Type

100Base-TX, IEEE 802.3ab Type

1000Base-T); Duplex: 10Base-T/100Base-TX:

half or full; 1000Base-T: full only

2 auto-sensing 10/100/1000 ports (IEEE

802.3 Type 10Base-T, IEEE 802.3u Type

100Base-TX, IEEE 802.3ab Type

1000Base-T); Duplex: 10Base-T/100Base-TX:

half or full; 1000Base-T: full only

2 auto-sensing 10/100/1000 ports (IEEE

802.3 Type 10Base-T, IEEE 802.3u Type

100Base-TX, IEEE 802.3ab Type

1000Base-T); Duplex: 10Base-T/100Base-TX:

half or full; 1000Base-T: full only

2 open mini-GBIC (SFP) slots 2 open mini-GBIC (SFP) slots 2 open mini-GBIC (SFP) slots

Physical characteristics

Dimensions 9.3(d) x 17.4(w) x 1.73(h) in. (23.62 x 44.2 x

4.39 cm) (1U height)

9.3(d) x 17.4(w) x 1.73(h) in. (23.62 x 44.2 x

4.39 cm) (1U height)

12.5(d) x 17.4(w) x 1.73(h) in. (31.75 x 44.2 x

4.39 cm) (1U height)

Weight 10.75 lb. (4.88 kg), Fully loaded 5.5 lb. (2.49 kg), Fully loaded 15.05 lb. (6.83 kg), Fully loaded

Memory and processor

Processor MIPS @ 300 MHz, 16 MB flash, 128 MB

SDRAM; packet buffer size: 2 MB

MIPS @ 300 MHz, 16 MB flash, 128 MB

SDRAM; packet buffer size: 1 MB

MIPS @ 300 MHz, 16 MB flash, 128 MB

SDRAM; packet buffer size: 1 MB

Mounting

Mounts in an EIA-standard 19 in. telco rack or

equipment cabinet (hardware included);

horizontal surface mounting only

Mounts in an EIA-standard 19 in. telco rack or

equipment cabinet (hardware included);

horizontal surface mounting only

Mounts in an EIA-standard 19 in. telco rack or

equipment cabinet (hardware included);

horizontal surface mounting only

Performance

100 Mb Latency < 6.2 µs (LIFO) < 4.1 µs (LIFO) < 4.1 µs (LIFO)

1000 Mb Latency < 4.4 µs (LIFO) < 2.9 µs (LIFO) < 2.9 µs (LIFO)

Throughput up to 13.0 million pps up to 9.5 million pps up to 9.5 million pps

Routing/Switching capacity 17.6 Gbps 12.8 Gbps 12.8 Gbps

MAC address table size 8000 entries 8000 entries 8000 entries

Environment

Operating temperature 32ºF to 122ºF (0ºC to 50ºC) 32ºF to 122ºF (0ºC to 50ºC) 32ºF to 122ºF (0ºC to 50ºC)

Operating relative humidity 15% to 95% @ 104ºF (40ºC), non-condensing 15% to 95% @ 104ºF (40ºC), non-condensing 15% to 95% @ 104ºF (40ºC), non-condensing

Non-operating/Storage temperature -40ºF to 158ºF (-40ºC to 70ºC) -40ºF to 158ºF (-40ºC to 70ºC) -40ºF to 158ºF (-40ºC to 70ºC)

Non-operating/Storage relative humidity 15% to 90% @ 149ºF (65ºC), non-condensing 15% to 90% @ 149ºF (65ºC), non-condensing 15% to 90% @ 149ºF (65ºC), non-condensing

Altitude up to 10000 ft. (3 km) up to 10000 ft. (3 km) up to 10000 ft. (3 km)

Acoustic Power: 45 dB, Pressure: 36.2 dB; DIN

45635T.19 per ISO 7779

Power: 0 dB, Pressure: 0 dB No Fan Power: 64 dB, Pressure: 57 dB; DIN

45635T.19 per ISO 7779

Electrical characteristics

Maximum heat dissipation 285 BTU/hr (300.67 kJ/hr) 142 BTU/hr (149.81 kJ/hr) 410 BTU/hr (432.55 kJ/hr), (switch-only

BTU/hr: 410; combined switch + max. PoE

devices at 15.4 W: 2281 BTU/hr )

Voltage 100-127 / 200-240 VAC 100-127 / 200-240 VAC 100-127 / 200-240 VAC

Current 1.3 / 0.8 A 0.8 / 0.4 A 7.0 / 3.5 A

HP ProCurve Switch 2610 Series

Power consumption 66 W 41 W 77 W

Frequency 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz

Notes Maximum power rating is the worst-case

theoretical maximum power number with fully

loaded PoE, 100% traffic, all ports plugged in,

and all modules populated.

Maximum power rating is the worst-case

theoretical maximum power number with fully

loaded PoE, 100% traffic, all ports plugged in,

and all modules populated.

Maximum power rating is the worst-case

theoretical maximum power number with fully

loaded PoE, 100% traffic, all ports plugged in,

and all modules populated.

Power consumption: 77 W without PoE; 527

W with PoE.

Safety

CSA 22.2 No. 60950; UL 60950; IEC 60950;

EN 60950

CSA 22.2 No. 60950; UL 60950; IEC 60950;

EN 60950

CSA 22.2 No. 60950; UL 60950; IEC 60950;

EN 60950

Emissions

FCC Class A; VCCI Class A; EN

55022/CISPR 22 Class A

FCC Class A; VCCI Class A; EN

55022/CISPR 22 Class A

FCC Class A; VCCI Class A; EN

55022/CISPR 22 Class A

Immunity

EN EN 55024, CISPR 24 EN 55024, CISPR 24 EN 55024, CISPR 24

ESD IEC 61000-4-2; 4 kV CD, 8 kV AD IEC 61000-4-2; 4 kV CD, 8 kV AD IEC 61000-4-2; 4 kV CD, 8 kV AD

Radiated IEC 61000-4-3; 3V/m IEC 61000-4-3; 3V/m IEC 61000-4-3; 3V/m

EFT/Burst IEC 61000-4-4; 1.0 kV(power line), 0.5kV

(signal line)

IEC 61000-4-4; 1.0 kV(power line), 0.5kV

(signal line)

IEC 61000-4-4; 1.0 kV(power line), 0.5kV

(signal line)

Surge IEC 61000-4-5; 1 kV/2 kV AC IEC 61000-4-5; 1 kV/2 kV AC IEC 61000-4-5; 1 kV/2 kV AC

Conducted IEC 61000-4-6; 3V IEC 61000-4-6; 3V IEC 61000-4-6; 3V

Power frequency magnetic field IEC 61000-4-8; 1A/m,50 or 60 Hz IEC 61000-4-8; 1A/m,50 or 60 Hz IEC 61000-4-8; 1A/m,50 or 60 Hz

Voltage dips and interruptions IEC 61000-4-11; >95% reduction, 0.5 period;

30% reduction, 25 periods

IEC 61000-4-11; >95% reduction, 0.5 period;

30% reduction, 25 periods

IEC 61000-4-11; >95% reduction, 0.5 period;

30% reduction, 25 periods

Harmonics EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2

Flicker EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3

Management

HP ProCurve Manager Plus; HP ProCurve

Manager (included); command-line interface;

Web browser; configuration menu;

out-of-band management (serial RS-232C)

HP ProCurve Manager Plus; HP ProCurve

Manager (included); command-line interface;

Web browser; configuration menu;

out-of-band management (serial RS-232C)

HP ProCurve Manager Plus; HP ProCurve

Manager (included); command-line interface;

Web browser; configuration menu;

out-of-band management (serial RS-232C)

Notes

When using mini-GBICs with this product,

mini-GBICs with revision "B" or later (product

ends with the letter "B" or later, e.g., J4858B,

J4859C) are required.

When using mini-GBICs with this product,

mini-GBICs with revision "B" or later (product

ends with the letter "B" or later, e.g., J4858B,

J4859C) are required.

When using mini-GBICs with this product,

mini-GBICs with revision "B" or later (product

ends with the letter "B" or later, e.g., J4858B,

J4859C) are required.

Services

HP ProCurve Switch 2610 Series

3-year, 4-hour onsite, 13x5 coverage for

hardware (U4683E)

3-year, 4-hour onsite, 24x7 coverage for

hardware (U4835E)

3-year, 4-hour onsite, 24x7 coverage for

hardware, 24x7 software phone support

(U6321E)

3-year, 24x7 SW phone support, software

updates (UF792E)

Installation with minimum configuration,

system-based pricing (U4826E)

Installation with HP-provided configuration,

system-based pricing (U4830E)

Refer to the HP Web site at

www.procurve.com/services for details on the

service-level descriptions and product

numbers. For details about services and

response times in your area, please contact

your local HP sales office.

3-year, 4-hour onsite, 13x5 coverage for

hardware (U4683E)

3-year, 4-hour onsite, 24x7 coverage for

hardware (U4835E)

3-year, 4-hour onsite, 24x7 coverage for

hardware, 24x7 software phone support

(U6321E)

3-year, 24x7 SW phone support, software

updates (UF792E)

Installation with minimum configuration,

system-based pricing (U4826E)

Installation with HP-provided configuration,

system-based pricing (U4830E)

Refer to the HP Web site at

www.procurve.com/services for details on the

service-level descriptions and product

numbers. For details about services and

response times in your area, please contact

your local HP sales office.

3-year, 4-hour onsite, 13x5 coverage for

hardware (U4683E)

3-year, 4-hour onsite, 24x7 coverage for

hardware (U4835E)

3-year, 4-hour onsite, 24x7 coverage for

hardware, 24x7 software phone support

(U6321E)

3-year, 24x7 SW phone support, software

updates (UF792E)

Installation with minimum configuration,

system-based pricing (U4826E)

Installation with HP-provided configuration,

system-based pricing (U4830E)

Refer to the HP Web site at

www.procurve.com/services for details on the

service-level descriptions and product

numbers. For details about services and

response times in your area, please contact

your local HP sales office.

Standards and protocols Device management

HTML and telnet management

General protocols

IEEE 802.1D MAC Bridges

IEEE 802.1p Priority

IEEE 802.1Q VLANs

IEEE 802.1v VLAN classification by

Protocol and Port

IEEE 802.1w Rapid Reconfiguration of

Spanning Tree

IEEE 802.3ad Link Aggregation

Control Protocol (LACP)

IEEE 802.3af Power over Ethernet

IEEE 802.3x Flow Control

RFC 768 UDP

RFC 783 TFTP Protocol (revision 2)

RFC 792 ICMP

RFC 793 TCP

RFC 826 ARP

RFC 854 TELNET

RFC 951 BOOTP

RFC 1542 BOOTP Extensions

RFC 2030 Simple Network Time

Protocol (SNTP) v4

RFC 2131 DHCP

RFC 3046 DHCP Relay Agent

Information Option

IP multicast

RFC 3376 IGMPv3

MIBs

RFC 1213 MIB II

RFC 1493 Bridge MIB

RFC 2021 RMONv2 MIB

RFC 2096 IP Forwarding Table MIB

RFC 2613 SMON MIB

RFC 2618 RADIUS Client MIB

RFC 2665 Ethernet-Like-MIB

RFC 2668 802.3 MAU MIB

RFC 2674 802.1p and IEEE 802.1Q

Bridge MIB

RFC 2737 Entity MIB (Version 2)

RFC 2863 The Interfaces Group MIB

Network management

IEEE 802.1AB Link Layer Discovery

Protocol (LLDP)

RFC 3164 BSD syslog Protocol

RFC 3176 sFlow

ANSI/TIA-1057 LLDP Media Endpoint

Discovery (LLDP-MED)

SNMPv1/v2c/v3

Security

IEEE 802.1X Port Based Network

Access Control

RFC 1492 TACACS+

Secure Sockets Layer (SSL)

SSHv1/SSHv2 Secure Shell

HP ProCurve Switch 2610 Series

Specifications

HP ProCurve Switch 2610-48-PWR (J9089A) HP ProCurve Switch 2610-24/12PWR (J9086A)

Ports

48 auto-sensing 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE

802.3u Type 100Base-TX); Media Type: Auto-MDIX; Duplex: half or

full

24 auto-sensing 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE

802.3u Type 100Base-TX); Media Type: Auto-MDIX; Duplex: half or

full

1 RJ-45 serial console port 1 RJ-45 serial console port

2 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T, IEEE

802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Duplex:

10Base-T/100Base-TX: half or full; 1000Base-T: full only

2 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T, IEEE

802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Duplex:

10Base-T/100Base-TX: half or full; 1000Base-T: full only

2 open mini-GBIC (SFP) slots 2 open mini-GBIC (SFP) slots

Physical characteristics

Dimensions 13.5(d) x 17.4(w) x 1.73(h) in. (34.29 x 44.2 x 4.39 cm) (1U height) 9.3(d) x 17.4(w) x 1.73(h) in. (23.62 x 44.2 x 4.39 cm) (1U height)

Weight 16.7 lb. (7.58 kg), Fully loaded 7.5 lb. (3.4 kg)

Memory and processor

Processor MIPS @ 300 MHz, 16 MB flash, 128 MB SDRAM; packet buffer size:

2 MB

MIPS @ 300 MHz, 16 MB flash, 128 MB SDRAM; packet buffer size:

1 MB

Mounting

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet

(hardware included); horizontal surface mounting only

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet

(hardware included); horizontal surface mounting only

Performance

100 Mb Latency < 6.2 µs (LIFO) < 4.1 µs

1000 Mb Latency < 4.4 µs (LIFO) < 2.9 µs

Throughput up to 13.0 million pps up to 9.5 million pps

Routing/Switching capacity 17.6 Gbps 12.8 Gbps

MAC address table size 8000 entries 8000 entries

Environment

Operating temperature 32ºF to 122ºF (0ºC to 50ºC) 32ºF to 122ºF (0ºC to 50ºC)

Operating relative humidity 15% to 95% @ 104ºF (40ºC), non-condensing 15% to 95% @ 104ºF (40ºC), non-condensing

Non-operating/Storage temperature -40ºF to 158ºF (-40ºC to 70ºC) -40ºF to 158ºF (-40ºC to 70ºC)

Non-operating/Storage relative humidity 15% to 90% @ 149ºF (65ºC), non-condensing 15% to 90% @ 149ºF (65ºC), non-condensing

Altitude up to 10000 ft. (3 km) up to 10000 ft. (3 km)

Acoustic Power: 63.6 dB, Pressure: 56.6 dB; DIN 45635T.19 per ISO 7779 Power: 46 dB, Pressure: 38.4 dB; DIN 45635T.19 per ISO 7779

Electrical characteristics

Maximum heat dissipation 410 BTU/hr (432.55 kJ/hr), (switch-only BTU/hr: 410; combined

switch + max. PoE devices at 15.4 W: 2281 BTU/hr)

181 BTU/hr (190.96 kJ/hr), (switch-only BTU/hr: 181; combined

switch + max. PoE devices at 15.4 W: 827 BTU/hr)

Voltage 100-127 / 200-240 VAC 100-127 / 200-240 VAC

Current 7.0 / 3.5 A 3.3 / 1.7 A

Power consumption 96 W 62 W

Frequency 50 / 60 Hz 50 / 60 Hz

Notes Maximum power rating is the worst-case theoretical maximum power

number with fully loaded PoE, 100% traffic, all ports plugged in, and

all modules populated.

Power consumption: 96 W without PoE; 590 W with PoE.

Maximum power rating is the worst-case theoretical maximum power

number with fully loaded PoE, 100% traffic, all ports plugged in, and

all modules populated.

Power consumption: 62 W without PoE; 189 W with PoE.

HP ProCurve Switch 2610 Series

Safety

CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950 CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950

Emissions

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A

Immunity

EN EN 55024, CISPR 24 EN 55024, CISPR 24

ESD IEC 61000-4-2; 4 kV CD, 8 kV AD IEC 61000-4-2; 4 kV CD, 8 kV AD

Radiated IEC 61000-4-3; 3V/m IEC 61000-4-3; 3V/m

EFT/Burst IEC 61000-4-4; 1.0 kV(power line), 0.5kV (signal line) IEC 61000-4-4; 1.0 kV(power line), 0.5kV (signal line)

Surge IEC 61000-4-5; 1 kV/2 kV AC IEC 61000-4-5; 1 kV/2 kV AC

Conducted IEC 61000-4-6; 3V IEC 61000-4-6; 3V

Power frequency magnetic field IEC 61000-4-8; 1A/m,50 or 60 Hz IEC 61000-4-8; 1A/m,50 or 60 Hz

Voltage dips and interruptions IEC 61000-4-11; >95% reduction, 0.5 period; 30% reduction, 25

periods

IEC 61000-4-11; >95% reduction, 0.5 period; 30% reduction, 25

periods

Harmonics EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2

Flicker EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3

Management

HP ProCurve Manager Plus; HP ProCurve Manager (included);

command-line interface; Web browser; configuration menu;

out-of-band management (serial RS-232C)

HP ProCurve Manager Plus; HP ProCurve Manager (included);

command-line interface; Web browser; configuration menu;

out-of-band management (serial RS-232C)

Notes

When using mini-GBICs with this product, mini-GBICs with revision

"B" or later (product ends with the letter "B" or later, e.g., J4858B,

J4859C) are required.

When using mini-GBICs with this product, mini-GBICs with revision

"B" or later (product ends with the letter "B" or later, e.g., J4858B,

J4859C) are required.

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (U4683E)

3-year, 4-hour onsite, 24x7 coverage for hardware (U4835E)

3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software

phone support (U6321E)

3-year, 24x7 SW phone support, software updates (UF792E)

Installation with minimum configuration, system-based pricing

(U4826E)

Installation with HP-provided configuration, system-based pricing

(U4830E)

Refer to the HP Web site at www.procurve.com/services for details

on the service-level descriptions and product numbers. For details

about services and response times in your area, please contact your

local HP sales office.

3-year, 4-hour onsite, 13x5 coverage for hardware (U4683E)

3-year, 4-hour onsite, 24x7 coverage for hardware (U4835E)

3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software

phone support (U6321E)

3-year, 24x7 SW phone support, software updates (UF792E)

Installation with minimum configuration, system-based pricing

(U4826E)

Installation with HP-provided configuration, system-based pricing

(U4830E)

Refer to the HP Web site at www.procurve.com/services for details

on the service-level descriptions and product numbers. For details

about services and response times in your area, please contact your

local HP sales office.

HP ProCurve Switch 2610 Series

Standards and protocols Device management

HTML and telnet management

General protocols

IEEE 802.1D MAC Bridges

IEEE 802.1p Priority

IEEE 802.1Q VLANs

IEEE 802.1v VLAN classification by

Protocol and Port

IEEE 802.1w Rapid Reconfiguration of

Spanning Tree

IEEE 802.3ad Link Aggregation

Control Protocol (LACP)

IEEE 802.3af Power over Ethernet

IEEE 802.3x Flow Control

RFC 768 UDP

RFC 783 TFTP Protocol (revision 2)

RFC 792 ICMP

RFC 793 TCP

RFC 826 ARP

RFC 854 TELNET

RFC 951 BOOTP

RFC 1542 BOOTP Extensions

RFC 2030 Simple Network Time

Protocol (SNTP) v4

RFC 2131 DHCP

RFC 3046 DHCP Relay Agent

Information Option

IP multicast

RFC 3376 IGMPv3

MIBs

RFC 1213 MIB II

RFC 1493 Bridge MIB

RFC 2021 RMONv2 MIB

RFC 2096 IP Forwarding Table MIB

RFC 2613 SMON MIB

RFC 2618 RADIUS Client MIB

RFC 2665 Ethernet-Like-MIB

RFC 2668 802.3 MAU MIB

RFC 2674 802.1p and IEEE 802.1Q

Bridge MIB

RFC 2737 Entity MIB (Version 2)

RFC 2863 The Interfaces Group MIB

Network management

IEEE 802.1AB Link Layer Discovery

Protocol (LLDP)

RFC 3164 BSD syslog Protocol

RFC 3176 sFlow

ANSI/TIA-1057 LLDP Media Endpoint

Discovery (LLDP-MED)

SNMPv1/v2c/v3

Security

IEEE 802.1X Port Based Network

Access Control

RFC 1492 TACACS+

Secure Sockets Layer (SSL)

SSHv1/SSHv2 Secure Shell

HP ProCurve Switch 2610 Series accessories

HP ProCurve 100-FX SFP-LC Transceiver (J9054B)

NEW HP ProCurve 100-BX-D SFP-LC Transceiver (J9099B)

NEW HP ProCurve 100-BX-U SFP-LC Transceiver (J9100B)

HP ProCurve Gigabit-SX-LC Mini-GBIC (J4858C)

HP ProCurve Gigabit-LX-LC Mini-GBIC (J4859C)

HP ProCurve Gigabit-LH-LC Mini-GBIC (J4860C)

HP ProCurve Gigabit 1000Base-T Mini-GBIC (J8177C)

NEW HP ProCurve 1000-BX-D SFP-LC Mini-GBIC (J9142B)

NEW HP ProCurve 1000-BX-U SFP-LC Mini-GBIC (J9143B)

HP ProCurve 600 Redundant External Power Supply (J8168A)

HP ProCurve 610 External Power Supply (J8169A)

HP ProCurve Manager 2.3 (-)

HP ProCurve Network Immunity Manager 1.0 50-device license (J9060A)

HP ProCurve Network Immunity Manager 1.0 +100-device license

(J9061A)

HP ProCurve Network Immunity Manager 1.0 unlimited-device license

(J9062A)

For more information

To learn more about HP ProCurve Networking, please visit ProCurve.com

warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or

omissions contained herein. February 2009

This manual suits for next models

Table of contents

Other HP Switch manuals
