HP StorageWorks XP1024 Quick guide

HP StorageWorks

Disk Array XP operating system

conﬁguration guide: Windows

2000/2003

XP12000

XP10000

XP1024

XP128

This guide describes the requirements and procedures for connecting and conﬁguring the XP family

of disk arrays to work with a Windows 2000/2003 system running the Windows 2000/2003

operating system.

Part number: A5951-96193

Fourth edition: November, 2005

Legal and notice information

Conﬁdential computer software. Valid license from HP required for possession, use or copying. Consistent with

FAR 12.211 and 12.212, Commercial Computer Software, Computer Software Documentation, and Technical

Data for Commercial Items are licensed to the U.S. Government under vendor’s standard commercial license.

The information contained herein is subject to change without notice. The only warranties for HP products

and services are set forth in the express warranty statements accompanying such products and services.

Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical

or editorial errors or omissions contained herein.

Microsoft, Windows, Windows XP, and Windows NT are U.S. registered trademarks of Microsoft Corporation.

Disk Array XP operating system conﬁguration guide: Windows 2000/2003

Contents

Preface ......................... 5

Aboutthisguide................................ 5

Intendedaudience............................... 5

Diskarrays.................................. 5

Relateddocumentation............................. 5

Documentconventionsandsymbols ....................... 6

HPtechnicalsupport.............................. 7

Subscriptionservice .............................. 7

OtherHPwebsites .............................. 7

1Installation....................... 9

Featuresandrequirements ........................... 9

FibreChannelinterface.......................... 10

Deviceemulationtypes.......................... 10

Failover ................................ 10

SNMP conﬁguration........................... 11

RAIDManagercommanddevices ..................... 11

Installationprocedures ............................ 12

Install and conﬁgurethediskarray....................... 13

Settingthehostmodeforthediskarrayports ................ 13

SettingtheSystemOptionMode...................... 15

ConﬁguringtheFibreChannelports .................... 16

Fibreaddress............................ 16

Fabric and connection parameter settings . . . . . . . . . . . . . . . . 17

Install and conﬁgurethehost ......................... 18

LoadingtheOSandsoftware ....................... 18

Installing and conﬁguringtheHBAs..................... 18

Cross-referencingHBAs........................ 19

FabriczoningandLUNsecurity ...................... 20

Connectthediskarray............................ 22

Deﬁningthepaths............................ 22

Verifyingthehostrecognizesarraydevices ............... 23

Conﬁgurediskdevices............................ 24

Writingsignatures............................ 24

Creatingandformattingdiskpartitions ................... 25

Verifying ﬁlesystemoperations ...................... 25

Disk Array XP operating system conﬁguration guide: Windows 2000/2003 3

2Troubleshooting.................... 27

Errorconditions............................... 27

CallingtheHPsupportcenter ......................... 29

ContactInformation ........................... 29

Beforeyoucall ............................. 29

APathworksheet .................... 31

BDiskarraysupportedemulations............. 33

Supportedemulations ............................ 33

Emulation speciﬁcations ........................... 34

Glossary........................ 37

Index ......................... 41

Preface

About this guide

This guide provides information about:

•Requirements and procedures for connecting an XP disk array to a host system

•Conﬁguring the disk array for use with the Windows 2000/2003 operating

system

Intended audience

This guide is intended for system administrators with knowledge of:

•The host hardware

•Windows 2000/2003 operating system

•XP disk arrays

Disk arrays

Unless otherwise noted, the term “disk array” refers to these disk arrays:

•HP StorageWorks Disk Array XP128

•HP StorageWorks Disk Array XP1024

•HP StorageWorks XP10000 Disk Array

•HP StorageWorks XP12000 Disk Array

Related documentation

The following documents provide related information:

•HP StorageWorks Disk Array XP128: Owner’s Guide

•HP StorageWorks Disk Array XP1024: Owner’s Guide

•HP StorageWorks XP10000 Disk Array: Owner’s Guide

•HP StorageWorks XP12000 Disk Array: Owner’s Guide

You can ﬁnd these documents on the storage web site:

http://h18006.www1.hp.com/storage/xparrays.html

Disk Array XP operating system conﬁguration guide: Windows 2000/2003 5

Document conventions and symbols

Convention Element

Blue text Cross-reference links and email addresses

Bold •Keys that are pressed

•Text typed into a GUI element, such as a box

•GUI elements that are clicked or selected, such as

menu and list items, buttons, tabs, and check boxes

•Literalvaluestypedexactlyasshown

Italics

Text emphasis and book titles

Blue, underlined:

www.hp.com [http://

www.hp.com]

Web site addresses

Monospace font •File and directory names

•System output

•Code

•Commands, their arguments, and argument values

Monospace, italic

font •Code variables

•Command variables

Monospace, bold

font Emphasized monospace text

WARNING!

Indicates that failure to follow directions could result in bodily harm or death.

CAUTION:

Indicates that failure to follow directions could result in damage to equipment or data.

NOTE:

Provides additional information.

6Preface

HP technical support

In North America, call technical support at 1-800-633-3600, available 24 hours a

day, 7 days a week.

Outside North America, call technical support at the location nearest you. Telephone

numbers for worldwide technical support are listed on the HP support web site:

http://www.hp.com/support. From this web site, select your country.

Collect the following information before calling:

•Technical support registration number (if applicable)

•Product serial numbers

•Product model names and numbers

•Applicable error messages

•Operating system type and revision level

•Detailed questions

For continuous quality improvement, calls may be recorded or monitored.

Subscription service

HP strongly recommends that customers register online using the Subscriber’s Choice

web site: http://www.hp.com/go/e-updates.

Subscribing to this service provides you with e-mail updates about the latest product

enhancements, driver versions, and ﬁrmware documents, plus instant access to many

other product resources.

After subscribing, locate your products by selecting Business support and then Storage

under Product Category.

Other HP web sites

For additional information, see the following HP web sites:

•h

ttp://www.hp.com/go/storage

•http://www.hp.com/support/

•http://www.hp.com/service_locator

•http://www.docs.hp.com

Disk Array XP operating system conﬁguration guide: Windows 2000/2003 7

8Preface

1 Installation

You and your HP service representative each play a role in installation. Your HP service

representative is responsible for installing the disk array and formatting the disk devices.

You are responsible for conﬁguring the host server for the new devices with assistance

from your HP service representative.

Features and requirements

Ask your HP service representative about the latest supported hardware and software.

The disk array has the following features:

•Storage capacity. The storage capacity for each model is listed below:

XP128: From8to128drivesforupto36TB,48FCports

XP1024: From8to1024drivesforupto149TB,64FCports

XP10000: Up to 240drivesforupto69.2TB,48FCports

XP12000: Up to 1152 drives for up to 332 TB, 128 FC ports

•Server support. Windows 2000/2003 PC server with the latest HP supported

patches

•Operating system support. Windows 2000/2003

Before installing the disk array, ensure the environment conforms to these requirements:

•Host Bus Adapters (HBAs) Install HBAs and all utilities and drivers. Refer to the

adapter documentation for installation details.

•(Recommended) HP StorageWorks Remote Web Console XP, Command View

XP Advanced Edition or Command View XP with LUN management feature for

conﬁguring disk array ports and paths

•(Recommended) HP StorageWorks LUN Conﬁguration and Security Manager XP

•(Optional) Other available XP software (some may not apply to your system):

HP StorageWorks Business Copy XP

HP StorageWorks Continuous Access XP

HP StorageWorksContinuousAccessExtensionXP

HP StorageWorks Auto LUN XP

HP StorageWorks Data Exchange XP

HP StorageWorks Resource Manager XP

HP StorageWorks RAID Manager XP

HP StorageWorks Cache LUN XP

Disk Array XP operating system conﬁguration guide: Windows 2000/2003 9

HP StorageWorks Auto Path XP

HP StorageWorks Cluster Extension XP

HP StorageWorks Performance Advisor XP software

Fibre Channel interface

The XP family of disk arrays supports these Fibre Channel elements:

•Connection speed of 1 Gbps and 2 Gbps

•Short-wave non-OFC (open ﬁber control) optical interface

•Multimode optical cables with SC or LC connectors

•Public or private arbitrated loop (FC-AL) or direct fabric attach

Even though the interface is Fibre Channel, this guide uses the term “SCSI disk” because

disk array devices are deﬁned to the host as SCSI disks.

Device emulation types

The XP family of disk arrays supports these device emulation types:

•OPEN-3/8/9/E/L/V devices: OPEN-x logical units represent disk devices.

Except for OPEN-V, these devices are based on ﬁxed sizes. OPEN-V is a

user-deﬁned size. Supported emulations include OPEN-3, OPEN-8, OPEN-9,

OPEN-E, OPEN-L, and OPEN-V devices.

•LUSE devices (OPEN-

): Logical Unit Size Expansion (LUSE) devices combine

2 to 36 OPEN-x devices to create expanded LDEVs larger than standard

OPEN-3/8/9/E/L/V disk devices. For example, an OPEN-x LUSE volume

created from ten OPEN-x volumes is designated as OPEN-x*10.

•CVS devices (OPEN-x CVS): Volume Size Conﬁguration (VSC) deﬁnes custom

volumes (CVS) that are smaller than normal ﬁxed-sized logical disk devices

(volumes). (OPEN-V is a CVS-based custom disk size that you determine. OPEN-L

does not support CVS.)

•LUSE (expanded) CVS devices (OPEN-x*n CVS): LUSE CVS combines CVS devices

to create an expanded device. This is done by ﬁrst creating CVS custom-sized

devices and then using LUSE to combine from 2 to 36 CVS devices. For example,

if three OPEN-9 CVS volumes are combined to create an expanded device, this

device is designated as OPEN-9*3-CVS.

Failover

The XP family of disk arrays supports many standard software products that provide host,

application, or I/O path failover and management.

10 Installation

Other manuals for StorageWorks XP1024

This manual suits for next models

Table of contents

Other HP Storage manuals

HP Surestore Disk Array 12h - And FC60 Service manual

HP 3PAR StoreServ 7200 2-node Use and care manual

HP StorageWorks P4000 Series User manual

HP P2000 G3 User manual

HP StorageWorks 9000 Virtual Libr User manual

HP StorageWorks MSL2024 User manual

HP D2D User manual

HP 418371-B21 - Dual Port 72 GB Hard Drive User manual

HP StorageWorks 6000 - Virtual Library System User manual

HP P9000 User manual

HP StorageWorks 1510i - Modular Smart Array User manual

HP D2D100 Instruction Manual

HP AH164A - StorageWorks 1/8 G2 Tape Autoloader Ultrium... User manual

HP StorageWorks 2000 Series User manual

HP STORAGEWORKS ALL-IN-ONE STORAGE SYSTEM User manual

HP Xw4400 - Workstation - 2 GB RAM Assembly Instructions

HP StorageWorks 2100 - Disk System User manual

HP Surestore 100st - Archive Server User manual

HP StorageWorks 7100 - Virtual Array User manual

HP StorageWorks 400r All-in-One User instructions

HP StoreVirtual P4000 G2 Service manual

HP StorageWorks XP1024 Quick guide

HP StorageWorks X5000 Instruction Manual

HP MSA 2040 User instructions

Popular Storage manuals by other brands

QNAP

QNAP TS 32PXU Series user guide

LaCie

LaCie RUGGED RAID user manual

Freecom

Freecom CLS DOCK Quick install guide

PNY

PNY Attache P-FD64MBATT3 install guide

OLT

OLT 6x6 Maximizer Assembly manual

Transcend

Transcend JetFlash 160 Specifications

LaCie

LaCie RUGGED MINI user manual

Thunderbolt

Thunderbolt 600 user manual

Panasonic

Panasonic LB-DH8 series Operator's guide

Intel

Intel RAID High Availability user guide

LaCie

LaCie 12big Thunderbolt 3 Quick install guide

Spectra Logic

Spectra Logic T-Series Spectra T50e quick start guide

Panasonic

Panasonic LKM-F931-1 instruction manual

Tabernus

Tabernus Enterprise Erase E2400 user guide

Rocstor

Rocstor COMMANDER 3F series user manual

Western Digital

Western Digital Ultrastar Data60 installation guide

Dell

Dell PowerVault MD3600f Series Getting started

CFI

CFI TERA STOR SATA RAID IV user manual
