HP StorageWorks DAT 40i User manual

getting started guide

hp StorageWorks

DAT tape drive

internal model

DAT 40i, DAT 72i

open this flap for quick

start installation poster

2 3

6 7

UNIX

Internal drives- contents

Pre-Installation

Before you start page 3

Backup software and drivers page 5

Using the CD-ROM page 7

Checking the SCSI connection page 9

Installing the tape drive

Step 1: Check the drive’s SCSI ID page 11

Step 2: Set the configuration switches (UNIX systems) page 13

Step 3: Prepare the mounting bay page 15

Step 4: Attach mounting hardware page 17

Step 5: Attach power extension cable and install drive page 19

Step 6: Attach power and SCSI cables page 21

Step 7: Secure the drive page 23

Step 8: Verify installation page 25

Using the tape drive

Your HP StorageWorks DAT tape drive page 27

Use the correct media page 29

Using HP OBDR page 33

Diagnostic tools page 35

Optimizing performance page 36

Troubleshooting page 37

Problems with cartridges page 41

Other sources of information page 43

Replacing your tape drive page 44

dds-internal-frame6.fm Page 1 Monday, January 5, 2004 5:01 PM

November 2003

Part Number: C5686-90906

Hewlett-Packard Company makes no warranty of any kind with regard to this material,

including, but not limited to, the implied warranties of merchantability and fitness for a

particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the furnishing, performance, or use

of this material.

This document contains proprietary information, which is protected by copyright. No part of

this document may be photocopied, reproduced, or translated to another language without

the prior written consent of Hewlett-Packard. The information contained in this document is

subject to change without notice.

Microsoft®, MS-DOS®, MS Windows®, Windows®and Windows NT®are U.S.

registered trademarks of Microsoft Corporation.

UNIX®is a registered trademark of The Open Group.

Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions

contained herein. The information is provided ”as is” without warranty of any kind and is

subject to change without notice. The warranties for Hewlett-Packard Company products are

set forth in the express limited warranty statements for such products. Nothing herein should

be construed as constituting an additional warranty.

Printed in the U.K.

Product Details

Write your tape drive details here so you can find them easily if you need them. The model name is on the

front of the drive and the product and serial numbers are on a label on the bottom of the drive.

Model (type of drive):

Model (number):

Serial (number):

Warranty Serial (number):

Date purchased/installed:

SCSI ID:

dds-internal-frame6.fm Page 2 Monday, January 5, 2004 5:01 PM

Before you start

HP StorageWorks DAT models

This guide describes how to install and operate the following HP StorageWorks DAT internal

tape drive models:

•HPStorageWorksDAT72

•HPStorageWorksDAT40

Which operating systems are supported?

HP StorageWorks DAT drives can be connected to servers running under Windows®,

NetWare, UNIX, Tru64 and Linux. Refer to the “HP StorageWorks Tape Software

Compatibility” topic on our World Wide Web site (www.hp.com/go/connect) for more

information about the operating system versions that are supported.

How do I connect the drive to my server?

You will need a properly installed and configured SCSI host bus adapter (HBA) or a built-in

SCSI controller on your server. Your tape drive is attached to the SCSI bus of the host server

via a spare connection on the internal SCSI ribbon cable. The cable should be compatible

with low voltage differential SCSI (LVDS) and it should have a spare 68-pin, high density

(HD), wide SCSI connector. See “Checking the SCSI connection” on page 9. The cable must

be terminated, see “Step 6: Attach power and SCSI cables” on page 21.

Why is the SCSI bus type important?

The SCSI bus type determines the speed at which data can be transferred between devices on

the bus and the maximum length of cable that can be used. The drives support a burst transfer

rate of 40 MB/sec. To benefit from this level of performance, it is important to ensure that the

drives are connected to a SCSI bus of a similar or higher specification. This means that you

need:

•An Ultra Wide, Ultra2 Wide, Ultra3 (160) or Ultra4 (320) SCSI bus. Ultra Wide SCSI

supports the maximum bus speed of 40 MB per second, Ultra2, Ultra3 and Ultra4 SCSI

exceeds this.

•LVD-rated SCSI cabling and terminators. The LVD interface enables the data to be

transferred at the drive's maximum rate.

If you attach the drive to a lower specification SCSI bus, it may still work but data will not be

transferred as quickly.

Note The drives are not compatible with high voltage differential (HVD) SCSI devices.

The following guidelines apply:

• For optimum performance the drive should be the only device on the SCSI bus.

• Always terminate the SCSI bus.

• Do not attach the drive to the same SCSI bus as a your disk drive or to a RAID controller.

dds-internal-frame6.fm Page 3 Monday, January 5, 2004 5:01 PM

How can I check the SCSI bus type and SCSI ID?

For many operating systems, you can install HP Library & Tape Tools from www.hp.com/

support/tapetools and run the “Install Check” to check your server’s current SCSI

configuration (see page 35). This will provide information about the SCSI bus and the SCSI

IDs in use. See also the SCSI topic in the electronic User’s Guide on the

HP StorageWorks Tape CD-ROM for other ways of checking the SCSI bus type.

What are the mounting requirements for the tape drive?

Mounting bay

You need one industry standard, 5¼-inch, half-height bay in which to install the

HP StorageWorks DAT tape drive. Power requirements are:

Mounting hardware

For many servers, no mounting tray or rails are required. Devices simply slide into the server’s

chassis and are fixed with screws. Other servers have built-in trays or rails.

Rail kits for a number of industry-standard servers may be available. For more details refer to:

www.hp.com/go/connect.

Some servers use non-standard mounting rails and do not include spares. If this is the case

with your system, you will have to order these accessories from the server manufacturer before

you can install the tape drive.

Do I need additional items for installation?

• You may need mounting hardware. See “What are the mounting requirements for the tape

drive?” above.

• If you do not have a spare, suitably-rated SCSI connector on your server, you must install a

new HBA (also known as a SCSI card). This should be of an Ultra Wide or higher SCSI

specification. You will need to purchase and install the new HBA into an unused, 64-bit PCI

expansion slot within your server before installing your tape drive. (The kit can also be

installed in a 32-bit PCI expansion slot, but performance may be degraded.)

Voltage Typical Current Maximum Current

5 V 3.5 A 4.0 A

12 V 0.3 A 1.7 A

Refer to our World Wide Web site for recommended products, configurations and ordering

information: www.hp.com/go/connect or www.hp.com/support.

dds-internal-frame6.fm Page 4 Monday, January 5, 2004 5:01 PM

Backup software and drivers

Backup software

For optimum performance it is important to use a backup application that is appropriate for

your system’s configuration. In a direct attach configuration, where the tape drive is attached

to a standalone server, you can use backup software that is designed for a single server

environment. In network configurations you will need backup software that supports enterprise

environments. HP, Veritas, Legato, Yosemite and Computer Associates all provide suitable

products. Further details about these and other products that may be appropriate can be

found on our connectivity web site.

1Go to our connectivity web site: www.hp.com/go/connect and select tape backup.

2Select software compatibility.

3Select your combination of operating system and tape drive model in the table. A list of

supported backup applications is displayed. This will also tell you whether your configuration

is compatible with HP One-Button Disaster Recovery, HP OBDR. (All HP StorageWorks DAT

tape drives support HP OBDR. However, you can only use this feature if your system

configuration and backup application also support it. See “Using HP OBDR” on page 33.)

4Make sure you have a backup application that supports HP StorageWorks DAT tape drives and

download any upgrades or patches, if required.

Drivers

Windows users

Before you install the tape drive, download the HP driver from our web site: www.hp.com/

support. Refer to the accompanying README file for specific installation instructions for

Windows NT, Windows 2000, Windows XP and Windows Server 2003 drivers. This will tell

you whether you need to install the driver before or after installing the tape drive.

If you do not have internet access, you can also download drivers from the

HP StorageWorks Tape CD-ROM, but these may not be the latest versions available.

UNIX users

The recommended backup applications use the operating system’s standard, built-in device

drivers. To upgrade drivers we recommend that you patch to the latest version of the operating

system or configure device files, as described in the UNIX Configuration Guide on the CD-

ROM.

IA64 users

If you are installing on an IA64 system, such as an HP Integrity server, check www.hp.com/

go/connect for the latest information on the availability of backup application upgrades

and drivers.

dds-internal-frame6.fm Page 5 Monday, January 5, 2004 5:01 PM

HP Product

Registration

User

Documentation

CD-ROM Guide

Drivers

HP Library &

Tape Tools

Figure 1: the HP StorageWorks Tape CD-ROM
