Hotpoint Ariston ARSL 105 User manual

Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Description of the washing machine

and starting a wash cycle, 4-5

Control panel

Indicator lights

Starting a wash cycle

ash cycles, 6

Table of wash cycles

Personalisation, 7

Setting the temperature

Setting the spin speed

Functions

Detergents and laundry, 8

Detergent dispenser drawer

Bleach cycle

reparing the laundry

Garments requiring special care

Load balancing system

Precautions and tips, 9

General safety

Disposal

Opening the porthole door manually

Care and maintenance, 10

Cutting off the water or electricity supply

Cleaning the washing machine

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Troubleshooting, 11

Service, 12

ARSL 105

Instructions for use

ASHING MACHINE

English,1

Polski,13

PL HU

Magyar,25

Èeský,37

Italiano,49

Installation

 This instruction manual should be kept in a safe

place for future reference. If the washing machine is

sold, transferred or moved, make sure that the

instruction manual remains with the machine so that

the new owner is able to familiarise himself/herself

with its operation and features.

 Read these instructions carefully: they contain vital

information relating to the safe installation and

operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washing machine from its packaging.

2. Make sure that the washing machine has not been

damaged during the transportation process. If it has

been damaged, contact the retailer and do not

proceed any further with the installation process.

3. Remove the 4

protective screws (used

during transportation) and

the rubber washer with

the corresponding

spacer, located on the

rear part of the appliance

(see figure).

4. Close off the holes using the plastic plugs provided.

5. Keep all the parts in a safe place: you will need

them again if the washing machine needs to be

moved to another location.

 ackaging materials should not be used as toys for

children.

Levelling

1. Install the washing machine on a flat sturdy floor,

without resting it up against walls, furniture cabinets

or anything else.

2. If the floor is not

perfectly level, compen-

sate for any unevenness

by tightening or loosening

the adjustable front feet

(see figure); the angle of

inclination, measured in

relation to the worktop,

must not exceed 2°.

Levelling the machine correctly will provide it with

stability, help to avoid vibrations and excessive noise

and prevent it from shifting while it is operating. If it is

placed on carpet or a rug, adjust the feet in such a

way as to allow a sufficient ventilation space

underneath the washing machine.

Connecting the electricity and water

supplies

Connecting the water inlet hose

1. Connect the supply

pipe by screwing it to a

cold water tab using a ¾

gas threaded connection

(see figure).

Before performing the

connection, allow the

water to run freely until it

is perfectly clear.

2. Connect the inlet hose

to the washing machine

by screwing it onto the

corresponding water inlet

of the appliance, which is

situated on the top right-

hand side of the rear part

of the appliance (see

figure).

3. Make sure that the hose is not folded over or bent.

 The water pressure at the tap must fall within the

values indicated in the Technical details table (see

next page).

 If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

 Never use second-hand hoses.

 Use the ones supplied with the machine.

Technical data

Model ARSL 105

Dimensions

width 59.5 cm

height 85 cm

depth 40 cm

Capacity from 1 to 5 kg

Electrical

connections

please refer to the technical data

plate fixed to the machine

ater connections

maximum pressure 1 M a (10 bar)

minimum pressure 0.05 M a (0.5 bar)

drum capacity 40 litres

Spin speed up to 1000 rotations per minute

Energy rated

programmes

according to

regulation

EN 60456

programme 6; temperature 60°C;

using a load of 5 kg.

This appliance conforms to the

following EC Directives:

- 89/336/EEC dated 03/05/89

(Electromagnetic Compatibility) and

subsequent modifications

- 2006/95/EC Low Voltage)

- 2002/96/EC

65 - 100 cm

Connecting the drain hose

Connect the drain hose,

without bending it, to a

drainage duct or a wall

drain located at a height

between 65 and 100 cm

from the floor;

alternatively, rest it on

the side of a washbasin

or bathtub, fastening the

duct supplied to the tap

(see figure). The free end

of the hose should not

be underwater.

 We advise against the use of hose extensions; if it is

absolutely necessary, the extension must have the

same diameter as the original hose and must not

exceed 150 cm in length.

Electrical connections

Before plugging the appliance into the electricity

socket, make sure that:

 the socket is earthed and complies with all

applicable laws;

 the socket is able to withstand the maximum power

load of the appliance as indicated in the Technical

data table (see opposite);

 the power supply voltage falls within the values

indicated in the Technical data table (see opposite);

 the socket is compatible with the plug of the

washing machine. If this is not the case, replace

the socket or the plug.

 The washing machine must not be installed

outdoors, even in covered areas. It is extremely

dangerous to leave the appliance exposed to rain,

storms and other weather conditions.

 When the washing machine has been installed, the

electricity socket must be within easy reach.

 Do not use extension cords or multiple sockets.

 The cable should not be bent or compressed.

 The power supply cable must only be replaced by

authorised technicians.

Warning! The company shall not be held responsible

in the event that these regulations are not respected.

The first wash cycle

Once the appliance has been installed, and before

you use it for the first time, run a wash cycle with

detergent and no laundry, using the wash cycle 1.

Detergent dispenser drawer: used to dispense

detergents and washing additives (see Detergents

and laundry).

There is a key which provides a summary of the

available wash cycles inside the detergent dispenser

drawer; this may be consulted at any time.

ON/OFF button: switches the washing machine on

and off.

ASH CYCLE knob: programmes the wash cycles.

During the wash cycle, the knob does not move.

FUNCTION buttons with indicator light: used to

select the available functions. The indicator light

corresponding to the selected function will remain lit.

TEMPERATURE knob: sets the temperature or the

cold wash cycle (see Personalisation).

SPIN SPEED knob: sets the spin speed or exclude

the spin cycle completely (see Personalisation).

ASH CYCLE PROGRESS/DELAY TIMER

indicator light

s: used to monitor the progress of the

wash cycle.

The illuminated indicator light shows which phase is in

progress.

If the Delay Timer function has been set, the time

remaining until the wash cycle starts will be indicated

(see next page).

DOOR LOCKED indicator light: indicates whether

the door may be opened or not (see next page).

START/PAUSE button with indicator light: starts or

temporarily interrupts the wash cycles.

N.B. To pause the wash cycle in progress, press this

button; the corresponding indicator light will flash

orange, while the indicator light for the current wash

cycle phase will remain lit in a fixed manner. If the

DOOR LOCKED indicator light is switched off, the

door may be opened.

To start the wash cycle from the point at which it was

interrupted, press this button again.

Standby mode

This washing machine, in compliance with new

energy saving regulations, is fitted with an automatic

standby system which is enabled after about 30

minutes if no activity is detected. ress the ON-OFF

button briefly and wait for the machine to start up

again.

Description of the washing machine

and starting a wash cycle

TEMPERATURE

knob

Detergent dispenser drawer

ASH CYCLE PROGRESS/

DELAY TIMER

indicator lights

FUNCTION

buttons with

indicator lights

ON/OFF

button

SPIN SPEED

knob

DOOR

LOCKED

indicator light

START/PAUSE

button with indicator

light

Control panel

ASH CYCLE

knob

Indicator lights

The indicator lights provide important information.

This is what they can tell you:

Delayed start

If the DELAY TIMER function has been activated (see

Personalisation), after the wash cycle has been

started the indicator light corresponding to the

selected delay period will begin to flash:

As time passes, the remaining delay will be displayed

and the corresponding indicator light will flash:

Once the set delay has elapsed, the flashing indicator

light will switch off and the selected wash cycle will

begin.

ash cycle phase indicator lights

Once the desired wash cycle has been selected and has

begun, the indicator lights switch on one by one to

indicate which phase of the cycle is currently in progress.

Function buttons and corresponding indicator

lights

When a function is selected, the corresponding

indicator light will illuminate.

If the selected function is not compatible with the

programmed wash cycle, the corresponding indicator

light will flash and the function will not be activated.

If a function which is incompatible with another

function selected previously, only the most recent

selection will remain active.

Door locked indicator light

If this indicator light is on, the appliance door is locked

to prevent it from being opened accidentally; to avoid

any damage, wait for the indicator light to switch off

before you open the appliance door.

N.B. If the DELAY TIMER function is activated, the door

cannot be opened; pause the machine by pressing the

START/ AUSE button if you wish to open it.

 If the START/ AUSE indicator light (orange) flashes

rapidly at the same time as the function indicator

light, this indicates a problem has occurred (see

Troubleshooting).

Starting a wash cycle

1. Turn the washing machine on by pressing the ON/OFF button. All the indicator lights will turn on for a few

seconds, then only the indicator lights relative to the selected programme settings will remain lit and the START/

AUSE indicator light will flash.

2. Load the laundry and close the door.

3. Set the WASH CYCLE knob to the desired programme.

4. Set the washing temperature (see Personalisation).

5. Set the spin speed (see Personalisation).

6. Measure out the detergent and washing additives (see Detergents and laundry).

7. Select the desired functions.

8. Start the wash cycle by pressing the START/ AUSE button and the corresponding indicator light will remain lit

in a fixed manner, in green. To cancel the set wash cycle, pause the machine by pressing the START/ AUSE

button and select a new cycle.

9. At the end of the wash cycle the indicator light will switch on. The DOOR LOCKED indicator light will switch

off, indicating that the door may be opened. Take out your laundry and leave the appliance door ajar to make

sure the drum dries completely. Switch the washing machine off by pressing the ON/OFF button.

Wash

Rinse

Spin

Drain no spin

End of wash cycle

Specials wash cycles

Sanitizing cycle (wash cycle 6). A high-temperature hygienic wash cycle (over 60°C) which requires the use of bleach.

our the bleach, the detergent and the additives into the relevant compartments (see paragraph entitled

Detergent dispenser drawer).

Goodnigt cycle (wash cycle 7). This is a silent cycle which can be run at night, when the electricity prices are lower. The

wash cycle is designed for cottons and synthetics. At the end of the cycle the machine stops while there is still water in

the drum; to spin and drain the laundry press the START/ AUSE button; alternatively the machine will perform the spin

cycle and drain the water automatically after 8 hours.

Baby cycle (wash cycle 8). This wash cycle can be used to remove the soiling typically caused by babies, while ensuring

that all detergent is removed from nappies in order to prevent the delicate skin of babies from suffering allergies. The

cycle has been designed to reduce the amount of bacteria by using a greater quantity of water and optimising the effect

of special disinfecting additives added to the detergent.

At the end of the wash cycle, the machine will slowly rotate the drum to prevent the formation of creases; to end the cycle

press the START/ AUSE button.

Mix 30(wash cycle 4) this wash cycle was designed to wash lightly soiled garments quickly: it lasts just 30 minutes and

therefore saves both energy and time. By selecting this wash cycle (4 at 30°C), it is possible to wash different fabrics

together (except for wool and silk items), with a maximum load of 3 kg.

Mix 15(wash cycle 5) this wash cycle was designed to wash lightly soiled garments quickly: it lasts just 15 minutes and

therefore saves both energy and time. By selecting this wash cycle (5 at 30°C), it is possible to wash different fabrics

together (except for wool and silk items), with a maximum load of 1.5 kg.

ash cycles

The information contained in the table is intended as a guide only.

For all Test Institutes:

1) Test wash cycle in co pliance with regulation EN 60456: set wash cycle 6 with a te perature of 60°C.

2) Long wash cycle for cottons: set wash cycle 1 with a te perature of 40°C.

3) Short wash cycle for cottons: set wash cycle 2 with a te perature of 40°C.

Wash cycles

Table of wash cycles

Description of the wash cycle

Max

te p.

(°C)

Max.

speed

(rp )

Detergents Max.

load

(kg)

Cycle

duration

Bleach Wash Fabric

softener

Special cycles

6Sanitizing cycle: Extremely soiled whites. 90° 1000 ll l 5165

6Sanitizing cycle (1): Heavily soiled whites and resistant colours. 60° 1000 -ll

5 145

7Goodnigt cycle: Lightly soiled delicate colours. 40° 1000 -ll

3290

8Baby cycle: Heavily soiled delicate colours. 40° 800 -ll

2 120

9Shirts 40° 600 -ll

270

10 Silk/Curtains: For garments in silk and viscose, lingerie. 30° 0 -ll

155

11 Wool: For wool, cashmere, etc. 40° 600 -ll

155

Everyday wash cycles (Daily)

1Cotton: Heavily soiled whites and resistant colours. 60° 1000 ll l 5 122

1Cotton (2): Heavily soiled whites and delicate colours. 40° 1000 ll l 5105

2Coloured Cottons (3): Lightly soiled whites and delicate colours. 40° 1000 ll l 585

3Synthetics resistents: Heavily soiled resistant colours. 60° 800 -ll

2,5 85

3Synthetics delicates: Lightly soiled resistant colours. 40° 800 -ll

2,5 70

4Mix 30': To refresh lightly soiled garments quickly (not suitable

for wool, silk and clothes which require washing by hand). 30° 800 -ll

330

5Mix 15': To refresh lightly soiled garments quickly (not suitable

for wool, silk and clothes which require washing by hand). 30° 800 -ll

1,5 15

Partial wash cycles

ARinse -1000 - - l536

BLight rinse -800 - - l2,5 31

CSpin -1000 - - - 516

DLight spin -800 - - - 2,5 12

EDrain no spin -0- - - 52

Setting the temperature

Turn the TEM ERATURE knob to set the wash temperature (see Table of wash cycles).

The temperature may be lowered, or even set to a cold wash ( ).

The washing machine will automatically prevent you from selecting a temperature which is higher than the

maximum value set for each wash cycle.

Setting the spin speed

Turn the S IN S EED knob to set the spin speed for the selected wash cycle.

The maximum spin speeds available for each wash cycle are as follows:

Wash cycles Maxi u spin speed

Cottons 1000 rpm

Synthetics 800 rpm

Wool 600 rpm

Silk drain only

The spin speed may be lowered, or the spin cycle can be excluded altogether by selecting the symbol .

The washing machine will automatically prevent you from selecting a spin speed which is higher than the

maximum speed set for each wash cycle.

Functions

The various wash functions available with this washing machine will help to achieve the desired results, every time.

To activate the functions:

1. ress the button corresponding to the desired function;

2. the function is enabled when the corresponding indicator light is illuminated.

Note: If the indicator light flashes rapidly, this signals that this particular function may not be selected in

conjunction with the selected wash cycle.

Delay timer

This timer delays the start time of the wash cycle by up to 12 hours.

ress the button repeatedly until the indicator light corresponding to the desired delay time switches on. The fifth time

the button is pressed, the function will be disabled.

N.B. Once you have pressed the START/ AUSE button, the delay time may only be decreased if you wish to modify it.

This option is enabled with all programmes.

Easy iron

By selecting this function, the wash and spin cycles will be modified in order to reduce the formation of creases.

At the end of the cycle the washing machine will perform slow rotations of the drum; the EASY IRON and START/

AUSE indicator lights will flash (orange) and the phase will remain lit in a fixed manner. To end the cycle, press

the START/ AUSE button or the EASY IRON button.

For the Silk (10) wash cycle, the machine will end the cycle while the laundry is soaking and the EASY IRON and

START/ AUSE indicator lights will flash (orange) and the RINSE phase will remain lit in a fixed manner. To drain the

water so that the laundry may be removed, press the START/ AUSE button or the EASY IRON button.

 This function may not be used in conjunction with wash cycles 4, 5, 6, 7, 8, 11, C, D, E.

Extra rinse

By selecting this function, the efficiency of the rinse is increased and optimal detergent removal is guaranteed. It is

particularly useful for sensitive skin.

 This function may not be used in conjunction with wash cycles 4, 5, C, D, E.

Super ash

Because a greater quantity of water is used in the initial phase of the cycle, and because of the increased cycle

duration, this function offers a high-performance wash.

 This function may not be used in conjunction with wash cycles 4, 5, 6, 10, 11, A, B, C, D, E.

Personalisation

Detergents and laundry

Detergent dispenser drawer

Good washing results also depend on the correct

dose of detergent: adding too much detergent will not

necessarily result in a more efficient wash, and may in

fact cause build up on the inside of your appliance

and contribute to environmental pollution.

 Do not use hand washing detergents because these

create too much foam.

Open the detergent

dispenser drawer and

pour in the detergent or

washing additive, as

follows.

compartment 1: Detergent for the wash cycle

(powder or liquid)

Liquid detergent should only be poured in immediately

prior to the start of the wash cycle.

compartment 2: Additives (fabric softeners, etc.)

The fabric softener should not overflow the grid.

extra compartment 3: Bleach

Bleach cycle

Bleaching may only be performed in conjunction with

wash cycles 1, 2, 6.

our the bleach into extra compartment 3; pour the

detergent and softener into the corresponding

compartments, then select one of the

abovementioned wash cycles.

This option is recommended only for very soiled

cotton garments.

Preparing the laundry

 Divide the laundry according to:

- the type of fabric/the symbol on the label

- the colours: separate coloured garments from

whites.

 Empty all garment pockets and check the buttons.

 Do not exceed the listed values, which refer to the

weight of the laundry when dry:

Durable fabrics: max. 5 kg

Synthetic fabrics: max. 2,5 kg

Delicate fabrics: max. 2 kg

Wool: max. 1 kg

MAX

How much does your laundry weigh?

1 sheet 400-500 g

1 pillow case 150-200 g

1 tablecloth 400-500 g

1 bathrobe 900-1200 g

1 towel 150-250 g

Garments requiring special care

Shirts: use special wash cycle 9 to wash shirts in

various fabrics and colours.

It guarantees maximum care is taken of the garments

and minimises the formation of creases.

Silk: use special wash cycle 10 to wash all silk

garments. We recommend the use of special

detergent which has been designed to wash delicate

clothes.

Curtains: fold curtains and place them in a pillow

case or mesh bag. Use wash cycle 10.

ool: Hotpoint/Ariston is the only washing machine

manufacturer to have been awarded the prestigious

Woolmark latinum Care endorsement (M.0508) by

the Woolmark Company, which means that all

woollen garments may be washed in the washing

machine, even those which state hand wash only

on the label. Wash cycle 11 therefore offers

complete peace of mind when washing woollen

garments in the washing machine (max. load 1 kg)

and guarantees optimal performance.

Load balancing system

Before every spin cycle, to avoid excessive vibrations

and to distribute the load in a uniform manner, the drum

rotates continuously at a speed which is slightly greater

than the washing rotation speed. If, after several at-

tempts, the load is not balanced correctly, the machine

spins at a reduced spin speed. If the load is excessively

unbalanced, the washing machine performs the distri-

bution process instead of spinning. To encourage im-

proved load distribution and balance, we recommend

small and large garments are mixed in the load.

Precautions and tips

 This washing machine was designed and

constructed in accordance with international safety

regulations. The following information is provided for

safety reasons and must therefore be read carefully.

General safety

 This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

Children should be supervised to ensure that they

do not play with the appliance.

 This appliance was designed for domestic use only.

 Do not touch the machine when barefoot or with

wet or damp hands or feet.

 Do not pull on the power supply cable when

unplugging the appliance from the electricity

socket. Hold the plug and pull.

 Do not open the detergent dispenser drawer while

the machine is in operation.

 Do not touch the drained water as it may reach

extremely high temperatures.

 Never force the porthole door. This could damage

the safety lock mechanism designed to prevent

accidental opening.

 If the appliance breaks down, do not under any

circumstances access the internal mechanisms in

an attempt to repair it yourself.

 Always keep children well away from the appliance

while it is operating.

 The door can become quite hot during the wash cycle.

 If the appliance has to be moved, work in a group

of two or three people and handle it with the utmost

care. Never try to do this alone, because the

appliance is very heavy.

 Before loading laundry into the washing machine,

make sure the drum is empty.

Disposal

 Disposing of the packaging materials: observe local

regulations so that the packaging may be re-used.

 The European Directive 2002/96/EC on Waste

Electrical and Electronic Equipment, requires that

old household electrical appliances must not be

disposed of in the normal unsorted municipal waste

stream. Old appliances must be collected

separately in order to optimise the recovery and

recycling of the materials they contain and reduce

the impact on human health and the environment.

Opening the porthole door manually

In the event that it is not possible to open the

porthole door due to a powercut, and if you wish to

remove the laundry, proceed as follows:

1. remove the plug from

the electrical socket.

2. make sure the water

level inside the machine is

lower than the door

opening; if it is not, remove

excess water using the

drain hose, collecting it in a

bucket as indicated in the

figure.

3. using a screwdriver,

remove the cover panel on

the lower front part of the

washing machine (see

figure).

4. pull outwards using the tab as indicated in the

figure, until the plastic tie-rod is freed from its stop

position; pull downwards and open the door at the

same time.

5. reposition the panel, making sure the hooks are

securely in place before you push it onto the

appliance.

The crossed out "wheeled bin" symbol on the

product reminds you of your obligation, that when

you dispose of the appliance it must be separately

collected.

Consumers should contact their local authority or

retailer for information concerning the correct

disposal of their old appliance.

Care and maintenance

Cutting off the water and electricity

supplies

 Turn off the water tap after every wash cycle. This

will limit wear on the hydraulic system inside the

washing machine and help to prevent leaks.

 Unplug the washing machine when cleaning it and

during all maintenance work.

Cleaning the washing machine

The outer parts and rubber components of the

appliance can be cleaned using a soft cloth soaked

in lukewarm soapy water. Do not use solvents or

abrasives.

Cleaning the detergent dispenser

drawer

Remove the dispenser

by raising it and pulling it

out (see figure).

Wash it under running

water; this operation

should be repeated

frequently.

Caring for the door and drum of your

appliance

 Always leave the porthole door ajar in order to

prevent unpleasant odours from forming.

Cleaning the pump

The washing machine is fitted with a self-cleaning

pump which does not require any maintenance.

Sometimes, small items (such as coins or buttons)

may fall into the pre-chamber which protects the

pump, situated in its bottom part.

 Make sure the wash cycle has finished and unplug

the appliance.

To access the pre-chamber:

1. using a screwdriver,

remove the cover panel

on the lower front part of

the washing machine

(see figure);

2. unscrew the lid by

rotating it anti-clockwise

(see figure) a little water

may trickle out. This is

perfectly normal;

3. clean the inside thoroughly;

4. screw the lid back on;

5. reposition the panel, making sure the hooks are

securely in place before you push it onto the

appliance.

Checking the water inlet hose

Check the inlet hose at least once a year. If there are

any cracks, it should be replaced immediately: during

the wash cycles, water pressure is very strong and a

cracked hose could easily split open.

 Never use second-hand hoses.

Table of contents

Languages:

Other Hotpoint Ariston Washer manuals

Hotpoint Ariston

Hotpoint Ariston FMG 723 User manual

Hotpoint Ariston

Hotpoint Ariston RPD 965 D User manual

Hotpoint Ariston

Hotpoint Ariston AVSL 105 User manual

Hotpoint Ariston

Hotpoint Ariston AQ7L 05 U User manual

Hotpoint Ariston

Hotpoint Ariston AVTL 104 User manual

Hotpoint Ariston

Hotpoint Ariston ECO7F 1292 User manual

Hotpoint Ariston

Hotpoint Ariston ECOT7D 149 User manual

Hotpoint Ariston

Hotpoint Ariston WMG 641 User manual

Hotpoint Ariston

Hotpoint Ariston ECO6D 1291 User manual

Hotpoint Ariston

Hotpoint Ariston RZ 1047 B User manual

Hotpoint Ariston

Hotpoint Ariston AWM 129 User manual

Hotpoint Ariston

Hotpoint Ariston FMSD 822 User manual

Hotpoint Ariston

Hotpoint Ariston WML 902 User manual

Hotpoint Ariston

Hotpoint Ariston AQUALTIS AQ9D 48 X User manual

Hotpoint Ariston

Hotpoint Ariston AQUALTIS AQ103F 69 User manual

Hotpoint Ariston

Hotpoint Ariston Aqualtis AQGL 109 User manual

Hotpoint Ariston

Hotpoint Ariston ARXXF 125 User manual

Hotpoint Ariston

Hotpoint Ariston RSG 724 J User manual

Hotpoint Ariston

Hotpoint Ariston ARXF 145 User manual

Hotpoint Ariston

Hotpoint Ariston WMD 942 User manual

Hotpoint Ariston

Hotpoint Ariston AQUALTIS AQ86F 29 User manual

Hotpoint Ariston

Hotpoint Ariston aqualtis aq9f49u User manual

Hotpoint Ariston

Hotpoint Ariston ARSF 109 User manual

Hotpoint Ariston

Hotpoint Ariston Aqualtis AQXGF 169 User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
